- Page 1 CONCRETE POOLS INSTALLATION & OWNER’S MANUAL...
-
Page 2: Table Of Contents
CONTENTS READ THIS FIRST TOOLS REQUIRED PRODUCT SUPPORT AND INFORMATION INCLUDED PARTS FINISHED INSTALLATION INSTALLATION PROCEDURE LIGHT ASSEMBLY LIGHT REMOVAL KEY DIMENSIONS NOTICE HORIZONTAL MOUNT ONLY NOT INTENDED FOR OPERATION OUT OF WATER... -
Page 3: Read This First
• Temperature range for installation, operation and servicing: +5°C ~ +40°C (+41°F ~ +104°F) IMPORTANT NOTE It is recommended that the ATOM lighting range is operated using a Spa Electrics LV25-12 or LV50- 12 transformer. • DO NOT use electronic or switch-mode power supplies with ATOM lights. These power supplies will damage the light and void your product warranty. -
Page 4: Tools Required
TOOLS REQUIRED No. 2 Phillips screwdriver 13mm open-ended spanner Flat-blade screw driver (for light- head removal) IMPORTANT NOTES • The use of power tools for product assembly is NOT recommended as these devices can cause faults and damage to light components. •... -
Page 5: Included Parts
INCLUDED PARTS NICHE & NICHE CAP MOUNTING RING & MOUNTING RING CAP CABLE GLAND LOCKING RING (INC. 2 X SCREWS) PLUG & CABLE LIGHT ASSEMBLY LV25-12 / LV50-12 DUAL / LV100Q-12 TRANSFORMERS (INCLUDED IN SINGLE / DUAL / TRI OR QUAD LIGHT KITS) -
Page 6: Finished Installation
FINISHED INSTALLATION STANDARD WALL MOUNTING BREAK CONDUITS ABOVE WATERLINE WATER LINE (OPTIONAL) DRAW BOX OR SIMILAR 70mm (MAX) 50mm (MIN) CONTINUE CONDUIT TO TRANS- SEALANT FORMER SOIL CONCRETE REINFORCING BARS POOL FINISH 22mm (MAX) 12mm (MIN) 50mm MINIMUM 140mm (STANDARD) CONCRETE 120mm (MINIMUM) COVERAGE... - Page 7 STEP MOUNTING NOTE BREAK CONDUITS (OPTIONAL) ABOVE WATERLINE DRAW BOX OR SIMILAR ENSURE INSTALLED LIGHT IS FULLY SUBMERGED BELOW WATERLINE (ALLOWING FOR EVAPORATION) CONDUIT EXITS WATER LINE HORIZONTALLY FROM NICHE (SEE PAGE 12) CONTINUE CONDUIT SEALANT TO TRANS- FORMER SOIL POOL FINISH 22mm (MAX) 50mm...
-
Page 8: Installation Procedure
INSTALLATION PROCEDURE VERTICAL CONDUIT INSTALLATION 20mm CONDUIT GLUED INTO CONDUIT TAKE-OFF USING PVC SOLVENT CEMENT SUITABLE FOR NON-PRESSURE APPLICATIONS IMPORTANT SECURE NICHE TO REINFORCING BARS USING WIRE TIES (4 PLACES) NOTE REFER TO PAGES 8-10 FOR ALTERNATIVE INSTALLATION CONFIGURATIONS... - Page 9 HORIZONTAL CONDUIT INSTALLATION SECURE NICHE TO REINFORCING BARS USING WIRE TIES (4 PLACES) 20mm CONDUIT GLUED INTO CONDUIT TAKE-OFF USING APPROVED PVC SOLVENT CEMENT NOTE REFER TO PAGES 8-10 FOR ALTERNATIVE INSTALLATION CONFIGURATIONS...
- Page 10 NICHE & CONCRETE DETAILS 70mm (MAX) 50mm (MIN) 50mm (MIN) CONCRETE COVERAGE NOTE SCALLOP CONCRETE AROUND NICHE PERIMETER AND FILL WITH SEALANT NICHE PROTRUDING? 20mm NICHE CAN BE TRIMMED (MAX) A MAXIMUM OF 20mm IF IT PROTRUDES FORWARD OF FINISHED CONCRETE SURFACE...
- Page 11 INSTALL CABLE & PLUG INTO NICHE DRAW CABLE THROUGH CONDUIT REMOVE NICHE PROTECTIVE CAP CABLE NICHE + PLUG (INSTALLED ASSEMBLY IN WALL) NOTE: DO NOT REMOVE RED DUST COVER 2 METRES (MAX) FROM PLUG 700mm (MIN) (SEE STEP 9) TIGHTEN CABLE NUT BY HAND ONLY RUBBER GROMMET PLASTIC WASHER...
- Page 12 INSTALL MOUNTING RING INTO NICHE NOTE COIL PLUG & CABLE INSIDE NICHE ENSURE “TOP” IS POSITIONED CORRECTLY APPLY PVC SOLVENT CEMENT TO MOUNTING RING FIRMLY PUSH MOUNTING RING INTO NICHE NOTE ENSURE PROTECTIVE CAP REMAINS IN MOUNTING RING (UNTIL STEP 7)
- Page 13 APPLY POOL FINISH NOTE PROTECTIVE CAP MUST REMAIN IN MOUNTING RING DURING RENDERING / TILING POOL FINISH 22mm (MAX) 12mm (MIN) CABLE COILED WITHIN NICHE NOTE DO NOT TRIM FRONT EDGE OF MOUNTING RING...
- Page 14 REMOVE LOCKING RING REMOVE DUST CUP ROTATE ANTI-CLOCKWISE & RELEASE LOCKING RING REMOVE LOCKING RING HOLD DOWN BUTTON WITH FLAT-BLADE...
- Page 15 ASSEMBLE LOCKING RING TO MOUNTING RING REMOVE MOUNTING SCREWS FROM REAR OF LOCKING RING REMOVE PROTECTIVE CAP FROM MOUNTING RING PULL PLUG & CABLE THROUGH LOCKING RING ASSEMBLE LOCKING RING WITH MOUNTING RING USING MOUNTING SCREWS PROVIDED...
- Page 16 REMOVE PLUG DUST COVER REMOVE DUST COVER FROM PLUG USING PHILLIPS-HEAD (NO.2) SCREW-DRIVER NOTE ENSURE SEAL IS SEATED FLAT IN PLUG BASE NOTE DO NOT REMOVE RED DUST COVER UNDERWATER...
- Page 17 ASSEMBLE PLUG TO LIGHT ALIGN TERMINAL PINS AND FIRMLY ASSEMBLE PLUG TO LIGHT FASTEN PLUG TO LIGHT USING 3 x (M3.5 X 21mm) FASTENERS & NO.2 PHILLIPS-HEAD SCREWDRIVER IMPORTANT NOTES → DO NOT OVERTIGHTEN SCREWS → DO NOT USE POWER-TOOLS →...
-
Page 18: Light Assembly
LIGHT ASSEMBLY COIL CABLE INSIDE NICHE 2m (MAX) 700mm (MIN) INSERT LIGHT INTO LOCKING RING ROTATE 15° ANTI- CLOCKWISE FROM ‘TOP’ TO ALIGN WITH LOCKING MECHANISM ROTATE CLOCKWISE TO LOCK LIGHT IN PLACE... -
Page 19: Light Removal
LIGHT REMOVAL PUSH DOWN BUTTON WITH FLAT BLADE & HOLD ROTATE ANTI-CLOCKWISE & RELEASE FROM LOCKING RING... -
Page 20: Key Dimensions
KEY DIMENSIONS NICHE INSTALLED LIGHT POOL WALL 28.5mm... - Page 21 PAGE INTENTIONALLY LEFT BLANK...
- Page 22 PAGE INTENTIONALLY LEFT BLANK...
- Page 23 PAGE INTENTIONALLY LEFT BLANK...
- Page 24 NOTE PLEASE STORE THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE © COPYRIGHT 2024 SPA ELECTRICS PTY. LTD. ALL RIGHT RESERVED 2024 02 27...
