Spa Electrics ARGON Winterization Instructions

TOOLS REQUIRED
• Flat-blade screw driver
1: PUSH AND LEVER OFF LIGHT RIM
WITH FLAT BLADE
INSERT FLAT BLADE SCREWDRIVER
INTO NICHE ABOVE TOP 12 O'CLOCK ARROW
AND LEVER OFF LIGHT RIM
2: ROTATE AND PULL OUT LIGHT ASSEMBLY
ROTATE LIGHT ASSEMBLY COUNTER-CLOCKWISE
SO THE ARROW ON THE LIGHT ASSEMBLY IS AT
10 O'CLOCK AND THEN PULL OUT THE LIGHT
ASSEMBLY FROM NICHE
3: REMOVE PLUG
FROM LIGHT
UNSCREW PLUG COLLAR
COUNTER-CLOCKWISE
UNTIL IT IS
FREE SPINNING
IMPORTANT NOTES
• Lights must be removed from pool wall and cable disconnected via plug connection & stored in a safe place.
• Winterization Cover must be fitted to Plug Top prior to reinstalling into niche for winter.
• Unless niche/conduit connection is adequately sealed (i.e. via included cable gland components),
pool water level must be drained down 12" below the lowest light(s) position in pool wall.
• All conduits should be checked for accumulated water and drained if required.
• Follow instructions OR consult your local pool professional for complete pool winterization process.
• All installation steps should be carried out with manual tools only. The use of power tools during installation is not
recommended as these devices can cause faults and damage to light components.
• Images are for illustrative purposes only. Appearances of parts and assemblies may vary from the illustrations.
PRODUCT SUPPORT & INFORMATION
For the most up to date installation information and contact information
for assistance in your region, please visit www.spaelectrics.com
COPYRIGHT 2020 SPA ELECTRICS PTY. LTD. ALL RIGHTS RESERVED US 20201116
WINTERIZATION
INSTRUCTIONS
LIGHT REMOVAL
4: DISCONNECT THE
TERMINALS
DISCONNECT LIGHT
ASSEMBLY FROM PLUG
BY PULLING APART
STORAGE
ENSURE LIGHT ASSEMBLY AND LIGHT RIM
IS SAFELY STORED FOR NEXT SEASON USE
