Würth SP1 Quick Start Manual

Foam Gun SP1

For intensive foam cleaning of surfaces and
parts.
Non-runny, firm foam.
• Great cleaning power.
• Loosens stubborn dirt reliably and quickly.
Highly effective.
• Efficient use thanks to visible application of the cleaning
agent.
• Optimum foam yield.
Environmentally-friendly.
Minimal waste water contamination thanks to conservative
use of the cleaning agent.
Easy to use.
Ready for use in a short amount of time.
Two diffusers.
Can be used over small or large areas.

Details/Application

Cars, trucks, buses, construction machines, land and forestry, vehicle preparation, building facade cleaning, equipment mainte-
nance and much more.

Instructions

##keep##
##keep##
• Remove loose dirt from the surface to be treated.
• Fill the supply tank of the SP1 Foam Gun with cleaning agent according to the mixing specifications from the manufacturer.
• Screw on the appropriate diffuser, depending on the application.
• Connect the compressed air.
• Rotate the green lever to the vertical position to open access to the cleaning agent.
• Cover the object in foam, allow the cleaner to work in (but not dry) and then clean thoroughly with water.

Notice

• Do not use cleaning agents that contain acids, bases and/or are easily flammable.
• We recommend using BMF Cleaner or Absobon Engine Wash. A constant air pressure of 6 – 8 bar is required for optimum
output utilization.
Adolf Würth GmbH & Co. KG, 74650 Künzelsau
