- Page 1 DYNASTY FIREPLACES Installation Guide for Dynasty Fireplaces Cascade Series (DY-BTX)
- Page 2 NEVER plug this heater into an outlet that is old, cracked, or has any loose wires or connections. Plugging this heater into a faulty outlet could result in electric arcing within the outlet that could cause the outlet to overheat or catch fire ©2022 Dynasty Fireplaces...
- Page 3 Cascade Series Installation Guide STEP 1 1. Create framing and opening according to the dimensions of your fireplace Framing Dimensions Model DY-BTX52 DY-BTX64 DY-BTX74 DY-BTX82 19 ½” 19 ½” 19 ½” 19 ½” 48 ¾” 60 ¾” 70 ¾” 78 ½” Depth 6”...
- Page 4 Cascade Series Installation Guide STEP 2 2. Finishing material can be applied around the opening prior to installation. NOTE: Ensure screws can be installed into the finishing material on the left and right of the opening...
- Page 5 Cascade Series Installation Guide STEP 3 3. Remove the magnetically attached front trim, and note the location of the side mounting brackets and opening for screws...
- Page 6 Cascade Series Installation Guide STEP 4 4. Insert the power cord and ensure fireplace has power. Place the fireplace in the opening and secure the left and right brackets onto the wall with screws.
- Page 7 Cascade Series Installation Guide STEP 5 5. Reinstall the magnetically attached front trim piece...
- Page 8 SUPPORT For more product information, maintenance guide, and contact information, visit: support.dynastyfireplaces.com Contact us: support@dynastyfireplaces.com ©2022 Dynasty Fireplaces...
- Page 9 THANK WWW.DYNASTYFIREPLACES.COM...
