Instructions
Colour LED -
When the tip flashes
red and vibration is felt
it means that a live
voltage field has been
detected.
Bright LED torch.
Torch on / off -
Press to switch on.
Release to switch
off.
AC Voltage
sensing tip.
Pocket clip / Battery retaining clip -
Gently lift the clip and slide to the
rear to access the battery
compartment. The unit requires 2 x
AAA batteries. Always replace with
good quality alkaline batteries.
Specification
Operating Voltage Range
Operating Frequency Range
Temperature Range
Humidity
Safety Standard
Batteries
Dimensions (mm)
Weight (no batteries)
Socket & See
Century Road
High Carr Business Park
Newcastle under Lyme
Staffordshire UK
ST5 7UG
Tel: +44 (0) 1782 567096
Fax: +44 (0) 1782 567095
Email: sales@socketandsee.co.uk
Website: www.socketandsee.co.uk
50 - 1000 VAC
50 - 60 Hz
-10°C to 50°C
80% max
Instruction Manual & Specification
BSEN 61010
2 x AAA
150 x 26 x 20
28 g
Issue1 01/19
VVD PRO
Vibrating Non Contact
AC Voltage Detector
SnS044
