Page 1 Operating manual Disc mower NOVACAT 352 ED/RCB/CF 3784 Machine No.: +..00291 3784.en-GB.80W.0...
Page 2 And if we don't have what you're looking for, then your Specialist Service Centre is there for you with help and advice. Scan the QR code on the type plate of the machine or visit http://www.mypoettinger.com Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 3 The operating instructions are part of the machine, therefore pass them on to any new owner when passing on the machine. Instruct the new owner and make them aware of the regula- tions mentioned. Your PÖTTINGER service team wishes you every success. Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 4 Text sections marked in this way contain advice on the subject of environmental protection. Directions Directions (such as left, right, front, rear) are given based on the normal "working travel direc- tion" of the machine. Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 5 Use of symbols Illustrations may contain additional symbols, arrows and other lines that serve to improve the comprehensibility of the image content or are intended to draw attention to a specific area of the image. Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 6 TINGER. If you have not received this mail, please contact your local dealer. Your dealer can fill in the handover declaration online. Austria PÖTTINGER Landtechnik GmbH Industriegelände 1 4710 Grieskirchen Phone+43 7248 600-0 Fax+43 7248 600-2513 info@poettinger.at Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 7 Amendment index Date Index Amendment reason Amended chapter Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 8: Table Of Contents
EU - declaration of conformity................... Intended use........................Non-intended useage......................Technical data Dimensions........................Weights..........................Mower discs and cutter blades..................Power requirements......................Hydraulics......................... Electrics..........................Noise emission........................Control terminal operation Comfort control........................Safety and the environment Safety advice........................Qualification of personnel....................Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 9 Assemble / adjust lower link bolts................Adjustment of the cardan shaft..................Check PTO drive....................... Conical disc assembly recommendation..............Rear power lift height....................Hydraulic relief setting....................Remove / reposition conveyor cones................Conditioner (option)..................... Setting the roller conditioner (optional)................Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 10 Replace / refit reversible cutter blades................ 126 Replace conditioner drive V-belt.................. 129 Replace roller conditioner drive V-belt................. 132 Tine conditioner, tines and tine fastening assembly work........... 134 Replace toothed belt conditioning roller..............139 Replace crossflow drive V-belt..................140 10 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 11 Check / fill cutter bar oil level.................... 175 Check / refill mower input gear oil level................177 Every 4 years....................... 178 Check and adjust hydraulic pressure accumulator............178 Every 6 years....................... 179 Hydraulic hoses......................... 179 Operating manual NOVACAT 352 ED/RCB/CF | 11 3784.en-GB.80W.0...
Page 12 Vibrations with tine conditioner during mowing operation........... 190 Plans Electric..........................191 Hydraulics......................... 191 Supplement to USA / CANADA operating instructions Warning signs, GB / USA / CANADA................192 Secure load towing......................204 12 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 13: Crane Loading
Attachment points for lifting gear The hitching points are marked with the following sticker. Implementation ► Carefully attach and secure sufficiently sized, undamaged lifting gear to the marked hitching points. Stop points Operating manual NOVACAT 352 ED/RCB/CF | 13 3784.en-GB.80W.0...
Page 14: Factory Standard Tightening Torque
41000 M 12 x 1.25 44500 63000 M 14 x 1.5 60000 85000 M 16 x 1.5 81000 115000 M 20 x 1.5 134000 189000 M 24 x 2 188000 1090 265000 14 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 15: Layout And Function
High cut skids Can be retrofitted underneath the cutter bar for in- illustra- creased cutting heights. tion Elements marked as "left" or "right" are present on both sides of the machine. Operating manual NOVACAT 352 ED/RCB/CF | 15 3784.en-GB.80W.0...
Page 16: Accessories Included In The Scope Of Delivery
1 = Operational instructions, spare parts list and transfer declaration. 2 = knife wrench 3 = Blade box Upgrade program The PÖTTINGER Landtechnik GmbH upgrade program offers many upgrade possibilities. You can receive additional information from your service dealer. 16 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 17: At A Glance
The following data is displayed on the identification plate for each machine type and design. Data Data Chassis number Year of mfr. Model Model year Vehicle identification number Axle load per axle Type Bearing load Serial number Permissible total weight Basic weight Operating manual NOVACAT 352 ED/RCB/CF | 17 3784.en-GB.80W.0...
Page 18: Description
PÖTTINGER Landtechnik GmbH Industriegelände 1 AT - 4710 Grieskirchen Machine (interchangeable equipment): mower NOVACAT 352 ED RCB CF Type 3784 Serial no. This declaration of conformity is issued under the sole responsibility of the manufacturer. The object of the declaration described above is in conformity with the relevant Union...
Page 19: Intended Use
Transporting persons or animals on the machine. • Immersion in liquids during transport, operation or storage of the machine. • Working of roads, stony ground and other surfaces consisting essentially or partially of stone, sand or asphalt. Operating manual NOVACAT 352 ED/RCB/CF | 19 3784.en-GB.80W.0...
Page 20: Technical Data
Technical data Dimensions Designation NOVACAT 352 ED / RC /CF Type 3784 3-point coupling Cat. III / Width 3 Working width 3.46 m Transport width < 3.00 m Area output 3.7 ha/t Weights Designation NOVACAT 352 ED / RC /CF...
Page 21: Power Requirements
Hydraulic oil Hydraulic oil specification DIN 51524 Part 1 and 2 Oil temperature Max. 80 °C Operating pressure 170 to max. 200 bar Oil supply volume minimum 80 l/min with 200 bars Operating manual NOVACAT 352 ED/RCB/CF | 21 3784.en-GB.80W.0...
Page 22: Electrics
Continuous sound pressure level dB(A) 77.8 The actual noise level in the workplace may differ from the measured continuous sound lev- el depending on the different tractor designs. We recommend wearing hearing protection during the work! 22 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 23: Control Terminal Operation
Releasing the button interrupts the process. (1) switch to the right and activate tractor control de- Lower link arm operation vice (1) switch to the left and activate tractor control de- Hydraulic tailgate cross- vice flow operation Operating manual NOVACAT 352 ED/RCB/CF | 23 3784.en-GB.80W.0...
Page 24: Safety And The Environment
For example,sSuch obligations may concern the wearing of personal protective equipment or the road traffic regula- tions. 24 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 25: Maintaining Operational Safety
Maintenance work, as described in this manual, must be fully carried out at the given time intervals or have them completed in a specialist workshop. • Do not make any software alterations to the programmable control system. Operating manual NOVACAT 352 ED/RCB/CF | 25 3784.en-GB.80W.0...
Page 26: Special Hazards
► Look for leaks using only appropriate equipment (for example, special spray for identify- ing leaks). Have any defects remedied immediately in a specialist workshop. ► Never seal off leaks using your hands or other body parts. ► Should injuries occur, contact a doctor immediately. 26 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 27: Operational Danger Area
► Check that protective devices are complete and ready for operation before start-up. ► Before commissioning and during operation, direct persons away from the danger zone in and around the machine. Marking = danger area of the machine Operating manual NOVACAT 352 ED/RCB/CF | 27 3784.en-GB.80W.0...
Page 28: Warning Signs
French! See also "Supplement to the Operating Instructions USA / CANADA". Roller conditioner Pos. Warning signs Meaning Clean toothed belt-drive every 100 ha. Danger from flying objects when the engine is running. Keep a safe distance. 28 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 29 Pos. Warning signs Meaning Correct belt tension! (see Operating Instruc- tions!) Beater bar position Do not touch rotating machine components. Wait until they have stopped completely. On both sides of the machine. Operating manual NOVACAT 352 ED/RCB/CF | 29 3784.en-GB.80W.0...
Page 30 Danger from flying objects when the engine is running. Keep a safe distance. Do not touch rotating machine components. Wait until they have stopped completely. 30 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 31 Safety and the environment Pos. Warning signs Meaning Check belt tension! (see Operating Instruc- tions) Do not touch rotating machine components. Wait until they have stopped completely. CF Standard Front view Operating manual NOVACAT 352 ED/RCB/CF | 31 3784.en-GB.80W.0...
Page 32 Switch off tractor engine and remove igni- tion key prior to all maintenance or repair work. Danger of hands being crushed. Never reach into the crushing danger area as long as parts are able to move there. 32 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 33 9 / 10 / Danger of hands being crushed. Never reach into the crushing danger area as long as parts are able to move there. Operating manual NOVACAT 352 ED/RCB/CF | 33 3784.en-GB.80W.0...
Page 34 See Operating Instructions of cardan shaft manufacturer for trimming! 2 / 3 / Danger of hands being crushed. Never reach into the crushing danger area as long as parts are able to move there. 34 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 35 Switch off tractor engine and remove igni- tion key prior to all maintenance or repair work. Danger of hands being crushed. Never reach into the crushing danger area as long as parts are able to move there. Operating manual NOVACAT 352 ED/RCB/CF | 35 3784.en-GB.80W.0...
Page 36 The required filling pressure is indicated on a sticker on the pressure reservoir. Danger of hands being crushed. 10 / Never reach into the crushing danger area as long as parts are able to move there. 36 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 37: Traffic Safety Equipment
For machines which are operated in the USA / CANADA, a "Flasher Control Module" (to adapt the blinking frequency of the direction indicators to the current applicable regulations) is available from PÖTTINGER! Lighting standard Operating manual NOVACAT 352 ED/RCB/CF | 37 3784.en-GB.80W.0...
Page 38 2 / 3 Orange reflector Orange reflectors on both sides of the machine Orange reflector NOVACAT 352 ED USA CANADA lighting 1 = yellow LED indicators 2 = red LED red lights 3 = red reflective film 4 = SMV-Emblem...
Page 39 2 = yellow LED indicators 3 = red LED red lights 4 = yellow LED indicators 5 = red reflective film 6 = SMV-Emblem NOVACAT 352 CF USA CANADA lighting 7 = red reflective film Operating manual NOVACAT 352 ED/RCB/CF | 39 3784.en-GB.80W.0...
Page 40 NOVACAT 352 RCB USA CANADA side warning sign 1 / 2 = 4x warning signs on both sides of the machine NOVACAT 352 ED USA CANADA side warning sign 1 / 2 = 4x warning signs on both sides of the machine...
Page 41: Safety Flap Operation
Move the safety flap to its park position before attaching the machine to the tractor: ▷ Activate the handle and move the flap downwards as far as it will go. The flap is then held in position with the spring-loaded lever. Operating manual NOVACAT 352 ED/RCB/CF | 41 3784.en-GB.80W.0...
Page 42: Handling Hazardous Substances
Carry out the procedure in the same way on both sides of the machine for machines with 2 mower units. Handling hazardous substances In addition to the information in these Instructions, the generally applicable, statutory or oth- erwise binding regulations on environmental protection are to be observed. 42 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 43: Fuel Efficiency And Soil Protection
Safety and the environment Fuel efficiency and soil protection Careful adjustment of the machine preserves machine/soil and saves fuel. Operating manual NOVACAT 352 ED/RCB/CF | 43 3784.en-GB.80W.0...
Page 44: Disposal Of The Machine
Remove lubricants such as gear oil, hydraulic oil, etc. from components before they are scrapped. Disposal of rubber parts / tyres • Take tyres with and without rims and other rubber components to the corresponding re- cycling point. 44 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 45: Valves / Cover / Auxiliary Equipment
Unlock and open tailgate Implementation ► Remove linch pin (5). ► Swing operating lever (4) to the side and press upwards as shown. This causes the lock hooks underneath the tailgate to swing out. Operating manual NOVACAT 352 ED/RCB/CF | 45 3784.en-GB.80W.0...
Page 46 Swivel operating lever (4) to the right until the lock button (6) clicks into place. ► Remove operating lever and swivel flap upwards slightly with the handle (H) with one hand. The flap can now be swiveled freely. 46 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 47 The flap is left in this position during operation when mowing is to take place without the formation of swaths. In this case, the operating lever is returned to its transport position and secured with the linch pin as shown. Operating manual NOVACAT 352 ED/RCB/CF | 47 3784.en-GB.80W.0...
Page 48 Remove operating lever and insert sideways in its transport position so that the lock hooks can be closed. Do not insert linch pin yet! ► Close the tailgate completely and press the operating lever downwards to close the lock- ing lever completely. 48 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 49: Manual Operation Of Side Protection Apron Carrier
► Make sure that all the lock hooks and locking bolts are closed properly before operating the machine. Manual operation of side protection apron carrier Not with hydraulic side protection! Operating manual NOVACAT 352 ED/RCB/CF | 49 3784.en-GB.80W.0...
Page 50 All rotating machine parts are stationary. Implementation ► Insert screwdriver in the hole in the spring-loaded bolt (3), pull the bolt to the side until the side protection is unlocked and hold in position. 50 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 51: Operation Of Front Protection Apron Carrier
Make sure that the protection has locked in properly, twisting the clamping piece if nec- essary. ► Carry out process in reverse order to fold down side protection. Operation of front protection apron carrier Operating manual NOVACAT 352 ED/RCB/CF | 51 3784.en-GB.80W.0...
Page 52 Make sure that the safeguard engages correctly. Close front protection Implementation ► Hold front protection, pull spring-loaded locking bolts out as far as they will go and hold in this position. Protective cover masked 52 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 53: Operation Of Support Stands
Standard 1 = front support stand in working position 2 = rear support stand in working position (only used with machines without ballast). Operating manual NOVACAT 352 ED/RCB/CF | 53 3784.en-GB.80W.0...
Page 54 Remove spring-loaded bolts (4) and adjust support stand downwards with the handle (3). ► Release the bolt in the lowest position and slide the support stand further until the spring-loaded bolt in the next hole in the support stand visibly and audible engages. 54 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 55 Pivot the support stand downwards so that the pin can engage in the lower hole. ► Push support stand forwards and replace the linch pin (V). The linch pin can only be fitted when the pin has engaged properly. Operating manual NOVACAT 352 ED/RCB/CF | 55 3784.en-GB.80W.0...
Page 56 ▷ Make sure that the support stand (3) is locked at the same height as the front sup- port stand (1). View from the front. 56 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 57: Conditioner Support Leg
Remove the spring-loaded bolt (2) with the other hand and hold in position to unlock the support stand. ► Move the support stand downwards until the bolt (2) can no longer lock into place. Operating manual NOVACAT 352 ED/RCB/CF | 57 3784.en-GB.80W.0...
Page 58 If the position is not low enough, repeat the process from point 1 and move the sup- port stand into the next lowest position. ► Retract the support stand Carry out process in the reverse order. 58 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 59: Operation
Ensure that spare parts, machine components or operating terminals packed in the ma- chine (e.g. in seed hoppers, in loading spaces, under protective covers) and on the ma- chine have been removed. Operating manual NOVACAT 352 ED/RCB/CF | 59 3784.en-GB.80W.0...
Page 60: Coupling
Danger of crushing the whole body when activating the power lift! ► Direct people from the risk area around the power lift. ► Do not stand between the tractor and the power lift when operating the power lift via external buttons. 60 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 61: Mounting On Tractor
Tractor control devices set in float position. 3-point coupling Implementation Set rear power lift to position control. Drive the tractor up to just in front of the machine, stop, apply parking brake. Operating manual NOVACAT 352 ED/RCB/CF | 61 3784.en-GB.80W.0...
Page 62 Damage may be caused due to excess pressure in the hydraulic unit in the machine if the tractor engine / hydraulic pressure supply are not switched off. ► Turn off tractor engine / hydraulic pressure supply and switch off ignition before coupling! 62 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 63 13 Set rear power lift height adjustment, cutting height and release as required if machine is to be operated afterwards. See "Rear power lift height" on page 75.See "Hydraulic re- lief setting" on page 77. Operating manual NOVACAT 352 ED/RCB/CF | 63 3784.en-GB.80W.0...
Page 64: Tractor Ballast
The calculation method gives only the mathematical results using the weights in the ma- chine and tractor technical data at the moment of delivery. These figures may differ from the actual weight due to subsequent technical changes. 64 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 65 </= kg (G Total weight perm kg (T kg (T Front axle load </= kg V act V perm kg (T </= kg (T Rear axle load </= kg H act H perm Operating manual NOVACAT 352 ED/RCB/CF | 65 3784.en-GB.80W.0...
Page 66: Determine The Required Tractor Ballast Weights Using The Weighing Method
See the tractor operational instructions. Weigh the total weight ► Drive the tractor together with the machine in transport position and the ballast weights with the front and rear axle on the scales. 66 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 67 ) taking the tyre bearing capacity into account. See the tractor opera- H perm tional instructions. ► Verify if the technical data of the tyres and rims correspond to the tractor manufacturer requirements. See the tractor operational instructions. Operating manual NOVACAT 352 ED/RCB/CF | 67 3784.en-GB.80W.0...
Page 68: Determine The Required Tractor Ballast Weights Using Calculation
H act V act ..............................► Enter the value for the permissible rear axle load (T ) according to the tractor operat- H perm ing instructions in the table of values. 68 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 69 Operation ► Double the permitted tyre load capacity according to the tractor operational instructions or the documentation of the tyre manufacturer (two tyres per axle) and enter in the value table. Operating manual NOVACAT 352 ED/RCB/CF | 69 3784.en-GB.80W.0...
Page 70: Adjustment / Retrofitting
Assemble / adjust lower link bolts Assemble lower link bolts on support frame according to the three-point category and adjust lower link width with the safety screw as shown below. 70 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 71 Continue process from next step if the bolt cannot be moved or turned. ► Carry out procedure similarly on both sides of the machine. ► Attach and secure lower link balls as required. Operating manual NOVACAT 352 ED/RCB/CF | 71 3784.en-GB.80W.0...
Page 72: Adjustment Of The Cardan Shaft
If necessary, have the cardan shaft shortened by an authorized service specialist. Check the permissible cardan shaft angulation. Refer to the cardan shaft's operating manual. The clearance around the cardan shaft must be sufficient, otherwise it will be damaged. 72 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 73 40 mm from the edge of the inner guard tube to the outer guard tube. ► Remove the cardan shaft parts. ► Shorten the exterior protective tube at the marked point. ► Shorten the inner protective tube to the same length as the external protective tube. Operating manual NOVACAT 352 ED/RCB/CF | 73 3784.en-GB.80W.0...
Page 74: Check Pto Drive
The conical discs are already fitted in the positions stated in the factory in the case of some cutter bars. Other conical disc positions are possible and may be disassembled depending on fodder availability / composition. (The cover disc must be replaced in all cases) 74 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 75: Rear Power Lift Height
► Direct persons out of the danger area around the machine before moving the machine. WARNING Simultaneous operation of machine and tractor by several people! ► Clearly define the areas of responsibility of present assistants and discuss work proce- dures. Operating manual NOVACAT 352 ED/RCB/CF | 75 3784.en-GB.80W.0...
Page 76 Mower unit and top link hidden! Raise / lower the machine using rear power lift until the distance shown above (depend- ing on hitch-up method) between the ground and the center of the positioning pin is reached. 76 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 77: Hydraulic Relief Setting
Height adjustments are not generally necessary during normal operation. Hydraulic relief setting Correct relief setting reduces wear and allows for clean mowing. Operating manual NOVACAT 352 ED/RCB/CF | 77 3784.en-GB.80W.0...
Page 78 The driving speed should be reduced at the same time to prevent the mower unit from jumping at higher driving speeds (due to reduced adaptation to terrain). 78 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 79 75 kg. ▷ If the recorded weight does not correspond to the factory setting or the current re- quirement, repeat the procedure from step 3. Operating manual NOVACAT 352 ED/RCB/CF | 79 3784.en-GB.80W.0...
Page 80: Remove / Reposition Conveyor Cones
• 2x covers supplied and 2x screws M10x30 Verbus Ripp 10.9 supplied for fitting the cov- ers if required. • The machine is standing on even, load-bearing ground in the working position. 80 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 81: Conditioner (Option)
Conditioning is achieved by means of 2 parallel, interlocking, flexibly mounted rubber rollers. Conditioning intensity is adjusted by means of the spring tension of the upper roller. The fol- lowing settings may be used for optimum adjustment to existing conditions. Operating manual NOVACAT 352 ED/RCB/CF | 81 3784.en-GB.80W.0...
Page 82 Because of component tolerances, an uneven roller gap can occur despite basic setting. Check gap on both sides and readjust on one side if necessary. 82 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 83 (1). ► Carry out procedure similarly on both sides of the machine. Setting the swath width The swath boards shape the cut and conditioned fodder to the desired swath width. Operating manual NOVACAT 352 ED/RCB/CF | 83 3784.en-GB.80W.0...
Page 84 Mount guide plates ▷ Attach guide plates to brackets (L) ▷ Guide plates that are not needed can be stored in the parking position (2, 3) at the top of the hood. 84 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 85 Set the hood at the desired angle. ▷ Tighten the adjusting screw (1). ▷ Carry out procedure similarly on both sides of the machine. ▷ Carry out the procedure similarly on the second roller conditioner if applicable. Operating manual NOVACAT 352 ED/RCB/CF | 85 3784.en-GB.80W.0...
Page 86: Tine Conditioner Settings
Adjust conditioning intensity 1 = 4-level adjustment lever for conditioning intensity 2 = adjustment lever for swath boards (swath width) 3 = conditioner tines 4 = Belt tensioner drive 86 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 87 The angle of the impact plate can be adjusted for the desired throw distance for cuttings: The most appropriate setting is determined during operation. Implementation ► Loosen ring nut (1) on both sides, adjust impact plate to inclined position and tighten ring nuts again. Operating manual NOVACAT 352 ED/RCB/CF | 87 3784.en-GB.80W.0...
Page 88 Individually adjustable guiding plates (3) on deflector plate support required swath shape. The most appropriate setting is determined during operation. Implementation ► Adjust wide spread placement: Swing swath discs (2) completely out 88 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 89 Adjust guide plates (4) as shown. ► Carry out procedure similarly on both sides of the machine. ► Adjust swath deposit: Pivot swath plates (2) inwards depending on required swath width. 2 = toggle nut Operating manual NOVACAT 352 ED/RCB/CF | 89 3784.en-GB.80W.0...
Page 90: Mowing Without Conditioner
NOVACAT 302 CF). The pre-assembled conditioner may be dismantled if required and replaced with another conditioner or a swath former. Swath former operation (option) is only possible without a conditioner (option) and only if the rear protection (option) is used. 90 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 91 Repeat procedure correspondingly on both sides of the machine. Open protection. Loosen the belt tension using the blade wrench (1) and remove the belt (2) on the condi- tioner belt pulley. Operating manual NOVACAT 352 ED/RCB/CF | 91 3784.en-GB.80W.0...
Page 92 Push chassis (5) into the bracket on both sides as far as the end stop. Remove retaining bolt and set aside for use on the rear protection or if the conditioner is to be re-assembled at a later stage. 92 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 93 Push lubricant line connection out from mower unit. Remove conditioner at the rear, place on a level, weight-bearing surface and secure against rolling using wheel chocks. The chassis is not suitable for manouvering the conditioner on unpaved surfaces! Operating manual NOVACAT 352 ED/RCB/CF | 93 3784.en-GB.80W.0...
Page 94 These safeguards are not included in the scope of delivery for a new machine with conditioner. The parts must be or- dered additionally (see spare parts list, component: "REAR PROTECTION“). Fit rear protection 94 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 95: Fit Conditioner / Swath Former
7 = optional retaining bolts with spring-assisted quick closure Remove chassis. ▷ Raise the arms slightly if necessary and relieve the chassis so that it can be re- moved. ▷ Then return the arms to working position. Operating manual NOVACAT 352 ED/RCB/CF | 95 3784.en-GB.80W.0...
Page 96 Make sure that the belts (2) run properly in both belt pulleys. Push the lubricating line connection into the mower unit when using roller conditioners. ▷ Connect roller conditioner lubricant line. The lubricant line is only connected in roller conditioners! 96 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 97: Swath Former (Option)
Machine is fully attached and properly secured to a suitable tractor. • Park tractor and machine on level and stable ground in working position and secure against rolling. • Cutting height correctly set Operating manual NOVACAT 352 ED/RCB/CF | 97 3784.en-GB.80W.0...
Page 98 15 - 20 mm away from the guide plate. ► Carry out procedure similarly on both sides of the machine. Set spring tension of additional swath discs Determine optimum setting during operation. 98 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 99: Crossflow Swath Apron Setting
(reduced counter-pressure in the spring). ► Carry out procedure similarly on both sides of the machine. CROSSFLOW swath apron setting The most appropriate setting is determined during operation. Operating manual NOVACAT 352 ED/RCB/CF | 99 3784.en-GB.80W.0...
Page 100 Loosen eyebolts (1), move swath apron as required and tighten eyebolts again. ► Check setting and correct if necessary. Adjust swath apron hydraulics lifting speed The lifting speed can be adjusted with the adjustable throttle valve (2). 100 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 101: Cross Flow (Option)
To release the powertrain of the machine, the wiping strip (B) can be removed with lengthy fodder and increased power requirements. Screw conveyor hidden! A = upper wiping strip B = lower wiping strip Operating manual NOVACAT 352 ED/RCB/CF | 101 3784.en-GB.80W.0...
Page 102 There should only be a minimal gap (maximum 1 mm) between the wiping strips and the conveyor! Implementation Loosen the fixing screws (1-6) in the slots on the inside of the cover so that the wiping strip is still movable. 102 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 103 If the conveyor does not rub against the scraper, continue with the next point. 11 Check distance between scraper and conveyor. ▷ If the distance is more than 1 mm from the conveyor, repeat the process from point Operating manual NOVACAT 352 ED/RCB/CF | 103 3784.en-GB.80W.0...
Page 104 A = upper wiping strip B = lower wiping strip ► Open tailgate and lock in open position. ► Loosen 3 nuts on threaded pieces (1) of wiping strip. ► Remove 6 screws (2) 104 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 105 Attach wiping strip to upper side of CROSSFLOW using previously removed screws as shown below. Attach and tighten surplus screws and nuts on the wiping strip. Right side of machine Left side of machine Operating manual NOVACAT 352 ED/RCB/CF | 105 3784.en-GB.80W.0...
Page 106 Reset distance between wiping strip and conveyor, see also "adjusting tailgate wip- ing strip". The process should be carried out in the same way on each CROSSFLOW unit in machines fitted with two CROSSFLOW units. 106 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 107: Work Assignment
► Stop the PTO shaft and wait for the drive to come to a standstill before raising the ma- chine. NOTICE Damage due to driving over obstacles! ► Drive carefully. ► Remove known obstacles if possible before starting work. Operating manual NOVACAT 352 ED/RCB/CF | 107 3784.en-GB.80W.0...
Page 108: Turning Manoeuvres On Slopes
The swath apron is raised or lowered to the correct position at the same time as the mowing unit during mowing. The swath apron can be deactivated if the mowing unit is not required during mowing. 108 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 109 Park tractor and machine on level and stable ground in headland position and secure against rolling. • Tractor motor turned off, parking brake applied, ignition key removed and stored. Implementation ► Activate swath apron: Open stop valve before moving the machine to working position. Operating manual NOVACAT 352 ED/RCB/CF | 109 3784.en-GB.80W.0...
Page 110: Create Working Position From Road Transport Position
Operation Two-way stopcock open ► Deactivate swath apron: Close two-way stopcock after moving the machine to headland position. Two-way stopcock closed Create working position from road transport position Working position 110 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 111: Mowing Work
Cutting height and release can then be adjusted as required.See "Hydraulic relief set- ting" on page 77. Mowing work An attached front mower can then be operated as required. No functions can be coupled with rear mower in standard system. Operating manual NOVACAT 352 ED/RCB/CF | 111 3784.en-GB.80W.0...
Page 112 Shortly before the unmown area, lower the machine into the working position, and where possible, do not mow the already mown areas again. ► Accelerate the tractor and adapt the drive speed according to the crop, the terrain and the release setting. 112 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 113: Trigger / Reset Anti-Collision Safety
Stop tractor immediately and switch off PTO drive. Make sure that the PTO shaft brake is not switched on. Continue with the next step to maneuver the machine out of this situation. Operating manual NOVACAT 352 ED/RCB/CF | 113 3784.en-GB.80W.0...
Page 114 Replace all damaged parts / have them replaced by a specialist workshop before con- tinuing to work with the machine. 114 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 115: Uncoupling
Machine is parked on level and stable ground and secured against rolling away. Implementation ► Move the cardan shaft holder to the stop position. ► Unhook the protective retaining chain from the tractor. Operating manual NOVACAT 352 ED/RCB/CF | 115 3784.en-GB.80W.0...
Page 116: Uncouple The Machine From The Tractor
Place the control device in float position to release pressure in the hydraulic line. In the event your control unit does not have such floating position, move the control lever to and fro several times with the engine switched off. 116 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 117: Put Machine Out Of Operation At End Of Season
► Apply rust protection to bare machine parts, e.g. hydraulic cylinder piston rods or simi- lar. ► Disconnect drive shafts from the machine, push together fully lengthwise and store in dry weather-protected area Operating manual NOVACAT 352 ED/RCB/CF | 117 3784.en-GB.80W.0...
Page 118: Maintenance
Before wintering the machine, unplug the control terminals and store them in a dry, frost- proof area which is protected from direct sunlight. Fully charge battery-operated terminals before winter storage and then check the battery status regularly to prevent its destruction through being totally discharged. 118 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 119: Cardan Shaft Maintenance
Push the cardan shaft back together. Clean and grease cardan shaft ► After a prolonged standstill, always clean and lubricate with brand-name grease before first operation, otherwise lubricate according to the cardan shaft manufacturer's instruc- tions. Operating manual NOVACAT 352 ED/RCB/CF | 119 3784.en-GB.80W.0...
Page 120: Daily Maintenance
Hydraulic hoses that are older than 5-6 years should be replaced. Use only replacement hoses with the same specifications. See the spare parts list. Prerequisite • Machine is to be set over levelled and stable ground and secured against rolling away. 120 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 121: Check / Change Lighting Of Lamps
The illuminants cannot be changed in LED luminaires! Change the LED-lights when faulty. Changing bulbs for the limiting lights Implementation ► Loosen the bolts 1 and 2 and remove the cover keeping in mind the gasket inside. Operating manual NOVACAT 352 ED/RCB/CF | 121 3784.en-GB.80W.0...
Page 122 LED lights with built-in bulbs. Implementation ► Open the bayonet connector on the rear side off the light and unplug the connector. ► Loosen the attachment screws on the rear side and remove the defective light. 122 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 123: Check / Replace Warning Signs, Warning Triangles, Warning Sheets
► Replace damaged warning signs, warning triangles, warning foils before travelling on public roads with the machine. Implementation ► Check that warning signs, warning triangles and warning foils are clean. Operating manual NOVACAT 352 ED/RCB/CF | 123 3784.en-GB.80W.0...
Page 124: Before Every Season
► Turn the clutch a few turns. This will remove impurities from the friction linings. ► Adjust the screws to the previously noted dimension (L). The clutch is ready for use again. 124 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 125: Check The Cardan Shaft Cam Clutch
Machine is to be set over levelled and stable ground and secured against rolling away. • Tractor motor turned off, ignition key removed and stored. Preparation • High-pressure cleaner • Preservative oil Implementation Thoroughly clean with a high-pressure cleaner. Operating manual NOVACAT 352 ED/RCB/CF | 125 3784.en-GB.80W.0...
Page 126: As Required
If both sides of the reversible blades are worn out or the blade is damaged, the blades must be replaced. Always replace the blades with new blades in twos to avoid imbalances. 126 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 127 The machine is standing on even, load-bearing ground in the working position. • Tractor motor turned off, ignition key removed and stored, and parking brake applied. • Front guard folded up. • Side protection folded up. Operating manual NOVACAT 352 ED/RCB/CF | 127 3784.en-GB.80W.0...
Page 128 With new mower blades, remove the anti-corrosion paint at the attachment points around the hole. Implementation ► Place the blade wrench (1) on any side between the mowing disc and the blade holder as shown. 128 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 129: Replace Conditioner Drive V-Belt
Carry out the same procedure for all cutter blades. Replace conditioner drive V-belt When the drive belts show signs of damage or wear, they must be replaced. Always replace all V-belts simultaneously! Operating manual NOVACAT 352 ED/RCB/CF | 129 3784.en-GB.80W.0...
Page 130 ► Hold the blade spanner firmly whilst pivoting the spring-loaded belt tensioner roller out of the working position. ► Do not release the blade spanner until the pressure on the spanner is equal to zero by locking in the plate (H). 130 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 131 Adjust belt tension to factory setting: Twist the nut on the tension roller spring and move the lower edge of the underlying disc to the covering with the pointer tip. Reassemble the machine unit in reverse sequence. Operating manual NOVACAT 352 ED/RCB/CF | 131 3784.en-GB.80W.0...
Page 132: Replace Roller Conditioner Drive V-Belt
Remove belt guard: Loosen screws (1) and (2) and remove protection. Insert blade spanner (K) into the guide with the handle side and press down until the lev- er engages in the plate (H). 132 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 133 Check tensioner pulley run Adjust belt tension to factory setting: Twist the nut on the top of the tension roller spring and set the length of the threaded bolt (X) = 180 mm. Operating manual NOVACAT 352 ED/RCB/CF | 133 3784.en-GB.80W.0...
Page 134: Tine Conditioner, Tines And Tine Fastening Assembly Work
► If worn tine attachments are replaced with new ones, the same number of tine attach- ments must also be replaced on the 180 ° opposed rotor side. 134 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 135 Tractor motor turned off, parking brake applied, ignition key removed and stored. Remove tines and tine attachment Implementation ► Remove screw (1) and cover (2). ► Attach the fitting aid and counteract the pressure of the internal rubber buffer using the fitting aid. Operating manual NOVACAT 352 ED/RCB/CF | 135 3784.en-GB.80W.0...
Page 136 Tap out spring pin with pin punch, adapt applied pressure on fitting aid accordingly if re- quired. ► Remove fitting aid. ► Remove individual parts. ► Replace faulty individual parts with new ones if required. ► Carry out the same procedure on all conditioner tines if required. 136 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 137 8 = spring pin 13x36 mm 9 = bolt M8x55 DIN931 Implementation ► Assemble individual parts paying particular attention to the fitting position of brackets (1), rubber buffers (2) and tines (5-6) as shown! Operating manual NOVACAT 352 ED/RCB/CF | 137 3784.en-GB.80W.0...
Page 138 Make sure that the tine bore holes are aligned and the slit in the spring pin points towards the tine tip. Spring pin assembly position ► Knock the dowel pin in until it stops and remove the fitting mandrel. 138 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 139: Replace Toothed Belt Conditioning Roller
Replace toothed belt conditioning roller Have the toothed belt replaced by a specialist dealer! The toothed belt tension cannot be properly adjusted during a repair without a frequency measurement tool! See repair instructions. Operating manual NOVACAT 352 ED/RCB/CF | 139 3784.en-GB.80W.0...
Page 140: Replace Crossflow Drive V-Belt
Tractor motor turned off, parking brake applied, ignition key removed and stored. Implementation ► Loosen belt tension by releasing the adjusting nut (3). 1 = Console 2 = Disc 3 = adjusting nut ► Remove covering (A) 140 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 141 ► Turn the adjusting nut until the washer (1) and bracket (2) are parallel again. View from above ► Re-fit covering (A) ► Repeat procedure correspondingly on both sides of the machine. Operating manual NOVACAT 352 ED/RCB/CF | 141 3784.en-GB.80W.0...
Page 142: After Service Life
Tractor motor turned off, ignition key removed and stored, an parking brake applied. • Drive shafts uncoupled if necessary. • Covering removed from transmission to be verified. Implementation ► Read and note lasered bushing numbers on all installed taper bushings. 142 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 143: Retighten Blade Bolts
2012 7/16 2017 7/16 2517 2525 3020 3030 3525 3535 Retighten blade bolts Mower discs with attached conveyor drums or conical discs will also be referred to simply as mower discs below! Operating manual NOVACAT 352 ED/RCB/CF | 143 3784.en-GB.80W.0...
Page 144 120 Nm before moving to the next adjacent cutter disc. ▷ Repeat the process as many times are necessary until all blade bolts on all cutter discs in the entire mower unit have been checked. 144 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 145: After 8 Hours Of Operation
Tractor motor turned off, parking brake applied, ignition key removed and stored. 1 = Console 2 = Disc 3 = adjusting nut Implementation Check that the edge of the bracket(1) is flush with the washer (2). View from above Operating manual NOVACAT 352 ED/RCB/CF | 145 3784.en-GB.80W.0...
Page 146: Crossflow Cleaning
Prerequisite • The machine is standing on even, load-bearing ground in the working position. • Tractor motor turned off, ignition key removed and stored, an parking brake applied. • Mower blades dismantled. 146 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 147 ► Check blade bolt head (B). ▷ If the blade bolt head shows signs of wear, the blade bolts must be replaced in any event. Operating manual NOVACAT 352 ED/RCB/CF | 147 3784.en-GB.80W.0...
Page 148: Lubricate Hydraulic Release
The machine is standing on even, load-bearing ground in the working position. • Machine correctly and completely attached to tractor. • Tyre pressure set correctly on tractor. • Tractor engine switched off, parking brake applied. Implementation Turn valve lever (2) and open valve. 148 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 149 Stop filling with the control device when the specified value has been reached. Turn tractor motor off, apply park brake, remove ignition key and keep safe. Close valve (2) lever. Check recommended release (75kg) with spring balance. Operating manual NOVACAT 352 ED/RCB/CF | 149 3784.en-GB.80W.0...
Page 150: Clean Primary Drive Conditioner
Park tractor and machine on level and stable ground in parking position and secure against rolling. • PTO turned off • Tractor motor turned off, parking brake applied, ignition key removed and stored. 150 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 151: Roller Conditioner Toothed Belt Drive (Variant) Cleaning
Tractor motor turned off, parking brake applied, ignition key removed and stored. Implementation ► Screw off covers (A1) and (A2) as shown. ► Thoroughly clean / vacuum the case with compressed air. ► Reattach the covers and tighten the screws. Operating manual NOVACAT 352 ED/RCB/CF | 151 3784.en-GB.80W.0...
Page 152: Toothed Belt Tension Tine Conditioner
▷ If the sleeve can be twisted very slightly and there is extra play along the longitudi- nal axis, continue with step 2. Have the machine overhauled by a specialist dealer. 152 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 153: Lubricate Roller Conditioner Roller Bearings
Tractor motor turned off, ignition key removed and stored, an parking brake applied. Implementation ► Grease all available lubrication points on V-belt drive side. Lubrication nipple (S) ► Grease all available lubrication points on toothed belt drive side / chain drive side. Operating manual NOVACAT 352 ED/RCB/CF | 153 3784.en-GB.80W.0...
Page 154: Lubricate Roller Conditioner
► Clean lubrication nipple before the lubrication process. ► Clean lubricant nozzle before the lubrication process. ► Contaminated lubricant should not be used and should be disposed of correctly. Implementation ► Clean any impurities from the lubricating nipples (19). 154 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 155: Lubricate Crossflow
► Clean lubrication nipple before the lubrication process. ► Clean lubricant nozzle before the lubrication process. ► Contaminated lubricant should not be used and should be disposed of correctly. Implementation ► Clean any impurities from the lubricating nipples. Operating manual NOVACAT 352 ED/RCB/CF | 155 3784.en-GB.80W.0...
Page 156: Lubricate Tine Conditioner Rotor Bearing
Tractor motor turned off, ignition key removed and stored, an parking brake applied. Implementation ► Lubricate all available greasing points on both sides of the conditioner. Lubrication nipple (S) View from above 156 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 157: For The First Time After 50 Operating Hours And Then Every 100 Hectares
So that the oil can be drained as completely as possible, it is necessary to bring it almost up to operating temperature. We recommend carrying out the change on warm days of >15 °C. Operating manual NOVACAT 352 ED/RCB/CF | 157 3784.en-GB.80W.0...
Page 158: Change Mower Input Gear Oil
So that the oil can be drained as completely as possible, it is necessary to bring it almost up to operating temperature. We recommend carrying out the change on warm days of >15 °C. 158 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 159 Gear oil close to operating temperature. • PTO turned off • Tractor motor turned off, parking brake applied, ignition key removed and stored. 1 = casing ventilation 2 = oil level inspection plug 3 = Drain screw Operating manual NOVACAT 352 ED/RCB/CF | 159 3784.en-GB.80W.0...
Page 160: Change Cutter Bar Gear Oil
1.2 liters synthetic gear oil 75W-90 GLS • Waste oil collecting pan with a minimum capacity of 2 litres. • Cleaning paper or similar Prerequisite • Machine is correctly and fully attached to a suitable tractor. 160 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 161 Remove oil level inspection plug and pour new transmission oil in gradually, up to the top mark on the dipstick. The fill level control screw must be tightened fully to measure the fill level. 10 Check oil level continuously during filling. Operating manual NOVACAT 352 ED/RCB/CF | 161 3784.en-GB.80W.0...
Page 162: Every 100 Operating Hours
So that the oil can be drained as completely as possible, it is necessary to bring it almost up to operating temperature. We recommend carrying out the change on warm days of >15 °C. A = Waste oil drain plug E = Filler plug 162 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 163: Change Crossflow Input Gear Oil
So that the oil can be drained as completely as possible, it is necessary to bring it almost up to operating temperature. We recommend carrying out the change on warm days of >15 °C. Operating manual NOVACAT 352 ED/RCB/CF | 163 3784.en-GB.80W.0...
Page 164 Waste oil collecting pan with a minimum capacity of 2 litres. • Cleaning paper or similar 1= Oil level control plug with dipstick 2 = Oil drain plug Implementation Dismantle guide place to access the drain screw. 164 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 165 12 Clean oil residue away from the area around the oil level inspection plug. 13 Reattach the guide plate and tighten the screws. Symbol illustration 14 Dispose of lubricant contaminated cleaning paper and other lubricant residues properly. Operating manual NOVACAT 352 ED/RCB/CF | 165 3784.en-GB.80W.0...
Page 166: Change The Gear Oil In The Roller Conditioner
Clean oil residue away from the area around the drain plug. ► Clean dirt away from the area around the filler plug. ► Open drain splug and drain lubricant completely. ► Re-insert and tighten the drain plug. ► Remove filler plug. 166 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 167: Change Roller Conditioner Belt
3 = Disc Implementation Remove cover ▷ Remove side protection: Remove 2 screws (14) ▷ Lift side protection up and away using the grip (15) ▷ Remove inner covering: Remove 2 screws (16) Operating manual NOVACAT 352 ED/RCB/CF | 167 3784.en-GB.80W.0...
Page 168: Cleaning The Roller Conditioner
The tension roller must run in alignment with the driving belts, see illustration Cleaning the roller conditioner Prerequisite • Park tractor and machine on level and stable ground, and secure against rolling. • PTO turned off 168 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 169: Check / Adjust Roller Conditioner Drive Belt Tension
Park tractor and machine on level and stable ground, and secure against rolling. • PTO turned off • Tractor motor turned off, parking brake applied, ignition key removed and stored. • Cover removed Operating manual NOVACAT 352 ED/RCB/CF | 169 3784.en-GB.80W.0...
Page 170 Adjust the setting with the locknut (5) so that the console (2) and washer are flush when closed. ▷ Close the crank lock (4) to secure the locking (5) in position. Repeat procedure correspondingly on both sides of the machine. 170 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 171: Per Year
Park tractor and machine on level and stable ground in working position. • Tractor motor turned off, ignition key removed and stored, an parking brake applied. • Machine secured against unintentional lowering by positioning. • Gear oil close to operating temperature. Operating manual NOVACAT 352 ED/RCB/CF | 171 3784.en-GB.80W.0...
Page 172 When propping up, make sure that the cutter bar is not inclined on the broad side but is in a fully horizontal position. Otherwise the oil level shown at the oil filler plug will be in- correct. Symbol illustration Horizontally incorrectly aligned! Symbol illustration Horizontally correctly aligned! 172 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 173: Check / Fill Input Gear Crossflow Oil Level
Clean dirt away from the area around the filler plug. ► Dispose of cleaning paper which has been contaminated with lubricant correctly. Check / fill input gear crossflow oil level 1 = Cutter bar input gear 2 = Crossflow input gear Operating manual NOVACAT 352 ED/RCB/CF | 173 3784.en-GB.80W.0...
Page 174 Clean oil level inspection plug and screw back in with a new seal, and tighten. Clean oil residue away from the area around the oil level inspection plug. Dispose of lubricant contaminated cleaning paper and other lubricant residues properly. 174 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 175: Check / Fill Cutter Bar Oil Level
• Tractor PTO switched off • Park tractor and machine on level and stable ground in working position. • Tractor motor turned off, ignition key removed and stored, an parking brake applied. Operating manual NOVACAT 352 ED/RCB/CF | 175 3784.en-GB.80W.0...
Page 176 Clean oil level inspection plug and screw back in with a new seal, and tighten. Clean oil residue away from the area around the oil level inspection plug. Dispose of lubricant contaminated cleaning paper and other lubricant residues properly. 176 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 177: Check / Refill Mower Input Gear Oil Level
Place frame on support stands. • PTO turned off • Tractor motor turned off, parking brake applied, ignition key removed and stored. 1 = casing ventilation 2 = oil level inspection plug 3 = Drain screw Operating manual NOVACAT 352 ED/RCB/CF | 177 3784.en-GB.80W.0...
Page 178: Every 4 Years
Machine is to be set over levelled and stable ground and secured against rolling away. • Tractor motor turned off, ignition key removed and stored. • Hydraulic system depressurized • Work is carried out by an authorized service dealer. Preparation • High-pressure nitrogen filling system 178 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 179: Every 6 Years
"old" hoses or transferring them to the new hoses. See Spare Parts List also. Lubrication plans Lubrication plan symbol explanation Symbol Explanation Every "X" operating hours Annually 100 ha Every 100 hectares Grease The number and position of the grease nipple Operating manual NOVACAT 352 ED/RCB/CF | 179 3784.en-GB.80W.0...
Page 180 Maintenance Symbol Explanation (lll), (lV) Operating materials code (see Operating materials specifications) Quantity of the operating fluid in litres Observe the manufacturer's safety instructions! 180 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 181 Maintenance X1=235mm (III) (III) (III) (100 ) 1,25 [l] SAE90 0,8 [l] SAE90 3,5 [l] SAE90 131-16-24 Operating manual NOVACAT 352 ED/RCB/CF | 181 3784.en-GB.80W.0...
Page 182: Operating Materials
140 according to API-GL 4 or API-GL 5 CROSSFLOW in- (III) Gear oil SAE 90 or SAE 85W - 0.8 litres put gear 140 according to API-GL 4 or API-GL 5 182 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 183 SAE 90 or SAE 85W - 1.25 litres 140 according to API-GL 4 or API-GL 5 Conditioner gear- Fully synthetic ISO-VG-class 220 0.7 litres lubricating oil for high tempera- ture lubrication Gas container Nitrogen As required Operating manual NOVACAT 352 ED/RCB/CF | 183 3784.en-GB.80W.0...
Page 184: Help And Advice
Lighting The lighting does not work Causes and remedies ► Defective fuse. ▷ Replace with fuse of identical specification. ► Present contact error of the cable. 184 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 185: Conditioner Blockages
► Use personal safety equipment such as protective glasses and gloves. ► After the work is completed, verify the function of safety and protection devices and ver- ify the tightness of all previously loosened screw connections. Operating manual NOVACAT 352 ED/RCB/CF | 185 3784.en-GB.80W.0...
Page 186 Park tractor and machine on level and stable ground, and secure against rolling. Implementation ► Memorise the conditioning intensity of the tine conditioner and set to level "0" using the adjustment lever (1) to make it easier to remove blockages. 186 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 187 Right roller conditioner for collector Adjusting spring for conditioning intensity and setting for distance between rollers. Swath plate assembled in parking position when not in use. Eye bolt for swath plate adjustment (right swath plate). Operating manual NOVACAT 352 ED/RCB/CF | 187 3784.en-GB.80W.0...
Page 188 Reduce the conditioning intensity of the conditioner to make it easier to remove block- ages: Twist the nuts (3) on the spring compressors to reduce the spring tension but do not remove the nuts completely! 188 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 189: Remove Cross Flow Blockage
► After the work is completed, verify the function of safety and protection devices and ver- ify the tightness of all previously loosened screw connections. If the blockage is difficult to remove, it can be helpful to break down the fodder manually. Operating manual NOVACAT 352 ED/RCB/CF | 189 3784.en-GB.80W.0...
Page 190: Vibrations With Tine Conditioner During Mowing Operation
Turn tine rotor manually and carry out visual control on the tines. ▷ Replace lost or damaged tines / tine fastenings immediately. ► Carry out assembly work according to maintenance instructions. See "Tine conditioner, tines and tine fastening assembly work" on page 134. 190 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 191: Electric
Plans Electric Hydraulics Operating manual NOVACAT 352 ED/RCB/CF | 191 3784.en-GB.80W.0...
Page 192: Supplement To Usa / Canada Operating Instructions
For machines which are to be operated in the USA / CANADA, a conversion kit with warn- ing stickers (to adapt to local applicable regulations) is available from PÖTTINGER in Eng- lish or French! See also "Supplement to the Operating Instructions USA / CANADA". CROSSFLOW 192 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 193 Supplement to USA / CANADA operating instructions Pos. Warning signs Pos. Warning signs Operating manual NOVACAT 352 ED/RCB/CF | 193 3784.en-GB.80W.0...
Page 194 Supplement to USA / CANADA operating instructions Pos. Warning signs Pos. Warning signs 194 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 195 Supplement to USA / CANADA operating instructions Swath former Pos. Warning signs Pos. Warning signs Operating manual NOVACAT 352 ED/RCB/CF | 195 3784.en-GB.80W.0...
Page 196 Supplement to USA / CANADA operating instructions Pos. Warning signs Pos. Warning signs Roller conditioner 196 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 197 Supplement to USA / CANADA operating instructions Pos. Warning signs Pos. Warning signs Operating manual NOVACAT 352 ED/RCB/CF | 197 3784.en-GB.80W.0...
Page 198 Supplement to USA / CANADA operating instructions Pos. Warning signs Pos. Warning signs Tine conditioner 198 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 199 Supplement to USA / CANADA operating instructions Pos. Warning signs Pos. Warning signs Operating manual NOVACAT 352 ED/RCB/CF | 199 3784.en-GB.80W.0...
Page 200 Supplement to USA / CANADA operating instructions Pos. Warning signs Pos. Warning signs 200 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 201 Supplement to USA / CANADA operating instructions Hitching frame and arm - 01 Pos. Warning signs Pos. Warning signs Operating manual NOVACAT 352 ED/RCB/CF | 201 3784.en-GB.80W.0...
Page 202 Supplement to USA / CANADA operating instructions Pos. Warning signs Pos. Warning signs 202 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 203 Supplement to USA / CANADA operating instructions Hitching frame and arm - 02 Pos. Warning signs Pos. Warning signs Operating manual NOVACAT 352 ED/RCB/CF | 203 3784.en-GB.80W.0...
Page 204: Secure Load Towing
The trac- tor must be heavy and powerful enough with adequate braking power for the towed load. Be especially careful when towing loads on unfavourable ground conditions, when turning and on slopes. 204 | Operating manual NOVACAT 352 ED/RCB/CF 3784.en-GB.80W.0...
Page 205 PÖTTINGER Service Support Centres Austria PÖTTINGER Landtechnik GmbH Industriegelände 1 A-4710 Grieskirchen Phone+43 7248 600-0 Fax+43 7248 600-2513 info@poettinger.at South Germany PÖTTINGER Deutschland GmbH Servicecenter Deutschland Süd Justus-von-Liebig-Str. 6 D-86899 Landsberg am Lech Phone+49 8191 9299-0 Fax+49 8191 59656 landsberg@poettinger.at North Germany PÖTTINGER Deutschland GmbH Servicecenter Deutschland Nord...
Page 206 Fax+39 0523 838253 info@poettinger.it Poland PÖTTINGER Polska sp.z.o.o ul. Skawinska 22 61333 Poznan Phone+48 618700555 info@poettinger.pl United Kingdom Alois POTTINGER UK Ltd. St. Marks Road 15 NN18AN Corby Phone+44 1536 272220 Fax+44 1536 206220 info.uk@pottingeruk.co.uk Ireland POETTINGER Ireland Ltd. Glenaleamy, Powerstown Road E91 D326 Clonmel/Co.
Page 207 Fax+7 495 646 89 16 info.ru@poettinger.ru Canada POETTINGER Canada Inc. 460 Rue Robinson Sud J2G 7N6 Granby/QC Phone+1 450 372 5595 Fax+1 866 417 1683 info@poettinger.ca United States POETTINGER US, Inc. 393 Pilot Drive 46383 Valparaiso/IN Phone+1 219 510 5534 Fax+1 219 707 5412 info@poettinger.us Australia...
Page 208 Phone+46 7063 83133 info@poettinger.dk Switzerland PÖTTINGER AG Mellingerstrasse 11 5413 Birmenstorf Phone+41 56 201 41 60 info@poettinger.ch Slovakia A.PÖTTINGER Slovakia s.r.o. Hollého 46 909 01 Skalica 3784.en-GB.80W.0...
Page 209 PÖTTINGER Service Partner A worldwide network of well established Service Specialist Centres is at your disposal. This regional proximity guarantees the prompt supply of spare parts, enables optimum product delivery and machine configuration by expert personnel. Our service features include: •...
Page 210 3784.en-GB.80W.0...

This manual is also suitable for:

Novacat 352 rcb Novacat 352 cf 3784

Pottinger NOVACAT 352 ED Operating Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Pottinger NOVACAT 352 ED

Summary of Contents for Pottinger NOVACAT 352 ED

This manual is also suitable for:

Table of Contents
