Summary of Contents for Socket & See VIP 100
- Page 1 VIP 100/150 Two Pole Voltage Testers Instruction Manual & Specification VIP 100 VIP 150 SS0010V2...
- Page 2 The VIP 100 and VIP 150 are designed to be used by skilled persons in accordance with safe methods of work. If the VIP 100 or VIP 150 are used in a manner not specified by Socket and See, the protection provided by them may be impaired.
- Page 3 The VIP 100 and VIP 150 should not be used on voltages over 600V. 2. Description The VIP 100 and VIP 150 are simple to use two pole voltage testers capable of measuring AC and DC voltages. They incorporate a number of features that make it safer and easier to use than many other two pole testers on the market.
-
Page 4: Maintenance And Service
When using the VIP 100 or VIP150 ensure that fingers are behind the finger guards. The tester is suitable for use with or without PPE. Check the correct function of VIP 100 or VIP 150 before and after use with a true AC output proving unit such as the Socket and See SP400. - Page 5 SS0010V2 Specification Operating Voltage Range 12 - 400V AC / DC 6 - 12 - 50 - 110 - 230 - 400V (VIP150) LED Indication 230 - 400V (VIP100) Cat IV 600V Overvoltage Category Operating Current <3.5 mA Operating Duty Cycle 30s on, 240s off Operating Conditions -10 to +55ºC at 70% RH...
- Page 6 SS0010V2 Ordering Information Item Supplier Code Socket and See VIP 100 SOC/VIP100 Socket and See VIP 150 SOC/VIP150 Socket and See SP200 Proving unit SOC/SP200 Socket and See SP400 Proving Unit SOC/SP400 with non contact voltage check Socket and See MCB locking off...
