I. INSTRUCTION ICONS
Symbol Definition
DANGER
Situation that could cause injury to yourself
and others
DANGER
Radiation with potential for risk to health or
death as a consequence
DANGER
Biohazard with potential for risk to health or
death as a consequence
CAUTION
Situation that could cause damage to your
device or other equipment
NOTE
Notes, usage tips. or additional information
Symbol
e
III. ABBREVIATIONS USED
Abbreviation Meaning
MCP Microplate
LH Liquid handling
DWP Deepwell plate
BSL Biosafety level
PIPETTE ADAPTOR Magnetic interface device adaptor
AA PIPETTE Andrew Alliance electronic pipette
OLM Optical localization module
LLD Liquid level detector
TIS Tip insertion system
ROW Rest of the world
IV. GLOSSARY
Term Definition
Device which can be automatically
handled by the Andrew+ Robot
Tool
robot. Some tools may require an
adaptor (e.g. PIPETTE ADAPTOR)
as interface to allow the
manipulation.
Part of Andrew+ Robot Robot
designed to host up to 4 tools.
Tool stand
The tool stand is the right arm of
the Andrew+ Robot and allows
both charging and wireless
communication with the tools.
Optional component used by the
Andrew+ Robot to host additional
Docking
tools for experiments which
stations
require more than 4 tools or tools
which cannot be installed on the
Andrew+ Robot's tool stand.
Smart pipette stand+ with cloud
connectivity capable of wirelessly
Pipette+
controlling Andrew Alliance
electronic pipettes.
Andrew+ Robot User Manual 2
