[ ANDREW+ ROBOT USER GUIDE ]
V. DELIVERY PACKAGE
Part Number
Andrew+ Robot (includes waste base,
waste container, power supply, cables,
176005081
1x single pipette adaptor, 1x multi-
channel pipette adaptor) and Andrew+
VI. INTRODUCTION
This paragraph describes the small number of steps that
should be followed in order to have your Andrew+ Robot
operational in less than 5 minutes.
A. UNIT DESCRIPTION
The Andrew+ Robot is a laboratory benchtop robot able to
execute experiments according to protocols described by a
user through its software: OneLab. ™
Andrew+ Robot is capable of handling a variety of laboratory
tools which are automatically used by the system. Examples
of such tools are:
Andrew Alliance electronic pipettes
■
Labware gripper
■
Liquid level detector
■
Laboratory conventional consumables required to execute
experiments are arranged into in a magnetic-based modular
system called Dominos. Using its camera, the Andrew+
Robot can localize and identify the consumables present
in its working area. It stands on a base which has a dual
functionality, namely, avoiding involuntary movement of the
robot arm, and hosting the Optical Location Module (OLM)
with which it can measure the length of the pipettes and
tips. The right arm of the Andrew+ Robot, referred to as
the 'tool stand' can hold up to a maximum of 4 tools. Their
manipulation does not require any user intervention. Your
consumables should be placed in appropriate Dominos,
located within the Andrew+ Robot workspace, so that the
Andrew+ Robot can identify them. Depending on your
protocol, you can have 2 Dominos for a small experiment and
up to 11 Dominos, compatible with multi-channel pipettes,
for a more complex one. The Andrew+ Robot is made for
research and development, industrial laboratories and
routine work, with applications limited but not restricted to
life sciences, biotechnology, chemistry, clinical research and
diagnostic.
Description
Robot Lifetime License
B. SAFETY PRECAUTIONS AND WARNINGS
For safe and correct use of the Andrew+ Robot, it is
recommended that both operating and service personnel
follow the instructions contained in this guide when
installing, using, cleaning, and maintaining this instrument.
If the instructions described in this manual are not carefully
followed, the Andrew+ Robot cannot function correctly and
the warranty will be null and void.
Use of biohazardous and
radioactive substances
If the Andrew+ Robot is potentially biohazardous due to the
use of biohazardous substances, it should be prominently
marked with the following symbol:
At a minimum, a biohazard symbol should be placed near the
sampling area and visible during NORMAL USE.
Any part of the equipment that contains biohazardous waste
material which can be removed from the equipment during
NORMAL USE, or a biohazardous drain connection, should be
marked with an appropriate biohazard symbol.
C. SYMBOLS
Advice to be aware and to be careful about!
These symbols point out a potential danger for
users and/or damage to the Andrew+ Robot if they
are not followed. When this symbol is visible, it is
mandatory to carefully read the User Manual before
taking any action or using the system.
Andrew+ Robot User Manual 3
