- Page 1 VOLVO Carplay MMI BOX...
-
Page 2: Specifications
Specifications Panel description For power cable connection, CAN data transmission USB/VIDEO USB data transmission, and for reverse/front camera connection HDMI IN HDMI signal input, support resolution up to 720P LVDS LVDS cable connector Toggle switch Refer DIP code setting to set for different car models RF CABLE Wifi antenna connector Features... - Page 3 Connection Diagram...
-
Page 4: Automatic Transmission
Reverse camera wirng connection and settings Automatic transmission 1. Connect the reverse camera to CVBS OUT labeled 'Reverse camera' 2. Connect the cable labeled '12V reverse camera(yellow)' to c amera power 3. Setting → Reverse → Reverse camera → Aftermarket... -
Page 5: Manual Transmission
Manual transmission 1. Connect the reverse camera to CVBS OUT labeled 'Reverse camera' 2. Setting → Reverse → Reverse camera → Aftermarket 3. Set ‘Reverse line detect’ to ON... - Page 6 Wireless carplay connection 1. Turn on WIFI (Fig.1) ’ 2. Turn on Bluetooth (Fig.2), and connect Carplay's bluetooth (Fig.3/4) 3. After the bluetooth connection is completed, the following prompts will pop up, click ‘Allow-Use carplay’ (Fig.5/6)
- Page 7 Wireless Android auto connection 1. Turn on WIFI (Fig.1) 2. Turn on Bluetooth (Fig.2) 3. Enter the Wireless Dev APP(Fig.3 ) 4. Search the bluetooth of phone(Fig. 4 / 5 /6) 5. Choose any one of the options on the car end to pair(Fig .7) 6.
- Page 8 Wired Android auto connection 1. Download Android auto APP on Android phone(Fig.1). 2. Click ‘WireAuto’ icon(Fig.2), the prompt ‘Please connect your Android device’ will pop up(Fig.3). 3. Plug your phone to USB port. then it will enter Android auto automatically(Fig.4). ①...
- Page 9 1. Click ‘Airplay’ icon first (Fig.1), the pairing information with the phone will be displayed (Fig.2). 2.Search wifi signal of Airplay and connect. 3. Turn on Airplay (Fig3/4). Note: If you have connected Carplay before, please disconnect Carplay wifi first. Wired Autolink connection 1.
- Page 10 Original buttons 1 Switch to the previous song 2 Sytem switching, long press 3s to switch system 3 Long press for 3s: system switching Long press for 12s: mandatory upgrade system 4 Answer/hang up the call 5 Switch to the next song 6 Select function in Carplay/Android auto interface 7 Short press: confirm 8 Short press: back...
- Page 11 Accessories Wifi Antenna AV-USB cable LVDS cable USB audio box CAN power cable...
