[ ANDREW+ ROBOT USER GUIDE ]
E. TECHNICAL SPECIFICATIONS
Technical Specification
Warranty
Power requirement
Electrical configuration
Interfaces
Operating temperature
Imaging system
Operating humidity
Altitude
Safe operating conditions for the
system
Degree of protection
Required personal computer
characteristics
Dimensions
Weight
Audio
Additional external power
interfaces
Working space
Definition
1 year
Voltage range 90~264 VAC, AC current 1.85 A/115 VAC, 1.0 A/230 VAC, Frequency 47~63 Hz,
inrush current (max) 120 A/230 VAC
The Andrew+ Robot should be connected exclusively with the power supply GSM160B24-R7B
and electrical cable supplied with the instrument
• Wi-fi (2.4 GHz / 5 GHz)
• Ethernet connection (1 Gigabit)
20 °C–37 °C
Hand:
• High resolution camera equipped with white LED light
OLM:
• High resolution camera equipped with low power white LED and class II red laser
(wavelength = 650 nm)
Maximum relative humidity 80% for temperatures up to 37° C.
Up to 2000 m above mean sea level
• Fluctuation of the supply voltage up to 10% of the rated voltage
• Transient overvoltage
IP 20
Tablet or computer equipped with Internet browser and network capability.
Dimension with both arms folded:
53.5 cm (H) x 43 cm (W) x 45.5 cm (L)
16 kg (only the robot)
Integrated audio system (nominal power = 1.5 W)
• Connection with docking station (1 A @ 24 V)
• 4 tool slots embedded in the tool stand (500 mA @ 7.5 V)
Domino self-assembling configuration dynamically set-up on a conventional bench space,
allowing operations on an arbitrary set of Dominos from 1 up to 11 elements compatible with
multi-channel pipettes - according to available space and experiment requirements.
Andrew+ Robot User Manual 5
