BleBox shutterbox DIN User Manual page 3

Attention! If the controller does not have a stable connection to the WiFi
network ("WiFi client status": "Connected", without any error warnings),
restarting the access point will not be possible - in this situation, the only
solution is to reset the controller to the factory settings. Disabling the
access point is recommended only after the complete driver configuration
and making sure that the entire system is working properly.
4
Go to the device settings (the "Settings" icon in the top right corner of the
screen). In the "Name and icon" section you can change the name of the
device under which it is displayed in the wBox application.
5 TIME AND LOCATION OF THE DEVICE
Go to settings, to the "Time and location" section. In the "Device time" tab,
select your region and location from the list, confirming the changes with the
"Save" button. The device will synchronize its time with the NTP time server
(if the controller is in a WiFi network with Internet access) or will download
the time from the phone / tablet. Since the controller does not have a clock
backup battery, the clock resets itself when the power is disconnected.
Hence, it is recommended that the controller is always connected to a WiFi
network with internet access so that it can automatically synchronize its
clock. This is especially important in controllers that have the function of
working with the schedule.
You can specify the location of the controller using your smartphone or tablet.
In the "Device location" tab click the "Set location" button. The application
will ask whether to share the location - allow. The approximate coordinates
of your location should appear in the "Coordinates" box. If the "Set location"
button flashes red with "Error" or the "Coordinates" field has not changed the
value from "Not set" to numerical data there has been a failure in retrieving
the location. You should then make sure that the phone / tablet has a GPS
module and that the wBox application has access rights to download the
location in the phone settings. Setting the location is especially important in
controllers that have the function of working with the schedule, in which the
schedule is based on sunrise and sunset.
TECHNICAL SPECIFICATIONS
supply voltage
controller energy consumption
number of outputs
type of outputs
maximum load
maximum power
number of inputs
inputs type
supported switches
number of buttons
buttons type
status signaling
housing type
dimensions
protection level
housing
mounting method
communication standard
radio frequency
DEVICE SETTINGS
230V AC
< 1W
2
relay, short-circuited to L, configurable:
independent or push-pull
per output: 5A
per output: AC1 (resistive, cosφ>
0.95): 5A @ 230V AC = 1150W AC3
(IEC60947-4-1): ~ 0.15kW @ 240V AC
(motor)
2
optoisolated, logical, configurable,
12-230V AC / DC
monostable (push-button),
bistable (traditional, cross switch),
not-illuminated
1
tact-switch, on / off function
backlight
installation module DIN-1, width
17.5mm
90(98,8) x 17,5 x 64,5mm
IP20 according to PN-EN 60529
ABS / acrylic, flammability class V-0
according to UL 94
direct mounting on a 35mm DIN rail
according to PN-EN 60715
μWiFi, compatible with WiFi, 802.11g
2.4 GHz
supply voltage
transmission type
API
mode
compatible devices and systems
controller operating temperature
ADDITIONAL INFORMATION
SCHEDULE
The controller has the ability to work according to a given schedule.
Adding schedule entries can be performed by clicking the "Add item" button in
the "Schedule" section of settings. You can select the days in which the task will
be performed, the type of entry (at a specific time, or relative to sunrise / sunset
- only having a correctly set location) and set the parameters of the task. The set
tasks will be visible as a list, individual entries can be edited, deleted or temporary
disabled.
SOFTWARE UPDATE
In order to update the software in the controller it must be connected to the
home WiFi network (see "WiFi connection settings" section) which is connected
to the Internet. Go to settings, to the "Details, update and help" section and click
the "Check for update" button. If an update is available the button changes to
"Download new software". After clicking it, wait about 1 minute without closing
the interface or taking any other actions. The device will download the latest
software and then reboot. You can read the device ID, hardware and software
versions in the device details.
HELP
The latest versions of the
materials about products are available
General questions: info@blebox.eu. Service and technical support: support@
blebox.eu
Before contacting our service, if it is possible, prepare the "Service key" of the
given controller available in its settings, in the "Details, update and help" tab. By
clicking the icon, the key will be copied to the phone's clipboard. Prepare also the
"Installation key" of the wBox application, available in the main application menu,
in the "Settings" tab.
Factory reset manual is available at: blebox.eu/start/reset
Attention! Factory reset does not remove the controller from the user account
assigned to it. The device must be independently removed from the account
- select "Manage devices" from the main menu of the wBox application, then
select the device and click the "Remove device" button. Alternatively, you can log
into the portal.blebox.eu system, go to the "Devices" tab, choose the device and
select "Remove device" from the top-right "Actions" menu.
for more information visit our website
www.blebox.eu
or send us an email to: info@blebox.eu
support is available at support@blebox.eu
made in Europe
230V AC
two-way, encrypted
open
direct connection (as an Access Point),
WiFi connection via a standard router,
connection with access from anywhere
in the world (only Internet access
required)
Apple iPhone, Apple iPad, iPad Mini,
Android, computers and mobile devices
supporting HTML5
from -20°C to +50°C
manual, additional informations
on our website: blebox.eu
