Summary of Contents for Chroma A190519

  • Page 2 Get more product & global distributor information in Chroma ATE APP...
  • Page 3 HV Contact Check Box A190519 Quick Start Guide Version 1.1 October 2021 P/N ITM-0257488...
  • Page 4 Legal Notices The information in this document is subject to change without notice. Chroma ATE INC. makes no warranty of any kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Chroma ATE INC. shall...
  • Page 5 Warranty All of Chroma’s instruments are warranted against defects in material and workmanship for a period of one year from date of shipment. Chroma agrees to repair or replace any assembly or component found to be defective, under normal use during this period. Chroma’s obligation under this warranty is limited solely to repairing any such instrument, which in Chroma’s sole opinion proves to be...
  • Page 6 Material Contents Declaration The recycling label shown on the product indicates the Hazardous Substances contained in the product as the table listed below. : See <Table 1>. : See <Table 2>. <Table 1> Hazardous Substances Lead Mercury Cadmium Hexavalent Polybrominated Selected Phthalates Chromium Biphenyls/...
  • Page 7 “” indicates that the level of the specified chemical substance exceeds the threshold level specified in the standards of SJ/T-11363-2006, EU Directive 2011/65/EU, and 2015/863/EU. Chroma is not fully transitioned to lead-free solder assembly at this moment; however, most of the components used are RoHS compliant.
  • Page 8 Failure to comply with these precautions or specific WARNINGS given elsewhere in this manual will violate safety standards of design, manufacture, and intended use of the instrument. Chroma assumes no liability for the customer’s failure to comply with these requirements. BEFORE APPLYING POWER Verify that the power is set to match the rated input of this power supply.
  • Page 9 Safety Symbols DANGER – High voltage. Explanation: To avoid injury, death of personnel, or damage to the instrument, the operator must refer to the explanation in the instruction manual. High temperature: This symbol indicates the temperature is hazardous to human beings. Do not touch it to avoid any personal injury.
  • Page 10 Standard Requirement Quick Start Guide Main Unit Standard Requirement (Cable) RTN/LOW HV Test Cable HV Test Cable 24V/0.75A Test Cable 4 pcs 1 pcs Power Adaptor 1pcs Note When additional item is required, just inform Chroma the item name. viii...
  • Page 11 Danger of Operating When the instrument is under output voltage, please don’t touch test area or you may shock hazard and result in death. Please obey the following items.  Make sure the grounding cable is connected correctly and using the standard power cord.
  • Page 12 Remove all connected wires and cables on the instrument before cleaning. Use a brush gently to clean the dust on it. For internal cleaning, use a low- pressure air gun to vacuum the dust inside or send it back to the distributors or agents of Chroma for cleaning.

  • Page 13: Table Of Contents

    HV Contact Check Box A190519 Quick Start Guide Table of Contents 1. Preface ..................... 1 An Overview of Product ..............1 2. Panel Operation ..................2 Description for Input and CONTACT Signal ........2 Description for Output Function ............. 3...

  • Page 15: Preface

    HV Contact Check Box A190519 Quick Start Guide Preface Product Overview HV Contact Check Box is used with Chroma Electrical Safety Analyzer and Hipot Analyzer for judging if test cable connecting to DUT is correct and performing contact check function.

  • Page 16: Panel Operation

    HV Contact Check Box A190519 Quick Start Guide Panel Operation Description for Input and CONTACT Signal CONTACT Indicator LED: The indicator LED is lighted while test cables of OUTPUT HV and RTN terminals are connected to DUT exactly. CONTACT Short-circuit Signal: These two contacts will be short- circuited while test cables of OUTPUT HV and RTN terminals are connected to DUT exactly.

  • Page 17: Description For Output Function

    HV Contact Check Box A190519 Quick Start Guide the power circuit or any device’s cable is shorted with the grounding terminal, and it is very dangerous as anyone who touches it may cause electric shock incident. Therefore, the safety ground terminal must connect to earth properly.

  • Page 18: Wiring Example

    HV Contact Check Box A190519 Quick Start Guide Wiring Example When the output terminal of HV contact check box connects DUT exactly and INTERLOCK of the Safety or Hipot Analyzer is short circuit status, thus the test can be started normally.
  • Page 20 CHROMA ATE INC. info@chromaate.com www.chromaate.com Copyright by CHROMA ATE INC. All Rights Reserved. All other trade names referenced are the properties of their respective companies.
