- Page 1 FIBREGLASS POOLS INSTALLATION & OWNER’S MANUAL...
-
Page 2: Table Of Contents
CONTENTS READ THIS FIRST TOOLS REQUIRED PRODUCT SUPPORT AND INFORMATION INCLUDED PARTS FINISHED INSTALLATION INSTALLATION PROCEDURE LIGHT REMOVAL LIGHT ASSEMBLY CONNECTIONS NOTICE HORIZONTAL MOUNT ONLY NOT INTENDED FOR OPERATION OUT OF WATER... -
Page 3: Read This First
• Temperature range for installation, operation and servicing: +5°C ~ +40°C (+41°F ~ +104°F) IMPORTANT NOTE It is recommended that the ATOM lighting range is operated using a Spa Electrics LV25-12 or LV50- 12 transformer. • DO NOT use electronic or switch-mode power supplies with ATOM lights. These power supplies will damage the light and void your product warranty. -
Page 4: Tools Required
TOOLS REQUIRED Hole Saw - Ø64mm Silicon & caulking gun Flat-blade screw driver (for light- Adjustable spanner (“Shifter”) head removal) IMPORTANT NOTES • The use of power tools for product ssembly is NOT recommended as these devices can cause faults and damage to light components. •... -
Page 5: Included Parts
INCLUDED PARTS NICHE & CABLE ASSEMBLY LIGHT ASSEMBLY CONICAL NUT CONICAL WASHER FLAT WASHER LV25-12 / LV50-12 DUAL / LV100Q-12 TRANSFORMERS (INCLUDED IN SINGLE / DUAL / TRI OR QUAD LIGHT KITS) -
Page 6: Finished Installation
FINISHED INSTALLATION FIBREGLASS FIBREGLASS CONDUIT POOL WALL NICHE TAKE-OFF FLAT CONICAL CONICAL EM LIGHT WASHER WASHER... -
Page 7: Installation Procedure
INSTALLATION PROCEDURE DRILL HOLE THROUGH POOL WALL * * MAY NOT BE REQUIRED IF PRE-PUNCHED / DRILLED HOLES AVAILABLE FOR LIGHT MOUNTING ESTIMATED WATERLINE Ø64mm 400mm (MAX) HOLESAW 300mm (MIN) BELOW ESTIMATED WATERLINE EASILY ACCESSIBLE FLAT SURFACE ORIENTATION OF NICHE “TOP” IMPORTANT POSITION “TOP”... - Page 8 ASSEMBLE WASHERS AND NUT ASSEMBLE COMPONENTS ON TO CABLE IN ORDER CONICAL CONICAL WASHER FLAT WASHER APPLY SILICONE APPLY NEUTRAL CURING SILICONE TO BOTH SIDES OF APPLY SMALL APPLY LARGE POOL WALL AMOUNT AMOUNT WARNING DO NOT USE ACID CURING APPLY SMALL APPLY LARGE SILICONES.
- Page 9 TIGHTEN NUT FIRMLY TIGHTEN BY HAND ONLY ADDITIONAL CHECKS REMOVE EXCESS SILICONE CHECK & TIGHTEN...
- Page 10 ATTACH CONDUIT (OPTIONAL) (OPTIONAL) 20mm CONDUIT...
-
Page 11: Light Removal
LIGHT REMOVAL HOLD DOWN RED BUTTON 20mm CONDUIT ROTATE LIGHT ANTI-CLOCKWISE ROTATE & RELEASE LIGHT FROM NICHE... -
Page 12: Light Assembly
LIGHT ASSEMBLY COIL CABLE ANTI-CLOCKWISE MINIMUM 700mm CABLE INSIDE NICHE COIL CABLE ANTI-CLOCKWISE INSERT LIGHT INTO NICHE INSERT LIGHT INTO NICHE POSITION ARROW TO ABOVE ANGLE... - Page 13 ROTATE LIGHT CLOCKWISE “CLICK” ASSEMBLED LIGHT...
-
Page 14: Connections
CONNECTIONS HOW TO CONNECT SINGLE LIGHT TO G.P.O. 25VA TRANSFORMER POOL LIGHT... - Page 15 HOW TO CONNECT MULTIPLE LIGHTS TO G.P.O. 50VA TRANSFORMER POOL LIGHT POOL LIGHT...
- Page 16 HOW TO CONNECT MULTIPLE LIGHTS TO G.P.O. CONTINUE DAISY-CHAIN UP TO 10A 50VA 25VA (MAX) TRANSFORMER TRANSFORMER POOL LIGHT POOL LIGHT POOL LIGHT...
- Page 17 PAGE INTENTIONALLY LEFT BLANK...
- Page 18 PAGE INTENTIONALLY LEFT BLANK...
- Page 19 PAGE INTENTIONALLY LEFT BLANK...
- Page 20 NOTE PLEASE STORE THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE © COPYRIGHT 2024 SPA ELECTRICS PTY. LTD. ALL RIGHT RESERVED 2024 02 15...
