#10-3071 No.5 Road, Richmond, BC V6X 2T4 Canada
Homeowner's
Installation Instructions &
Operating Manual
Model: DY-BTW40 - DY-BTW84
Dynasty Fireplaces
Advertisement
Table of Contents
Related Manuals for Dynasty Fireplaces DY-BTW40
Summary of Contents for Dynasty Fireplaces DY-BTW40
- Page 1 Homeowner’s Installation Instructions & Operating Manual Model: DY-BTW40 - DY-BTW84 READ AND SAVE THESE INSTRUCTIONS READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE.
-
Page 3: Table Of Contents
CONTENTS ………………………………………………………………………………….. CSA / Power Cord Labels ……………………………………………………………. Important Safety Information & Warnings…….. ……………………………………………………………………………………………....Preparation Packing List .……………………………………………………………………………………………. …………………………………………………………………………………………….. Product Dimension ……………………………………………………………………………………………………… Assembly ………………………………………………………………………………………… Battery Information ……………………………………………………………………………………………………….. Operation ………………………………………………………………………………………….. Control Panel ………………………………………………………………………………………. Remote Control ……………………………………………………………………………………… Care and Maintenance CSA / POWER CORD SAFETY LABELS CSA Rating Label Power Cord Warning Label IMPORTANT SAFETY INFORMATION! -
Page 4: Important Safety Information & Warnings
WARNING Read all instructions before using this heater! This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater, and keep them away from the sides and rear. - Page 5 WARNING: REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK---DO NOT USE THIS HEATER WITH ANY SOLID STATE SPEED CONTROL DEVICES. For residential use only! NOT for commercial use! Any commercial or public use of this heater voids all warranties, and could cause injury. ...
-
Page 6: Preparation
PREPARATION This carton includes GLASS! ALWAYS use extreme caution when handling glass. Failure to do so could result in personal injury or property damage. Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Parts and assembly steps are grouped for free-standing or wall-hanging use. -
Page 7: Product Dimension
PRODUCT DIMENSION Model 20 1/4″ 31 1/2″ 40 9/16″ 11 1/4″ 35″ 17 13/16″ 5 11/16″ EF172B(DY-BT40) (1030mm) (515mm) (800mm) (285mm) (888mm) (453mm) (145mm) 20 1/4″ 48 7/16″ 39 3/8″ 11 1/4″ 42 13/16″ 17 13/16″ 5 11/16″ EF173B(DY-BTW48) (1230mm) (515mm) (1000mm) (285mm) -
Page 8: Assembly
ASSEMBLY STEP 1. Find a safe location. Minimum clearance from the ceiling and the mantel must be at least 8 inches (200mm); minimum clearance from the front must be at least 3 feet (900 mm). Choose a location near an outlet so an extension cord is not required. DO NOT position the unit directly below a power outlet. - Page 9 Take out the two fixing brackets and 4pcs ST4X10 screws with 4 washers to fix on the left STEP 3. and right side panel of the unit. Make sure the distance from the fixing brackets to the fireplace surface is equal to D in order to make sure the firebox surface is not lower than the plasterboard surface.
- Page 10 Fix the 4pcs ST4X25 screws on the wood block. Make sure the front of the firebox is not STEP 5. lower than the surface of the wall. Carefully spread the small crystal stones across the fuel bed. Then evenly arrange the STEP 6.
- Page 11 STEP 7. Thread the ST3x8 screws (2) into the threaded holes on the glass panel. Check the alignment of the glass panel and securely tighten the screws.
-
Page 12: Battery Information
BATTERY INFORMATION Remote Control Battery This remote control uses two AAA batteries (included). Instructions for battery installation are inside the Remote Control battery compartment. Always replace the battery in the remote control with the same type of battery. NEVER dispose of batteries in fire. -
Page 13: Control Panel
CONTROL PANEL BUTTON FUNCTION ACTION & INDICATION ON: Turns on. 1. Press to turn the power on. OFF: Turns off. 2. Press to turn the power off. ON/OFF Controls the flame effect brightness. 1. Press once to turn the flame effect on. Cycles through levels... -
Page 14: Remote Control
Remote Control Aim the remote control at the remote receiver. Make sure you hear a beep NOTICE each time you press the button! If not, the fireplace will not respond to the signal. BUTTON FUNCTION ACTION & INDICATION ON: Turns on. 1. -
Page 15: Care And Maintenance
CARE AND MAINTENANCE ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in electric shock, fire, or personal injury. Cleaning NEVER immerse in water or spray with water. Doing so could result in electric shock, fire, or personal injury. - Page 16 Proof of purchase will be required so the original invoice should be retained. Dynasty Fireplaces #10-3071 No. 5 Road, Richmond, BC V6X 2T4 Canada Telephone: (604) 821-1009 Toll free: 1-877-521-1009...
