Operation manual and parts book
High speed, automatic, lockstitch sewing machine
with programmable stitches
Art Auto 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Art Auto 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Texi Art Auto 2

Summary of Contents for Texi Art Auto 2

  • Page 1 Operation manual and parts book High speed, automatic, lockstitch sewing machine with programmable stitches Art Auto 2...
  • Page 2 In order to create a better environment Please, read carefully before use First of all, I would like to express my heartfelt thanks to you for using our products. Our company is committed to caring for the earth's environment and has formulated the basic policy of "intelligent manufacturing and green manufacturing".
  • Page 3 Thank you very much for purchasing our industrial sewing machine Before using the sewing machine, please read <for your safe use> and use instructions carefully. The characteristic of industrial sewing machine is that it should be operated near the moving parts such as needles and spindles, which are easy to cause injury, so place use the sewing machine correctly under the guidance of the safety operation knowledge of trained or skilled personnel.
  • Page 4 [2] Safety Precautions Danger After closing the power switch and unplugging the power plug from the socket, wait for at least 5 minutes before opening the control box cover. Touching areas with high voltage can cause casualties. Warning No liquid is allowed to enter the sewing machine, otherwise it will cause fire, electric shock and operation failure.
  • Page 5 Be careful Sewing This sewing machine is only used by persons trained in safe During the sewing process, do not touch any moving parts operation. or place the objects on the moving parts, because this will This sewing machine cannot be used for any purpose other cause injuries to people or damage to the sewing than sewing.
  • Page 6 Precautions Prior to Startup 1. The machine head is coated with a thick layer of rust-prevention grease before encasement, and the encased machine head may possibly be subjected to grease hardening and dust buildup on the machine surface in process of long storage and long-haul traffic;...
  • Page 7 Main Techanical Specifications Specification Parameter For medium-weight materials Application Max sewing speed 5000 sti/min Max s titch 5 or 7mm DP ×5 9#～22# Length Needle 5.5mm(Max) Hand lifter Presser foot lift height Knee lifter 13mm(Max) Lubricating system Auto Lubrication oil 10# White oil 220V/550W Motor power...
  • Page 8 Mounting the Machine (Fig.1, Fig. 2, Fig.3, Fig.4 and Fig. 5) 1.Installation of oil pan and machine ① Fix the oil pan ② under the table ①with 6 screws ③ as shown in the Fig.1. As shown in the Fig,2 ,fix two cushions ②...
  • Page 9 Lubrication of machine(Fig.6 ) 1.Lubrication of gearbox Fill gearbox if the oil pointer ② below the lower tick mark in the oil window ③ when using the sewing machine. The steps of lubrication are as fellow: Remove the rubber plu g ① of oil filler, fill with oil using the oil bottle in accessory box. (No.10 white oil) Fill oil until the oil point e r ②...
  • Page 10 ② ① ① Fig.8 Fig.7 Mounting the Needle (Fig.8) 1. Turn the upper wheel to allow the needle to reach its maximum height. 2. Unscrew needle carrying screw ② hold needle ① by hand, and align the indentation A of needle to right direction B.
  • Page 11 1.Hold the rotating hook by hand, and fit t - he bobbin into the rotating hook. 2.Thread the thread through the thread groove A in the rotating hook, and draw out the thread in direction C. In this way, the thread is led out of hole B through the tension spring.
  • Page 12 ⑦ ⑧ ⑦ ⑥ ① ③ ⑦ ④ ② Fig.12 ⑤ Fig.12 Caution: 1.To reel bobbin thread onto bobbin① when no sewing is performed, draw the needle thread out of hole in the take-up lever, remove bobbin ① out of rotating hook. 2.Do not touch or lean anything to any running components when rolling the bottom line,in order to avoid the safety accident.
  • Page 13 Threading the Needle Thread (Fig. 13) Caution: 1.To prevent the unexpected startup of sewing machine, trim off the power supply before the operation is conducted. ① ① ② ② ③ ⑩ ④ ③ ⑤ ④ ⑩ ⑨ ⑥ ⑤ ⑦ ⑨...
  • Page 14 Caution: standard and maximal lifting heigh ② ① ① ③ Fig.14 Fig.15 13 Adjusting the Stitch Length The stitch pitch is controlled by the stepper motor , and there is no mechanical function to adjust the stitch pitch . If you need to adjust the stitch pitch , please directly adjust the stitch pitch on the operation panel.
  • Page 15 ③ ② ① Fig.16 Fig.17 15 Operating the Treadle(Fig. 17) 1.The treadle has 4 operation levels: 1) The machine runs at low sewing speed when you lightly depress the front part of the pedal. (as show in the picture B) 2) The machine runs at high sewing speed when you further depress the front part of the pedal.
  • Page 16 Adjusting the Treadle(Fig. 18, Fig. 19, Fig. 20) 1.Adjusting the angle of treadle 1) Adjust the angle of treadle only by adjusting the length of treadle connecting rod: unscrew screw ①, and adjust the length of treadle connecting rod by moving upward/ downward the upper connecting rod ②...
  • Page 17 3.Adjustment of stepping return strength ⑦ to adjust stepping return strength : tighten bolt ⑦t , he 1) Loosing nut ⑥ and turn bolt strength increases;loosen bolt ⑦, the strength decreases. a) Tighten nut ⑥ after adjusting stepping return strength. Caution: 1.To prevent the unexpected startup of sewing machine, trim off...
  • Page 18 Oil mass Adjustment o f Rotating Hook (Fig.21, Fig.2 2, Fig.23) 1.Adjustment method Adjust the oil mass of rotating hook usingadjusting screw ① :Screw down (turn it to the right) adjusting screw ① to raise the oil mass ,or unscrew (turn it to the right) the adjusting screw to lower the oil mass.
  • Page 19 2.Confirming the Oil Mass 1)Remove the thread from all points fromthe Spattered oil thread take-up to the needle. Too much Correct Too little 2)Use the lifting lever to lift the presser foot. 3)Run the machine at the normal sewing speed for approximately 3 minute without sewing any material (following the same 图...
  • Page 20 ① ② ① ② ④ ③ ⑤ Fig.24 Fig.25 Caution: 1. To prevent the unexpected startup of sewing machine, trim off the power supply before the operation is conducted. 2. For ordinary materials, the standard height of pressure adjusting screw① ranges from 32 to 34mm (4.5 kilogram force) approximately.
  • Page 21 Adjustment of The Knee Lift Height(Fig. 26) 1.Turn the machine pulley so that the feed dog is below the top of the needle plate. 2.Lower the presser foot by using the lifting lever. 3.Unscrew the nut ① and rotating the screw ② are the purpose to adjust the height of presser foot when the knee totally pushed to the touch point (by knee, the standard height:10 mm , the maximum height :13mm) 4.Securely tighten the nut ①.
  • Page 22 Caution: 1.To prevent the unexpected startup of sewing machine, trim off the power supply before the operation is conducted. 2.Adjusting the tension of needle thread After the lower thread tension has been adjusted,adjust the upper thread tension so that a good,even stitch is obtained.
  • Page 23 1.U nscrewing the screw ①. 2.Move the right thread hook ② to adjust : the thread amount of thread take-up lever will incr ease if turned it towards left (A direction), ② while turning it to the right (direction B) and ①...
  • Page 24 Caution: 1.To prevent the unexpected startup of sewing machine, trim off the power supply before the operation is conducted. 2.The take-up spring is already adjusted properly before the machine leaves the factory as a rule, and it requires readjustment only for sewing of special materials or usage of special stitch threads.
  • Page 25 ③ ② ① ① DB×1 DA×1 ① DP×5 Fig.32 Adjust t he H eight of t he N eedle B ar(Fig. 3 2) 1.Turn the machine pulley to set the needle bar ① to its lowest position. 2.Remove the rubber cap ② from the face plate. 3.Unscrewing the connecting screw ③...
  • Page 26 Caution: 1.To prevent the unexpected startup of sewing machine, trim off the power supply before the operation is conducted. 2.If the clearance between notch on needle and thread hooking tip of rot ating hook is too small, rotating hook tip may be worn; if the clearance is excessive, skipped stitch may take place.
  • Page 27 Caution: 1.To prevent the unexpected startup of sewing machine, trim off the power supply before the operation is conducted. 2.If the feed lifting eccentric cam is turned too far in the direction A, it may cause the needle to break. 3.To prevent material slippage from occurring,retard the needle timing.
  • Page 28 Caution: 1.To prevent the unexpected startup of sewing machine, trim off the power supply before the operation is conducted. ① Standard ④ Lower the front ④ Raise the front ④ D ③ ② Fig.36 Adjust t he l ean of f eed d og(Fig. 3 6) 1.Turn the pulley until the feed dog ④...
  • Page 29 Caution: 1.To prevent the unexpected startup of sewing machine, trim off the pow- er supply before the operation is conducted. 2.In order to prevent puckering,lowe r the front of the feed dog. 3.In order to prevent the material from slipping,raise the front of the feed dog. 4.The height of the feed dog will change after the angle has been adjusted,so it will be necessary to re-adjust the height of the feed dog.
  • Page 30 2.Grinding the stationary trimmer: If the cutting performance deteriorates,Sh- arpen the fixed knife ④ on a whetstone as Shown in the illustration ⑤. 3.Removing the movable trimmer : 1) Remove the needle. 2) Uplift the presser foot using foot lifting lever. 3) Screw off...
  • Page 31 Adjusting t he T hrea d-trimming Device(Fig. 40, Fig. 41) 1.Adjusting the position of thread-trimming cam 1) Rotating the hand wheel to raise the needle bar 5mm from the lowest place. 2) To press the core in trimming electromagnet ④ with your hands by arrow direction, allowing the ball of the trimming cam crank ③...
  • Page 32 Maintenance(Fig. 42, Fig. 43, Fig. 44) ① ② ③ Fig.42 ④ ⑤ Fig.43 ④ Fig.44 The following cleaning operations should be carried out each day in order to maintain the performance of this machine and to ensure a long service life. 3.Ensuring the oil amount in gear case: Confirm that the top of oil amount indicating rod is between the upper engraved marker line and the lower engraved marker line of the oil amount indicating window.(For the details, refer to “6 Lubrication...
  • Page 33 ④ 6)Remove the bobbin case ⑤ 7)Wipe off any dust from the rotary hook with a soft cloth, and check that there is no damage to the rotary hook ⑤.Wipe out with the cloth dust and hook oil drained in the under cover near the hook. a)Remove the bobbin from the bobbin case ④...
  • Page 34 Ask your supplier about:...
  • Page 35 Strima Sp. z o.o. Swadzim, st. Poznańska 54 62-080 Tarnowo Podgórne, Polska We declare, that the following product: Lockstitch sewing machine Model: Art Auto 2 (A8100-D4-W/02) which this declaration relates, complies with the following directives: Machine directive 2006/42/WE Low voltage directive 2006/95/WE...

  • Page 36: Table Of Contents

    CONTENTS Parts Book Machine Frame & Miscellaneous Cover Components … … … … … … … … … … … … … … … … … … … … … … Main Shaft & Thread Take-up Cover Components … … … … … … … … … … … … … … … … Hand Lifter &...

  • Page 37: Machine Frame & Miscellaneous Cover Components

    Machine Frame & Cover Miscellaneous Components A-13 A-12 A-11 A-20 A-17 A-21 A-16 A-10 A-15 A-18 A-20 A-14 A-23 A-22 A-19 A-24 A-19 A-44 A-25 A-26 A-13 A-32 A-31 A-27 A-43 A-45 A-40 A-39 A-36 A-28 A-33 A-38 A-34 A-30 A-31 A-41 A-37 A-42...
  • Page 38 Machine Frame & CoverMiscellaneous Components Name of part Part No. Ref. No. Remark 10008871 Bed screw stud Rubber plug 10008941 10010066 Screw SM11/64"×40 10003382 Screw SM11/64"×40 10062047 Slide buckle Plastic plate 10067450 10062565 Washer 10062049 Bobbin thread tension ASM Rubber plug A-10 10009576 Side plate gasket...

  • Page 39: Main Shaft & Thread Take-Up Cover Components

    Main Shaft & Thread Take-up Cover Components B-26 B-24 B-36 B-25 B-27 B-23 B-32 B-37 B-33 B-38 B-28 B-39 B-29 B-30 B-29 B-34 B-40 B-31 B-35 B-11 B-12 B-41 B-13 B-14 B-15 B-42 B-17 B-16 B-20 B-43 B-19 B-44 B-21 B-22 B-18 B-46...
  • Page 40 Main Shaft & Thread Take-up Cover Components Name of part Part No. Ref. No. Remark Adjusting pin 10010504 O-ring 6.46×1.78 10010538 Sleeve of adjusting pin 10010540 10066835 Roler felt 10067799 Main shaft 20023713 Head wheel 10011232 Screw M6×6 10059025 Screw M5 ASM. 10074227 ASM.
  • Page 41 Main Shaft & Thread Take-up Cover Components B-26 B-24 B-36 B-25 B-27 B-23 B-32 B-37 B-33 B-38 B-28 B-39 B-29 B-30 B-29 B-34 B-40 B-31 B-35 B-11 B-12 B-41 B-13 B-14 B-15 B-42 B-17 B-16 B-20 B-43 B-19 B-44 B-21 B-22 B-18 B-46...
  • Page 42 Needle bar B-44 10041609 Needle bar -5/H B-45 10010588 Screw SM1/8"×44 Thread guide B-46 10010591 Thread guide B-46 10005945 -5/H B-47 135X5 SERV 7 090 -5/H TEXI Needle DP×5 18# “ * ” Specifi c content need to consult customer service...

  • Page 43: Hand Lifter & Tension Release Components

    Hang Lifter & Tension Release Components C-13 C-15 C-12 C-14 C-45 C-16 C-11 C-17 C-46 C-13 C-10 C-18 C-19 C-21 C-20 C-27 C-22 C-23 C-29 C-28 C-24 C-28 C-25 C-26 C-30 C-48 C-31 C-24 C-49 C-33 C-32 C-38 C-47 C-34 C-36 C-42 C-35...
  • Page 44 Hang Lifter & Tension Release Components Name of part Part No. Ref. No. Remark 10052532 Presser foot ASM. 10005982 Presser foot ASM. -5/H 10010650 Screw SM9/64″×40 10010646 Presser bar 10014118 Shaft sleeve 10005915 Shaft sleeve -5/H Oil protector cover 10066598 10000325 Screw M6×8 Presser guide bar bracket...
  • Page 45 Hang Lifter & Tension Release Components C-13 C-15 C-12 C-14 C-45 C-16 C-11 C-17 C-46 C-13 C-10 C-18 C-19 C-21 C-20 C-27 C-22 C-23 C-29 C-28 C-24 C-28 C-25 C-26 C-30 C-48 C-31 C-24 C-49 C-33 C-32 C-38 C-47 C-34 C-36 C-42 C-35...
  • Page 46 Hang Lifter & Tension Release Components Name of part Part No. Ref. No. Remark C-46 10009205 Spring C-47 10013216 Nut SM1/4″×28 C-48 10000675 Clip C-49 10014477 Screw SM3/16″×28 “ * ” Specifi c content need to consult customer service -10-...

  • Page 47: Hook Of Driving Shaft Components

    Hook Of Driving Shaft Components D-17 D-17 D-26 D-17 D-28 D-17 D-27 D-29 D-25 D-24 D-23 D-22 D-13 D-15 D-14 D-16 D-12 D-13 D-11 D-10 D-10 D-17 D-17 D-18 D-20 D-17 D-21 D-17 D-19 -11-...
  • Page 48 Hook Of Driving Shaft Components Name of part Part No. Ref. No. Remark Bobbin case 52237NS 204 230 A Bobbin alu. 10025484 SMH-7.94BTR Hook 10011101 Screw SM11/64"×40 Positioning fi nger 10031260 10010064 Screw 10010063 Oil wick Oil sealing 7.94×12×3.5 10013029 Shaft sleeve 10068367 D-10...

  • Page 49: Feed Mechanism Components

    Feed Mechanism Components E-30 E-29 E-28 E-26 E-30 E-49 E-27 E-48 E-35 E-36 E-21 E-25 E-47 E-45 E-32 E-33 E-34 E-44 E-24 E-19 E-33 E-34 E-46 E-31 E-43 E-32 E-37 E-44 E-39 E-37 E-22 E-38 E-23 E-40 E-41 E-21 E-42 E-40 E-20 E-15...
  • Page 50 Feed Mechanism Components Name of part Part No. Ref. No. Remark Rubber plug 10069145 10010090 Closing ring 13.8×1 10068365 Shaft sleeve 10068366 Shaft sleeve Thrust collar 10010542 10038073 Screw SM1/4"×40 10068651 Feed driving shaft Feed driving shaft 10068650 Oil seal 14 .72×22×7 10012536 E-10 10004440...
  • Page 51 Feed Mechanism Components E-30 E-29 E-28 E-26 E-30 E-49 E-27 E-48 E-35 E-36 E-21 E-25 E-47 E-45 E-32 E-33 E-34 E-44 E-24 E-19 E-33 E-34 E-46 E-31 E-43 E-32 E-37 E-44 E-39 E-37 E-22 E-38 E-23 E-40 E-41 E-21 E-42 E-40 E-20 E-15...
  • Page 52 Feed Mechanism Components Name of part Part No. Ref. No. Remark Feed adjusting ASM. E-41 10005989 E-42 10010197 Screw SM9/64"×40 E-43 10067159 Feed adjust rod 10010649 E-44 Closing ring 5.1×0.6 Crank E-45 10067160 E-46 10011376 Screw M5×12 E-47 10067158 Oil seal Feed motor 10068811 E-48...

  • Page 53: Thread Trimmer Components

    Thread trimmer Components F-26 F-25 F-23 F-29 F-22 F-21 F-28 F-27 F-24 F-20 F-30 F-17 F-14 F-18 F-15 F-19 F-43 F-13 F-10 F-16 F-36 F-17 F-12 F-11 F-35 F-32 F-34 F-33 F-37 F-37 F-31 F-38 F-38 -17-...
  • Page 54 Thread trimmer Components Name of part Part No. Ref. No. Remark 10011421 Fixed knife 10011422 Screw SM9/64"×40 10024496 Screw SM1/8″×40 Dispart 10058067 Dispart 10062533 10013154 Washer 9×4.5×0.8 10014474 Screw SM11/64"×40 10011514 Screw SM11/64"×40 10031612 Knife shaft crack rod 10010900 Screw SM11/64"×40 F-10 10069005 Knife holder...

  • Page 55: Drive-By-Wire Components

    Drive-by-wire Components G-11 G-13 G-12 G-16 G-14 G-15 G-10 G-16 G-10 G-14 G-17 G-10 -19-...
  • Page 56 Drive-by-wire Components Name of part Part No. Ref. No. Remark 10063944 Screw SM3/16″×28 10074666 Operation screen ASM. 10043305 Screw SM11/64″×40 10008934 Screw SM3/16″×28 10011168 Washer 4.8×11.6×1.6 Led lamp ASM. 10063246 10009074 Screw M4×4 Electromagnet tension disk 10066837 10002417 Pedal control rod ASM. G-10 10049837 Screw M5×35...

  • Page 57: Lubrication Components

    Lubrication Components H-30 H-31 H-25 H-24 H-27 H-26 H-28 H-22 H-29 H-23 H-21 H-20 H-32 H-16 H-33 H-19 H-15 H-18 H-14 H-13 H-17 H-12 H-11 H-10 -21-...
  • Page 58 Lubrication Components Name of part Part No. Ref. No. Remark Oil wick 10008067 10066949 Oil connection Clamk 10011471 10064136 Oil connection 10012160 Clamk 10007796 Oil tube 10007800 Oil tube 10058103 Oil connection 10058087 Screw O-ring 3.6×1.8 10000567 H-10 H-11 10009991 Screw SM5/16″×24 Washer H-12...

  • Page 59: Presser Foot Components Of Oil Plate Knee Lift

    Presser Foot Components Of Oil Plate Knee Lift I-14 I-11 I-10 I-12 I-13 -23-...
  • Page 60 Presser Foot Components Of Oil Plate Knee Lift Name of part Part No. Ref. No. Remark Tank cover gasket 10068368 Knee lift rod 10068362 Oil pan 10068363 Retaining ring 10063385 10059960 Two-way crank of lifting pressor foot Nut M6×3.2 10003890 Screw 10061673 10058784...

  • Page 61: Components Of Thread-Running Stand

    Components Of Thread-running Stand J-14 J-14 J-15 J-15 J-10 J-7 J-8 J-7 J-8 J-16 J-16 J-11 J-17 J-17 J-12 J-13 J-18 J-18 J-19 J-20 J-20 J-19 J-21 -25-...
  • Page 62 Components Of Thread-running Stand Name of part Part No. Ref. No. Remark 10007130 Thread stand ASM. Column cap 10004282 Column pipe(upper) 10004293 10002953 Nut M5 10003022 Washer 5 10003301 Screw M5×14 Thread guide bushing 10004285 Thread guide pipe 10004289 Thread hanger(upper) 10004298 Column pipe connector J-10...

  • Page 63: K Auxiliaries

    Auxiliaries K-12 K-12 K-14 K-10 K-17 K-13 K-12 K-12 K-14 K-15 K-13 K-15 K-11 K-12 K-12 K-12 K-18 K-16 K-16 -27-...
  • Page 64 10051707 Scavenging felt Scavenging felt holder 10051651 Screw ST2 .2×6.5 10003185 Head cover Oil bottle with oil 10060866 K-10 135X5 SERV 7 090 TEXI Needle Head pole K-11 10050425 K-12 10003889 Nail K-13 10051246 Oil reservoir seat 10051245 Oil reservoir cushion...
  • Page 65 NOTES...
  • Page 66 NOTES...
  • Page 67 Dealer:...
