Programmable DC Electronic Load
6310A Series
Operation & Programming Manual
www.valuetronics.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6310A Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Chroma 6310A Series

Summary of Contents for Chroma 6310A Series

  • Page 1 Programmable DC Electronic Load 6310A Series Operation & Programming Manual www.valuetronics.com...
  • Page 2 www.valuetronics.com...
  • Page 3 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Version 1.6 August 2013 P/N A11 001257 www.valuetronics.com...

  • Page 4: Legal Notices

    The information in this document is subject to change without notice. Chroma ATE INC. makes no warranty of any kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 5: Warranty

    Chroma’s obligation under this warranty is limited solely to repairing any such instrument, which in Chroma’s sole opinion proves to be defective within the scope of the warranty when returned to the factory or to an authorized service center. Purchaser is responsible for the shipping and cost of the service item to Chroma factory or service center.

  • Page 6: Material Contents Declaration

    Material Contents Declaration The recycling label shown on the product indicates the Hazardous Substances contained in the product as the table listed below. : See <Table 1>. : See <Table 2>. <Table 1> Hazardous Substances Lead Mercury Cadmium Hexavalent Polybrominated Polybromodiphenyl Part Name Chromium...
  • Page 7 “ ” indicates that the level of the specified chemical substance exceeds the threshold level specified in the standards of SJ/T-11363-2006 and EU 2005/618/EC. Chroma is not fully transitioned to lead-free solder assembly at this moment; however, most of the components used are RoHS compliant.
  • Page 8 www.valuetronics.com...
  • Page 9 www.valuetronics.com...
  • Page 10 viii www.valuetronics.com...
  • Page 11 WARNING This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. www.valuetronics.com...

  • Page 12: Safety Summary

    Failure to comply with these precautions or specific WARNINGS given elsewhere in this manual will violate safety standards of design, manufacture, and intended use of the instrument. Chroma assumes no liability for the customer’s failure to comply with these requirements.

  • Page 13: Safety Symbols

    Safety Symbols DANGER – High voltage. Explanation: To avoid injury, death of personnel, or damage to the instrument, the operator must refer to an explanation in the instruction manual. High temperature: This symbol indicates the temperature is now higher than the acceptable range of human. Do not touch it to avoid any personal injury.

  • Page 14: Revision History

    Revision History The following lists the additions, deletions and modifications in this manual at each revision. Date Version Revised Sections Mar. 2009 1.0 Complete this manual. Dec. 2009 1.1 Modify and add specifications in the chapter of “General Information.” Add the following in the chapter of “Local Operation”: –...

  • Page 15: Table Of Contents

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual Table of Contents PART 1: Operation General Information ....................1-1 Introduction....................... 1-1 Description......................1-1 Overview of Key Features ................1-2 Specifications ....................1-2 Installation ......................2-1 Introduction....................... 2-1 Inspection & Standard Accessories..............2-1 Installing the Modules..................
  • Page 16 Programmable DC Electronic Load 6310A Series Operation & Programming Manual 4.2.7 Setting the Configuration ................ 4-17 4.2.8 Recalling Files/OCP Files/OPP Files............4-27 4.2.9 Saving File/OCP File/OPP File/Default/Program ........4-28 4.2.10 Going To Local ..................4-29 4.2.11 Lock Operation ..................4-29 4.2.12...
  • Page 17 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Register Information in Common ..............8-1 Channel Status ....................8-3 Channel Summary .................... 8-3 Questionable Status ..................8-4 Output Queue ....................8-4 Standard Event Status..................8-4 Status Byte Register ..................8-5 Service Request Enable Register..............
  • Page 18 www.valuetronics.com...

  • Page 19: Part 1: Operation

    PART 1 Operation www.valuetronics.com...
  • Page 20 www.valuetronics.com...

  • Page 21: General Information

    6314A, 6312A electronic load mainframes as well as 63101A, 63102A, 63103A, 63105A, 63106A, 63107A, 63108A, 63110A, 63112A, 63113A and 63123A electronic load modules. Here “Load” means the electronic load modules of the Chroma 6310A Series while “Mainframe” means the 6314A, 6312A electronic load mainframes.

  • Page 22: Overview Of Key Features

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 1.3 Overview of Key Features A. Configuration • Flexible configuration with plug-in electronic load modules in mainframes. • Local operation via front panel keypad. • Remote control via optional GPIB/USB or standard RS-232C interface.
  • Page 23 The storage relative humidity is 10% to 95%. The specifications of DC current accuracy are tested after the input is applied for 30 seconds. The power of the load module of 6310A series is supplied from 6314A/6312A mainframe. 10. The typical temperature coefficient is 100ppm.

  • Page 24: Dynamic Mode

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual MODEL 63101A 63105A 200W 300W POWER CURRENT 0∼4A 0∼40A 0∼1A 0∼10A VOLTAGE 0∼80V 0∼500V 0.4V@2A 0.4V@20A 1V@0.5A 1V@5A MIN. OPERATING VOLTAGE (DC)*1(Typical) 0.8V@4A 0.8V@40A 2V@1A 2V@10A CONSTANT CURRENT MODE 0∼4A 0∼40A...

  • Page 25: Short Circuit

    General Information GENERAL SHORT CIRCUIT Current (CC) – – Voltage (CV) – – Resistance (CR) – – Power (CP) – – Ω (Typical) Ω (Typical) ≧ ≧ INPUT RESISTANCE (LOAD R 100k R 100k OFF) Temperature Coefficient 100ppm/°C (Typical) 100ppm/°C (Typical) Supply from 6314A Mainframe Supply from 6314A Mainframe Power...
  • Page 26 Programmable DC Electronic Load 6310A Series Operation & Programming Manual MODEL 63102A(100W*2) 63103A 100W 300W POWER CURRENT 0∼2A 0∼20A 0∼6A 0∼60A VOLTAGE 0∼80V 0∼80V 0.4V@1A 0.4V@10A 0.4V@3A 0.4V@30A MIN. OPERATING VOLTAGE 0.8V@2A 0.8V@20A 0.8V@6A 0.8V@60A (DC)*1(Typical) CONSTANT CURRENT MODE 0∼2A 0∼20A...
  • Page 27 General Information GENERAL SHORT CIRCUIT Current (CC) – – Voltage (CV) – – Resistance (CR) – – Power (CP) – – Ω (Typical) Ω (Typical) ≧ ≧ INPUT RESISTANCE (LOAD R 100k R 100k OFF) Temperature Coefficient 100ppm/°C (Typical) 100ppm/°C (Typical) Supply from 6314A Mainframe Supply from 6314A Mainframe Power...
  • Page 28 Programmable DC Electronic Load 6310A Series Operation & Programming Manual MODEL 63107A(30W,250W) 63106A 250W 600W POWER CURRENT 0∼5A 0∼4A 0∼40A 0∼12A 0∼120A VOLTAGE 0∼80V 0∼80V 0.4V@2.5A 0.4V@2A 0.4V@20A 0.4V@6A 0.4V@60A MIN. OPERATING VOLTAGE 0.8V@5A 0.8V@4A 0.8V@40A 0.8V@12A 0.8V@120A (DC)*1(Typical) CC MODE 0∼5A...

  • Page 29: Input Resistance

    General Information GENERAL SHORT CIRCUIT Current (CC) – – – Voltage (CV) – – – Resistance (CR) – – – – – Power (CP) – – – Ω (Typical) Ω (Typical) ≧ ≧ INPUT RESISTANCE R 100k R 100k (LOAD OFF) Temperature 100ppm/°C (Typical) 100ppm/°C (Typical)
  • Page 30 Programmable DC Electronic Load 6310A Series Operation & Programming Manual MODEL 63108A 63112A 600W 120W 1200W POWER CURRENT 0∼2A 0∼20A 0∼24A 0∼240A VOLTAGE 0∼500V 0∼80V 1V@1A 1V@10A 0.4V@12A 0.4V@120A MIN. OPERATING VOLTAGE 2V@2A 2V@20A 0.8V@24A 0.8V@240A (DC) (Typical) CONSTANT CURRENT MODE 0∼2A...
  • Page 31 General Information GENERAL SHORT CIRCUIT Current (CC) – – Voltage (CV) – – Resistance (CR) – – Power (CP) – – Ω (Typical) Ω (Typical) ≧ ≧ INPUT RESISTANCE (LOAD OFF) R 100k R 100k Temperature Coefficient 100ppm/°C (Typical) 100ppm/°C (Typical) Supply from 6314A Mainframe Supply from 6314A Mainframe Power...
  • Page 32 Programmable DC Electronic Load 6310A Series Operation & Programming Manual MODEL 63123A POWER 350W CURRENT 0∼7A 0∼70A VOLTAGE 0∼120V MIN. OPERATING VOLTAGE (DC) 0.05V@3.5A 0.3V@35A 1(Typical) 0.1V@7A 0.6V@70A CONSTANT CURRENT MODE 0∼7A 0∼70A Range Resolution 0.125mA 1.25mA 0.04%+0.04%F.S. 0.04%+0.04%F.S. Accuracy CONSTANT RESISTANCE MODE CRL @ CH: 0.015Ω∼15Ω...
  • Page 33 General Information Resolution 0.125mA 1.25mA Accuracy 0.04%+0.04% F.S. POWER READ BACK Range 0∼35W 0∼350W 0.1%+0.1% F.S. Accuracy PROTECTIVE SECTION Over Power Protection Over Current Protection Over Temperature Protection Over Voltage Alarm GENERAL SHORT CIRCUIT Current (CC) – Voltage (CV) – Resistance (CR) –...
  • Page 34 Programmable DC Electronic Load 6310A Series Operation & Programming Manual 63110A (100W* MODEL POWER 100W CURRENT 0∼0.6A 0∼2A VOLTAGE 0∼500V MIN. OPERATING VOLTAGE (DC) 0.9V@0.3A 3V@1A *4(Typical) 1.8V@0.6A 6V@2A CONSTANT CURRENT MODE Range 0∼0.6A 0∼2A μ μ Resolution Accuracy 0.1%±0.1%F.S.
  • Page 35 General Information Temperature Coefficient 100PPM/°C (Typical) Dimension(H×W×D) 172×82×489.5mm / 6.77×3.23×19.27inch 4.2kg Weight (Approx.) Operating Temperature Range 0 ~ 40°C EMC & SAFETY 1-15 www.valuetronics.com...
  • Page 36 Programmable DC Electronic Load 6310A Series Operation & Programming Manual MODEL 63113A POWER 300W CURRENT 0∼5A 0∼20A VOLTAGE 0∼300V MIN. OPERATING VOLTAGE(DC) 0.5V@2.5A 2V@10A (Typical) 1V@5A 4V@20A CONSTANT CURRENT MODE 0∼5A 0∼20A Resolution 100μA 400μA Accuracy 0.1%±0.1%F.S. 0.1%±0.2%F.S. CONSTANT RESISTANCE MODE CRL@CH: 0.2Ω∼200Ω...
  • Page 37 General Information Resolution 100μA 400μA Accuracy 0.05%+0.05% F.S. PROTECTIVE SECTION Over Power Protection Over Current Protection Over Temperature Protection Over Voltage Alarm* GENERAL SHORT CIRCUIT Current (CC) – Voltage (CV) – Resistance (CR) – Power (CP) – RESPONSE Level 5 Sec. Ω(Typical) ≧...
  • Page 38 Programmable DC Electronic Load 6310A Series Operation & Programming Manual 0.2%×Vin/Rsetting±8mA CRL at CL: When the loading current is > 20% of F.S. current, 0.2% (setting+range) When the loading current is < 20% of F.S. current, the loading error is 0.2%×Vin/Rsetting±4mA...

  • Page 39: Installation

    Keep all packing materials in case the Load or the Mainframe has to be returned. If any damage is found, please file a claim with the carrier immediately. Do not return the instrument to Chroma without prior approval. Please ensure that the following items are received along with the Mainframe and Load.

  • Page 40: Installing The Modules

    Loads (Ex: 63106A). The Loads can be combined in the Mainframe in any order. The Chroma 6312A mainframe has room for only two single-width Loads or one double-width Load. The procedures for the module installation in both Mainframes are the same.
  • Page 41 Install each additional module in the slot next to the previous one, likewise if applicable. Figure 2-1 Installing Modules in the Electronic Load WARNING If the Mainframe is not installed with all modules, the empty one must be covered with the panel cover (Chroma part No: L00 002255) for safety and airflow. www.valuetronics.com...

  • Page 42: Channel Number

    7 and 8 on the rightmost. The channel number is fixed for the Mainframe even if the Load module is empty. Figure 2-2 shows the channel assignments for a Chroma 6314A Mainframe containing two Loads, 63103A single channel/module, and two Loads 63102A double channel/module.

  • Page 43: Changing Line Voltage

    Installation 2.4.1 Changing Line Voltage The electronic load can operate with a 115/230 Vac input as indicated on the rear LINE label. The 100/200 line voltage input model is used in Japan only. If the factory set switch on this label that does not correspond to the local nominal line voltage, turn off the Mainframe power and disconnect the power cord.

  • Page 44: Application Connection

    < --- Model Number 1.02 < --- F/W version Figure 2-4 Module Panel Self-test Display In case of failure, return the Mainframe or Load module to Chroma sales or service office for repair services. 2.5 Application Connection 2.5.1 Load Connections...
  • Page 45 UUT under emergency conditions. If there are any questions regarding safe operation of the equipment or adding external protection circuits, please contact Chroma’s service personnel. Figure 2-5 Load & Remote Sensing Connection...

  • Page 46: Remote Sensing Connections

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 2.5.2 Remote Sensing Connections There are two sensing points on the electronic load module. One is the measurement at Load, terminal, and the other is the measurement at Vsense. The Load module will automatically switch to Vsense when the Vsense terminals are connected to the UUT, otherwise it will measure at the Load terminals.

  • Page 47: Remote Control Connection

    The interface connectors on the rear panel connect the Load to the controller or a computer. The GPIB or USB interface of the electronic load is optional. The 6310A Series Remote Controller can control the load through RS-232C port standard. Connect the Remote Controller to the electronic load before powering on.
  • Page 48 www.valuetronics.com...

  • Page 49: Operation Overview

    Operation Overview 3.1 Introduction The Chroma 6314A and 6312A multiple electronic load mainframes are used for design, manufacturing, testing and quality assurance. The Mainframe contains four (6314A) or two (6312A) slots for load modules. Load modules occupy either one or two slots depending on the power rating of the module.

  • Page 50: Rear Panel Description

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual Figure 3-1 Front Panel of the Mainframe 6312A 3.3 Rear Panel Description The rear panel of the mainframe includes an RS-232C connector, a GO/NG output port, a DIGTAL I/O port, an AC LINE socket, a fuse holder, an optional GPIB or USB connector, and three cooling fans.

  • Page 51: Local/Remote Control

    /dynamic, and load A/B or display selection R/L. Details of local operation are given in Chapter 4 Local Operation. Fundamentals of remote programming are described in the second part of this manual, Chroma 6310A Programming Manual. 3.5 Modes of Operation There are four modes of operation: Constant Current (CC), Constant Resistance (CR), Constant Voltage (CV), and Constant Power (CP).

  • Page 52: Constant Current Mode

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 3.5.1 Constant Current Mode Figure 3-3 Constant Current Mode In CC mode, the Load will sink a current in accordance with the programmed value regardless of input voltage. The CC mode can be set with the front panel key MODE.
  • Page 53 Operation Overview STATic/DYNAmic Functions In CC mode two operation functions (STATic, DYNAmic) may be selected. The STATic function checks the stability of the output voltage from a power supply. In some modules (single channel/module) there are two current levels (A or B) for the static function. Both states A and B use the same range.
  • Page 54 Programmable DC Electronic Load 6310A Series Operation & Programming Manual CCDL1: 4A CCDL2: 2A CCDLT1: 15ms CCDLT2: 5ms CCDL↗: 0.1A/ μs CCDL↘: 0.3A/μs Current CCDL1 CCDL2 Time 15ms 15ms CCDL1: 2A CCDL2: 4A CCDLT1: 15ms CCDLT2: 10ms CCDL↗: 0.1A/μs CCDL↘: 0.3A/μs...

  • Page 55: Constant Resistance Mode

    Operation Overview Slew Rate (Rise, Fall A/μs or mA/μs) Slew rate determines the rate at which the current input of a module changes to a newly programmed value. There are two slew rate values. One is for rise rate, and another for fall rate.

  • Page 56: Constant Voltage Mode

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual MODE SELECT Select Constant Resistance low voltage range MODE SELECT Select Constant Resistance high voltage range Select the range by pressing the ENTER key. If the input voltage is over the maximum of the low range, you must select the high range.

  • Page 57: Constant Power Mode

    Operation Overview Voltage & Current Range (High) MODE SELECT Select Constant Voltage high voltage range Select the range by pressing the ENTER key. The voltage and current range in the CV mode is the high range. 3.5.4 Constant Power Mode Load Power setting Current...

  • Page 58: Led Mode

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 3.5.5 LED Mode Slope < 　 − ≥ 　 In the LED mode, the load simulation is similar to the fragment based on the programmed LED working point to sink current by input voltage.

  • Page 59: Load Synchronization

    Select the range by pressing the ENTER key. 3.7 Load Synchronization The Chroma 6314A/6312A multiple electronic load mainframes contain eight and four load channels respectively. The channel on/off or change of load timing is important. You can set the module to change synchronously through SYNC RUN in the configuration setting. If a channel is set to SYNC RUN ON, it means that the channel on/off or change of load level is synchronized with the other load modules.

  • Page 60: Start/Stop Sink Current

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual Therefore, both minimum transition time and slew rate must be considered in the determination of actual transition time. The minimum transition time is from 24 μs to 6 ms, which depends on the slew rate setting.

  • Page 61: Short On/Off

    Operation Overview Figure 3-11 Stop Sinking Current (Von Non-Latch) 3.11 Short On/Off A load module can simulate a short circuit at its input by setting the load on with full-scale current. The short circuit can be set on or off at the front panel or via remote control. There are two operations for the SHORT key on the front panel.

  • Page 62: Load On/Off

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 3.12 Load On/Off A module’s input can be toggled on/off through the ON/OFF key on the front panel of Mainframe, the LOAD key on the module, or the remote control.

  • Page 63: Save/Recall Setting

    Operation Overview • Reverse Voltage The Load conducts a reverse current when the polarity of UUT connection is not correct. The maximum safe reverse current is the same as the rated current of the load. If the reverse current of the UUT is over the rated current of load, the load may be damaged. If a reverse voltage condition is detected, you must turn off power to the UUT immediately, and make a correct connection.
  • Page 64 www.valuetronics.com...

  • Page 65: Local Operation

    Local Operation Local Operation 4.1 Introduction This chapter describes how to operate the electronic load from the local panel in detail. The descriptions include: Mainframe panel control, Module panel control and indicators. 4.2 Local Operation of Load Mainframe In order to use the front panel keys to control the electronic load, local operation must be in effect.
  • Page 66 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Figure 4-1 Front Panel of Mainframe Line switch Turn the ac power on/off. LCD display Display channel information normally. Channel indicator Indicate the active channel settings. Function keys CHAN To select a channel for settings.

  • Page 67: Selecting The Channel

    Local Operation program is from 1 to 10. Saving DEFAULT saves the status of all channels for the next time the electronic load is turned on. All saved settings are stored in EEPROM, and will not be lost when the ac power is cycled. SPEC To select specification data for editing, or to enable SPEC function.

  • Page 68: Setting The Operation Mode

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 4.2.2 Setting the Operation Mode The MODE key and ▲ , ▼ keys are used to select the modes of channels for local control. Press MODE to display the selected channel’s active mode. The active mode can be changed by use of the ▲...
  • Page 69 Local Operation Set Slew Rate There are 250 discrete steps in each range. Set the rise 50 mA/μs and fall slew rates to 50 mA/μs by pressing 5 , 0 , ENTER for rise and 6 , 0 , ENTER for fall slew rate. LED simulation load does not have Set Slew Rate function.
  • Page 70 Programmable DC Electronic Load 6310A Series Operation & Programming Manual CRL↗ : 0.10A/μs CRL↘ : 0.20A/μs Setting CV Values The CV values for the selected channel are programmed by pressing the MODE, ▲ and ENTER keys. The voltage values can be programmed in one range. The voltage levels are programmed in volts and the response speed is programmed in fast/slow operations.
  • Page 71 Local Operation MODE SELECT Set Resistor Level There are 4000 discrete steps from 0 to full scale in each range. Set the main resistance level1 (A) to 20 watts by pressing 2 , ENTER. Set the level2 (B) resistance level to 10 watts by pressing 1 , ENTER.
  • Page 72 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Definition: : The output voltage of LED power. : The output current of LED power. Coefficient: The ratio of dynamic LED working point and DC impedance. : The dynamic impedance of LED operating point.

  • Page 73: Setting The Ocp/Opp Mode Of Operation

    Local Operation 4.2.3 Setting the OCP/OPP Mode of Operation The OCP/OPP key has OCP and OPP modes for users to test the UUT voltage to ensure that it reaches the trigger voltage level and determine if the OCP or OPP protection is acting normally.
  • Page 74 Programmable DC Electronic Load 6310A Series Operation & Programming Manual When the OCP/OPP execution is done, to clear the 7-segment display of the module, press the MEAS. key to clear it and restore the display of voltage, current or power.
  • Page 75 Local Operation CURRENT RANGE 1.CCH 2.CCL Set the start and end current Press 1 , . , 5 ,ENTER keys to set the start current (Istart) and press 6 ,ENTER keys to set the end current (Iend). Istart： 1.500 A Iend：...

  • Page 76: Setting The Program

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual − Pend Pstart Accuracy Typical Step The following examples illustrate how to set the OPP values of the load module for 63103A. Enter into the OPP mode and Select POWER Range Press the OCP/OPP key to enter into the Power mode and select the power range.

  • Page 77: Program Select

    Local Operation ten programs (1-10). Each program has ten sequences to map files from 1 to 100. The program 1 maps files from 1 to 10. Table 4-1 shows the relationship between the program sequence and the corresponding file. Table 4-1 The Relationship of the Program Sequence and the Corresponding File. Program 1 Sequence No.
  • Page 78 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Setting the Sequence P/F Delay Time The sequence Pass/Failure delay time let you set the delay time for P/F checking when the load condition changes. The failure status of the sequence will latch when a program is executed.

  • Page 79: Running The Program

    Local Operation To set the external control, press the ▼ key and select EXT to key in 3 . EXT=3 Setting the Short Channel When the sequence mode is not SKIP, you must set the short channel & time. The short channel is selected as the active channel.

  • Page 80: Setting The Specification

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual will show the following: PROG. XX : 1 2 4 5 6 7 8 9 10 PROG. XX stands for the file number of the program that failed, 1 to 10. Also, 1, 2, 3...10 shown by LCD stands for the failed sequence.

  • Page 81: Setting The Configuration

    Local Operation 4.2.7 Setting the Configuration The electronic load provides useful features such as Von point, Current limit, Sync run, etc. To use these powerful features, you must set relevant parameters in accordance with application needs by the use of the configuration setup. This procedure is only needed for the initial setup of a test operation.
  • Page 82 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Set Von latch. There are two operating modes for Von control. Von latch ON means that Load will sink current continuously when Von voltage is reached. Von latch OFF means that the load will stop sinking current when the UUT voltage is under the Von voltage.
  • Page 83 Local Operation Figure 4-3 Von LATCH OFF Current Waveform Set VOFF. The VOFF is set for the user to stop the current loading when the voltage is under the low limit. The default setting of VOFF is OFF. VOFF 1:ON 2:OFF Set VOFF FINAL.
  • Page 84 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Figure 4-4 Von and VOFF Loading Current Waveform Set CV mode CURR_LIMIT. It limits the current sinking of the load to protect the UUT in CV mode. The default setting of current limit is the maximum Load current.
  • Page 85 Local Operation or Percentage for HIGH and LOW data. The percentage values refer to the CENTER value of specification. The default setting of the SPEC entry mode is percentage. SPEC. ENTRY MODE 1:VALUE 2:PCet Set SYNChronous run mode. When SYNC run is set to ON, the Load on/off is controlled by the ON/OFF key on the Mainframe.
  • Page 86 AVERAGE: Set Timing Function mode The 6310A Series Loads have a unique timing & measurement function that is able to conduct precision time settings and measurements in the range of 00:00:00.000s to 24:00:00.000s. This feature allows users to set a trigger voltage & timeout value for battery discharge testing and similar applications.

  • Page 87: Timing Function

    Local Operation TIMING FUNCTION Vtrg: 2.000V Press 0 , 0 , 1 , ENTER to set the timeout. TIMEOUT (24hr) 00:10:00.000 s Figure 4-5 Battery Discharge Testing Timing function cannot be operated under CV mode but only valid in CC, CAUTION CR and CP mode.
  • Page 88 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Set ST/DYNA KEY. It sets the key on the module to the Static/DYNAmic function when required. It can change the MEAS. hot key to ST/DYNA for users to switch CC mode and CC Dynamic mod on the module directly.
  • Page 89 Local Operation WARNING This function supports LED simulation load only. Set the load internal impedance R is used to adjust the internal impedance for ripple current. It is suggested to set to OFF when the LED driver is on and is doing PWM dimming to avoid causing damage to the Electronic Load due to over transient current.
  • Page 90 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Note When the R is set to ON, the SHORT key will switch to R ON/OFF and the R valid only when the SHORT key is pressed. Once the SHORT key is released, the R function will be disabled.

  • Page 91: Recalling Files/Ocp Files/Opp Files

    Local Operation 1: ON 2: OFF This function supports 63113A only. Turning off this function may WARNING affect the system stability. Once there is a problem with system stability, it is suggested to restart this function. This function supports LED load simulation only. WARNING Display the versions of load module &...

  • Page 92: Saving File/Ocp File/Opp File/Default/Program

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual RECALL FILE FILE NO: The data of all channels will be recalled when you execute file recall. Press RECALL , 2 ,ENTER to recall OCP files from 1 to 10.

  • Page 93: Going To Local

    Output Input Note Pin 1 (+5V) is for 6310A series Remote Controller only. 4.2.13 Connecting the GO/NG Output Port The GO/NG output port on the rear panel of Mainframe is a 15-pin connector (DB-15, female connector). The GO/NG signals are TTL active low to indicate NG. They are defined as follows, see Figure 4-6 Pin Assignment of DIGITAL I/O Port and GO/NG OUTPUT Port.

  • Page 94: Connecting The Digital Io Port

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual GO/NG Output Port Connector Pin Number Channel No. Description H:PASS or SPEC. OFF, L:FAIL H:PASS or SPEC. OFF, L:FAIL H:PASS or SPEC. OFF, L:FAIL H:PASS or SPEC. OFF, L:FAIL H:PASS or SPEC. OFF, L:FAIL H:PASS or SPEC.
  • Page 95 Local Operation DIGITAL IO Port Connector DR3-15ST Definition Pin Number Definition － Load ON/OFF (O/P) Total Pass (O/P) Total Fail (O/P) Short Signal (O/P) Protection Signal (O/P) External Load ON/OFF (I/P) － － External Trig. For Sequences Run (I/P) Pin 2, 3, 4, 5, 14 are connected to GND. Note External ON/OFF (I/P) : <50ms (Level) Uses the TTL input signal (High >...
  • Page 96 Programmable DC Electronic Load 6310A Series Operation & Programming Manual EXT. ON/OFF→ EXT. Sequence Pin 15 Input Press “ENTER” key at frame Sequence Run (H) / Stop (L) Seq.1 Seq.2 Seq.3 Seq.4 1. Auto 2. Manual 3. EXT 1. Auto...

  • Page 97: Setting The Gpib Address

    Pin 10 Output 4.2.15 Setting the GPIB Address Please refer to the second part of this manual, Chroma 6310A Programming Manual. GPIB address displays after RS-232C parameters in the system. You can use this feature to check the GPIB address.

  • Page 98: Local Operation Of Single Channel/Module (Panel A)

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 4.3.1 Local Operation of Single Channel/Module (Panel A) Figure 4-7 Single Channel/Module (Panel A) 7-segment LED Display It displays the measurement Voltage, Current and Power. Each display has five digits.
  • Page 99 Local Operation MEAS. key can select the measurement voltage (V), current (A) and power (W) using the 7-segment display. See section 4.3.4 for detail operation. The other function of this key is Static/DYNAmic mode, see 4.2.7 for detail description. Set ST/DYNA KEY to on in CONF can switch the MEAS.

  • Page 100: Local Operation Of Double Channels/Module (Panel B)

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual mainframe is in OCP/OPP mode, it will perform the OCP/OPP test. See 4.2.3 for the detail operation. Load Input On/Off The input can be toggled on or off by pressing LOAD. When the input is turned on, the LED of the load will be active.
  • Page 101 Local Operation 7-segment LED Display The 7-segment LED displays measurement Voltage, Current and Power of single or double channels. Each display has five digits. The Channel LED Indicators There are two LEDs indicating the active right and/or left channel(s) of Load module. When the LED of channel R is on, the 7-segment display, mode, GO/NG indicators, and keypad are active on channel R.

  • Page 102: Switching Of Meas. Voltage, Current & Power On Module

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual Examples The following examples illustrate how to select the double channels/module in CC mode. There are two channels/modules, so you have to select the right or left channel for display &...

  • Page 103: Online Change Level

    Local Operation Figure 4-9 7-Segment Display for MEAS. V / A / W Switch 4.3.4 Online Change Level The load module provides the user with two ways to change level. They make it convenient to change the load directly with the rotary knob in LOADON. These two operation modes are described below.
  • Page 104 www.valuetronics.com...

  • Page 105: Part 2: Programming

    PART 2 Programming www.valuetronics.com...
  • Page 106 www.valuetronics.com...

  • Page 107: General Information For Programming

    General Information for Programming 5.1 Introduction This section describes how to program the 6310A series electronic load remotely from a GPIB controller, or USB controller or RS232C. The command set introduced here can be applied to all electronic loads of 6310A series, including 63101A, 63102A, 63103A, etc.

  • Page 108: Other Dip Switches

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 0 1 1 0 1 1 1 1 0 1 0 1 1 1 0 1 1 1 1 0 0 1 1 1 1 5.2.2 Other DIP Switches The remaining bits on the DIP switch, A6-A8, preset the electronic load mainframe 6312A or...

  • Page 109: Rs232C In Remote Control

    General Information for Programming 5.4 RS232C in Remote Control When you use RS232C in remote control, you have to send the remote command of CONFigure:REMote ON first in order to let control procedure enter into remote state, and then do other command set. When control comes to an end, you have to send the command of CONFigure:REMote OFF so as to let control procedure return to the mode of local operation.
  • Page 110 www.valuetronics.com...

  • Page 111: Introduction To Programming

    The Chroma 6310A electronic load accepts the numerical data type listed in Table 6-1. Numeric data may be followed by a suffix that dimensions the data. A suffix may be preceded by a multiplier. The Chroma 6310A makes use of the suffixes listed in Table 6-2 and multipliers listed in Table 6-3.

  • Page 112: Character Data Formats

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual Table 6-1 Numerical Data Type Symbol Description Example Digits with no decimal point. The decimal point is 123, 0123 assumed to be to the right of the least-significant digit. Digits with a decimal point.

  • Page 113: Separators And Terminators

    Introduction to Programming 6.4 Separators and Terminators In addition to keywords and parameters, GPIB program statements require the following: Data Separators: Data must be separated from the previous command keyword by a space. This is shown in examples as a space (CURR 3) and on diagrams by the letters SP inside a circle. Keyword Separators: Keywords (or headers) are separated by a colon (:), a semicolon (;), or both.
  • Page 114 Programmable DC Electronic Load 6310A Series Operation & Programming Manual (root):VOLT:L1: 30<nl> Starting a New Line returns to the Root. (root):SPEC:VOLT:H 30; :L 5;: (root):RES:L1 400; :RISE 1000;: www.valuetronics.com...

  • Page 115: Language Dictionary

    Language Dictionary Language Dictionary Commands for operating the 6310A Electronic Load remotely are grouped into subsystems. Each command belonging to the same subsystem is arranged in alphabetic order. A syntax chart of the subsystem, which includes the commands belonging to the same group, is given. Sub-systems are then ordered alphabetically according to their names in the following sections.
  • Page 116 Programmable DC Electronic Load 6310A Series Operation & Programming Manual 2. Clear the Error Queue 3. If “Clear Status Command” immediately follows a program message terminator (<nl>), the “Output Queue” and the MAV bit are also cleared. Syntax : *CLS...
  • Page 117 Model Always return zero 01.00 Revision level of the primary interference firmware Customer’s version Return Example : CHROMA 6314A,0,01.00,0 *OPC Operation Complete Command Type : Device Status Description : This command causes the interface to set the OPC bit (bit 0) of the Standard Event Status register when the Electronic Frame (6314A) has completed all pending operations.
  • Page 118 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Description : This command stores the present state of the single electronic load and the states of all channels of the multiple loads in a specified location in memory. Syntax : *SAV <NRf>...

  • Page 119: Specific Commands

    Language Dictionary 7.2 Specific Commands The 6310A series products are equipped with the following specific GPIB commands. 7.2.1 ABORT Subsystem :ABORt ABORt Type : All Channels Description : It sets all electronic loads to "OFF". Syntax : ABORt 7.2.2 CHANNEL Subsystem...
  • Page 120 Programmable DC Electronic Load 6310A Series Operation & Programming Manual CHANnel:[LOAD] Type : Channel Specific Description : It selects a specific channel by which the coming channel-specific command will be received and executed. Syntax : CHANnel <NRf+> Parameters : 1 ~ 8...
  • Page 121 Language Dictionary String Information CHROMA Manufacturer 6310XA Model Serial No. xx.xx Revision of the primary interface firmware PCB version Return Example : CHROMA,63102A,0,01.00,0 www.valuetronics.com...

  • Page 122: Configure Subsystem

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 7.2.3 CONFIGURE Subsystem :CONFigure :VOLTage <NRf> suffix <NR2> :RANGe <NRf> suffix <NR2> :LATCh ON/1 OFF/0 <NR1> :RESet :AUTO :LOAD ON/1 OFF/0 <NR1> :MODE LOAD/1 PROGRAM/0 <NR1> :SOUNd ON/1 OFF/0 <NR1>...
  • Page 123 Language Dictionary :CONFigure :TIMing :STATe ON/1 OFF/0 <NR1> :TRIGger <NR2> <NR2> :TIMEOUT <NR1> <NR1> :VOFF :STATe ON/1 OFF/0 <NR1> :TRIGger <NR2> <NR2> :MEASure :AVErage <NR1> <NR1> :DIGITalio ON/1 OFF/0 <NR1> :KEY ON/1 OFF/0 <NR1> :ECHO OLD/1 NEW/0 <NR1> www.valuetronics.com...
  • Page 124 Programmable DC Electronic Load 6310A Series Operation & Programming Manual :CONFigure :RDSEL DEFAULT/0 COEFF/1 OHM/2 VF/3 VFRD/4 <NR1> ON/1 OFF/0 :RRSEL DEFAULT/1 SET/0 :RRSET <NRf> :SHORt ON/1 OFF/0 :RESPonse :SEL DEFAULT/1 SET/0 :RESPonse :SET <NR1> :SETALLLED ALL/1 SINGLE/0 :RANGe ON/1...
  • Page 125 Language Dictionary CONFigure:VOLTage:ON Type : Channel-Specific Description : It sets the voltage of sink current on. Syntax : CONFigure:VOLTage:ON <NRf> [suffix] Parameters : For valid voltage range refer to respective specification. Example : CONF:VOLT:ON 1 It sets Von=1V. CONF:VOLT:ON 300mV It sets Von=300mV.
  • Page 126 Programmable DC Electronic Load 6310A Series Operation & Programming Manual CONFigure:AUTO:LOAD Type : All Channels Description : It sets if the load module will do Auto Load On during power-on. Syntax : CONFigure:AUTO:LOAD ON CONFigure:AUTO:LOAD OFF Parameters : ON/1, OFF/0...
  • Page 127 Language Dictionary Type : All Channels Description : It stores the data of CONFigure into EEPROM. Syntax : CONFigure:SAV Parameters : none Example : CONF:SAV CONFigure:LOAD Type : All Channels Description : The value at the setting of load module as LOADON is the one changed by the rotary knob (UPDATED/1) or the original set value (OLD/0).
  • Page 128 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Parameters : 0-86400000 Example : CONFigure:TIMing : TIMEOUT 1000 It sets the timeout. Query Syntax : CONFigure:TIMing: TIMEOUT? Return Parameters : <NR2>[Unit=ms] Query Example : CONFigure:TIMing:TRIG? It returns the timeout set.
  • Page 129 Language Dictionary Query Syntax : CONFigure:DIGITalio? Return Parameters : <NR1> Query Example : CONFigure:VOFF:STATe? It returns the Digital IO setting to be ON or OFF Return Example CONFigure:KEY Type : Channel-Specific Description : It sets if change the MEAS key on the Module to Static/Dynamic. Syntax : CONFigure:KEY <NR1>...
  • Page 130 Programmable DC Electronic Load 6310A Series Operation & Programming Manual CONF:RR OFF It sets the Rr function to off. Query Syntax : CONFigure:RR? Return Parameters : <NR1> Query Example : CONF:RR? Return Example It returns if the Rr function is on.
  • Page 131 Language Dictionary Query Syntax : CONFigure:RESPonse:SEL? Return Parameters : <NR1> Query Example : CONF:RESP:SEL? Return Example It returns the response speed the Electronic Load uses. CONFigure:RESPonse:SET Type : Channel-Specific Description : It sets the response speed of Electronic Load. Syntax : CONFigure:RESPonse:SET <NR1>...
  • Page 132 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Return Parameters : <NR1> Query Example : CONF: LVP? Return Example It returns the LVP function has been enabled. CONFigure:LEDLCRL:RANGe Type : Channel-Specific Description : It sets the CRL and LEDL Mode current range..

  • Page 133: Current Subsystem

    Language Dictionary 7.2.4 CURRENT Subsystem :CURRent :STATic <NRf+> suffix <NR2> :RISE <NRf+> suffix <NR2> :FALL :DYNamic <NRf+> suffix <NR2> :RISE <NRf+> suffix <NR2> :FALL <NRf+> suffix <NR2> CURRent:STATic:L1/L2 Type : Channel-Specific Description : It sets the Static Load Current of constant current mode. Syntax : CURRent:STATic:L1 <NRf+>...
  • Page 134 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Static Load L2. CURR:STAT:L1 MAX It sets the Constant Current = maximum value for Static Load L1. CURR:STAT:L2 MIN It sets the Constant Current = minimum value for Static Load L2.
  • Page 135 Language Dictionary Return Example : 35.6 CURRent:DYNamic:RISE/FALL Type : Channel-Specific Description : It sets the current slew rate of constant current dynamic mode. Syntax : CURRent:DYNamic:RISE <NRf+> [suffix] CURRent:DYNamic:FALL <NRf+> [suffix] Parameters : For valid value range refer to respective specification. Example : CURR:DYN:RISE 2.5 It sets the rise slew rate to 2.5A/μS.

  • Page 136: Fetch Subsystem

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 7.2.5 FETCH Subsystem FETCh:VOLTage? Type : Channel-Specific Description : It returns the real time voltage measured at the input of the load module. Query Syntax : FETCh:VOLTage? Return Parameters : <NR2> [Unit=Voltage]...
  • Page 137 Language Dictionary FETCh:STATus? Type : Channel-Specific Description : It returns the real time status of the load module. Query Syntax : FETCh:STATus? Return Parameters : <NR1> FETCh:ALLVoltage? Type : Channel-Independent Description : It returns the real time voltage measured at the input of the all load module.
  • Page 138 Programmable DC Electronic Load 6310A Series Operation & Programming Manual The time count in the format of hr:min:sec.ms If the parameter of arg1 is -1 or -2, it does not return arg2. 7-24 www.valuetronics.com...

  • Page 139: Load Subsystem

    Language Dictionary 7.2.6 LOAD Subsystem :LOAD :STATe ON/1 OFF/0 <NR1> :SHORt :STATe ON/1 OFF/0 <NR1> :KEY TOGGLE/1 HOLD/0 <NR1> :PROTection :CLEar <NR1> :CLEar :SAVe LOAD:[STATe] Type : Channel-Specific Description : The LOAD command makes the electronic load active/on or inactive/off. Syntax : LOAD:[STATe] ON LOAD:[STATe] OFF...
  • Page 140 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Syntax : LOAD:SHORt:[STATe] Example : LOAD:SHOR ON It activate the short-circuited simulation. LOAD:SHOR OFF It inactivates the short-circuited simulation. Parameters : ON/1, OFF/0 Query Syntax : LOAD:SHORt:[STATe]? Return Parameters : <NR1>...
  • Page 141 Language Dictionary LOAD:SAVe Type: All Channels Description: It saves the current data as default. Syntax: LOAD:SAVe Parameters: None Example: LOAD:SAV 7-27 www.valuetronics.com...

  • Page 142: Measure Subsystem

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 7.2.7 MEASURE Subsystem MEASure:VOLTage? Type : Channel-Specific Description : It returns the voltage measured at the input of electronic load. Query Syntax : MEASure:VOLTage? Return Parameters : <NR2> [Unit=Voltage] Query Example...
  • Page 143 Language Dictionary MEASure:CURRent? Type : Channel-Specific Description : It returns the current measured at the input of electronic load. Query Syntax : MEASure:CURRent? Return Parameters : <NR2> [Unit=Ampere] Query Example : MEAS:CURR? Return Example : 3.15 MEASure:POWer? Type : Channel-Specific Description : It returns the power measured at the input of electronic load.
  • Page 144 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Return Example : 1.2, 2, 0, 0, 10.2, 0, 0, 0 MEASure:ALLCurrent? Type : Channel-Independent Description : It returns the current measured at the input of all load modules. Query Syntax : MEASure:ALLCurrent? Return Parameters : <aard>...

  • Page 145: Mode Subsystem

    Language Dictionary 7.2.8 MODE Subsystem 7-31 www.valuetronics.com...
  • Page 146 Programmable DC Electronic Load 6310A Series Operation & Programming Manual :MODE CCDL CCDH <aard> MODE Type : Channel-Specific Description : This command sets operational modes of the electronic load. Syntax : MODE CCL It sets the CC mode of low range.
  • Page 147 Language Dictionary Parameters : CCL, CCH, CCDL, CCDH, CRL, CRH, CV, CPL, CPH, LEDL,LEDH Example : MODE CCL Query Syntax : MODE? It returns the operational mode of the electronic load. Return Parameters : <aard> Query Example : MODE? Return Example : CCL 7-33 www.valuetronics.com...

  • Page 148: Program Subsystem

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 7.2.9 PROGRAM Subsystem :PRORGram :FILE <NRf+> <NR1> :SEQuence <NRf+> <NR1> :SHORt :CHANnel <NRf> <NR1> :TIME <NRf> <NR2> :MODE SKIP AUTO MANUA <CHAR> :ACTive <NRf> <NR1> :CHAin <NRf> <NR1> :ONTime <NRf>...

  • Page 149: Program:file

    Language Dictionary PROGram:FILE Type : By program file Description : It sets the program number. Syntax : PROGram:FILE <NRf+> Parameters : 1 to 10 Example : PROG:FILE 10 Query Syntax : PROGram:FILE? It returns the active program number. Return Parameters : <NR1> Query Example : PROG:FILE? Return Example...
  • Page 150 Programmable DC Electronic Load 6310A Series Operation & Programming Manual PROGram:SEQuence:SHORt:TIME Type : By program file Description : It sets the short time of program file sequence. Syntax : PROGram:SEQuence:SHORt:TIME Parameters : 0 - 30.0 Example : PROG:SEQ:SHOR: TIME 10...

  • Page 151: Program:run

    Language Dictionary Syntax : PROGram:OFFTime <NRf> Parameters : For valid value range refer to respective specification. Example : PROG:OFFT 20 PROG:OFFT 200mS Query Syntax : PROGram:OFFTime? Return Parameters : <NR2> [Unit=Sec] Query Example : PROG:OFFT? Return Example : 0.2 PROGram:PFDTime Type : By program file Description...

  • Page 152: Resistance Subsystem

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 7.2.10 RESISTANCE Subsystem :RESistance <NRf+> suffix <NR2> :RISE <NRf+> suffix <NR2> :FALL RESistance:L1/L2 Type : Channel-Specific Description : It sets the static resistance level of constant resistance mode. Syntax : RESistance:L1 <NRf+> [suffix] RESistance:L2 <NRf+>...

  • Page 153: Run Subsystem

    Language Dictionary maximum programmable value. RES:FALL MIN It sets the CR fall slew rate to the minimum programmable value. Query Syntax : RESistance:RISE? RESistance:FALL? RESistance:RISE? MAX RESistance:FALL? MIN Return Parameters : <NR2> [Unit=OHM] Query Example : RES:RISE? It returns the CR rise slew rate. Return Example : 2.5 7.2.11 RUN Subsystem...
  • Page 154 Programmable DC Electronic Load 6310A Series Operation & Programming Manual SHOW:DISPlay Type : Channel-Specific (Double Channel Module Only) Description : It sets the the display mode of the electronic load. Syntax : SHOW:DISPlay L SHOW:DISPlay LPI SHOW:DISPlay LVP SHOW:DISPlay R...

  • Page 155: Specification Subsystem

    Language Dictionary 7.2.13 SPECIFICATION Subsystem i ica i < < < < < < 7-41 www.valuetronics.com...
  • Page 156 Programmable DC Electronic Load 6310A Series Operation & Programming Manual :SPECification :UNIT VALUE/1 PERCENT/0 <NR1> <NR1> :PASS :VOLTage :CURRent <NR1> :VOLTage <NRf> suffix :CURRent <NR2> :TEST ON/1 OFF/0 <NR1> SPECification:UNIT Type : All Channels Description : It sets the specific entry mode.
  • Page 157 Language Dictionary Description : It requests the GO-NG result refer to the current specification. Query Syntax : SPECification:CURRent? Query Example : SPEC:CURR? It returns the current GO-NG result to CC mode. Return Parameters : <NR1> Return Example : 0 (NG), 1 (GO) SPECification:LED? Type : Channel-Specific...
  • Page 158 Programmable DC Electronic Load 6310A Series Operation & Programming Manual SPECification:CURR:L? SPECification:CURR:C? Query Example : SPEC:CURR:H? Return Parameters : <NR2> [Unit=Current] Return Example : 4.75 SPECification:TEST Type : Channel-Specific Description : It starts or closes the specification test. Syntax : SPECification:TEST ON...

  • Page 159: Status Subsystem

    Language Dictionary 7.2.14 STATUS Subsystem :STATus :CHANnel :CONDition :ENABle <NR1> :EVENt :NTRansition <NR1> :PTRansition :CSUMmary :ENABle <NR1> :EVENt :QUEStionable :CONDition :ENABle <NR1> :EVENt :NTRansition <NR1> :PTRansition STATus:CHANnel:CONDition? Type : Channel-Specific Description : It returns the channel status in real time. Query Syntax : STATus:CHANnel:CONDition? Return Parameters : <NR1>...
  • Page 160 Programmable DC Electronic Load 6310A Series Operation & Programming Manual STATus:CHANnel:ENABle Type : Channel-Specific Description : It masks for selecting which bits in the Event register are allowed to be summed into the corresponding channel bit of the Channel Summary Event register.
  • Page 161 Language Dictionary Query Syntax : STATus:CSUMmary:ENABle? Return Parameters : <NR1> Query Example : STAT:CSUM:ENAB? It returns the setting of Channel Summary Enable register. Return Example STATus:CSUMmary:EVENt? Type : Channel-Specific Description : It Indicates all channels on which an enable STAT:CHAN Event has occurred since last time the register was read.

  • Page 162: Status:questionable:event

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual STATus:QUEStionable:EVENt? Type : Channel-Specific Description : It records all Questionable conditions that have occurred since last time the register was read. Query Syntax : STATus:QUEStionable:EVENt? Return Parameters : <NR1> Query Example...

  • Page 163: Voltage Subsystem

    Language Dictionary 7.2.15 VOLTAGE Subsystem :VOLTage <NRf+ > suffix < NR 2> M IN :C URR ent <NRf+ > suffix < NR 2> :MODE FAST/1 S LOW/0 <NR1> < VOLTage:L1/L2 Type : Channel-Specific Description : It sets the voltage of static load during constant voltage mode. Syntax : VOLTage:L1 VOLTage:L2...

  • Page 164: Voltage:current

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual Query Example : VOLT:L1? It returns the set voltage value of load L1. Return Example VOLTage:CURRent Type : Channel-Specific Description : It sets the current limit of constant voltage mode.

  • Page 165: Power Subsystem

    Language Dictionary 7.2.16 POWER Subsystem POWer: STATic:L1/L2 Type : Channel-Specific Description : It sets the static power level of constant power mode. Syntax : POWer:STATic:L1 <NR2> [suffix] POWer:STATic:L2 <NR2> [suffix] Parameters : For valid value range refer to respective specification. Example : POW:STAT:L1 20 W It sets the constant power = 20 w for...
  • Page 166 Programmable DC Electronic Load 6310A Series Operation & Programming Manual POW:STAT:FALL 1A/μS It sets the CP fall slew rate to 1wμS. POW:STAT:RISE MAX It sets the CP rise slew rate to the maximum programmable value. POW:STAT:FALL MIN It sets the CP fall slew rate to the minimum programmable value.

  • Page 167: Led Subsystem

    Language Dictionary 7.2.17 LED Subsystem < < < < < < < < < < LED:VO Type : Channel-Specific Description : It sets the output voltage of LED driver. Syntax : LED:VO <NRf+> Parameters : For valid value range refer to respective specification. Example : LED:VO 8 It sets Vo=8V.
  • Page 168 Programmable DC Electronic Load 6310A Series Operation & Programming Manual LED:RD:COEFF Type : Channel-Specific Description : It sets the LED operating point impedance. Syntax : LED:RD:COEFF <NRf+> Parameters : 0.001~1 Example : LED:RD:COEFF 0.1 It sets Coeff=0.1 LED:RD:COEFF 1 It sets Coeff=1...
  • Page 169 Language Dictionary Example : LED:VFRD:VF 8 It sets Vf=8V. LED:VFRD:VF 24 It sets Vf=24V. Query Syntax : LED:VFRD:VF? Return Parameters : <NRf+> Query Example : LED:VFRD:VF? It returns the set Vf value. Return Example : 24 LED:VFRD:N Type : Channel-Specific Description : It sets the LED number in series.

  • Page 170: Ocp Subsystem

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 7.2.18 OCP Subsystem Type : Channel-Specific Description : It executes or cancels the OCP Test. Syntax : OCP <NR1> Parameters : ON/1, OFF/0. Example : OCP ON It executes the OCP Test.
  • Page 171 Language Dictionary OCP:ISTArt Type : Channel-Specific Description : It sets the start current for OCP test mode. Syntax : OCP:ISTArt <NR2> Parameters : Refer to respective specification for valid value range. Example : OCP:ISTA 0.5 It sets the starts current = 0.5A OCP:ISTA MAX It sets the starts current = maximum value.
  • Page 172 Programmable DC Electronic Load 6310A Series Operation & Programming Manual OCP:DWEL MAX It sets the dwell time = maximum value. OCP:DWEL MIN It sets the dwell time = minimum value. Query Syntax : OCP:DWEL?[ <MAX | MIN>] Return Parameters : <NR1>[Unit = ms]...
  • Page 173 Language Dictionary Query Syntax : OCP:SPECification:H?[ <MAX | MIN>] Return Parameters : <NR2>, [Unit = Ampere] Query Example : OCP:SPECification:H? OCP:SPECification:H? MAX OCP:SPECification:H? MIN Return Example : 2.8 OCP:RESult? Type : Channel-Specific Description : It returns the result of OCP test function. Syntax : None Parameters...

  • Page 174: Opp Subsystem

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 7.2.19 OPP Subsystem Type : Channel-Specific Description : It executes or cancels the OPP Test. Syntax : OPP <NR1> Parameters : ON/1, OFF/0. Example : OPP ON Execute the OPP Test.
  • Page 175 Language Dictionary OPP:PSTArt Type : Channel-Specific Description : It sets the starts power for OPP test mode. Syntax : OPP:PSTArt <NR2> Parameters : Refer to respective specification for valid value range. Example : OPP:PSTA 5 It sets the Set starts power = 5W OPP:PSTA MAX It sets the starts power = maximum value.
  • Page 176 Programmable DC Electronic Load 6310A Series Operation & Programming Manual OPP:DWEL MIN It sets the dwell time = minimum value. Query Syntax : OPP:DWEL?[ <MAX | MIN>] Return Parameters : <NR1>[Unit = ms] Query Example : OPP:DWEL? OPP:DWEL? MAX OPP:DWEL? MIN...
  • Page 177 Language Dictionary Query Syntax : OPP:SPECification:H?[ <MAX | MIN>] Return Parameters : <NR2>, [Unit = Watt] Query Example : OPP:SPECification:H? OPP:SPECification:H? MAX OPP:SPECification:H? MIN Return Example : 10 OPP:RESult? Type : Channel-Specific Description : It returns the result of OPP test function. Syntax : None Parameters...
  • Page 178 www.valuetronics.com...

  • Page 179: Status Reporting

    Status Reporting 8.1 Introduction This chapter discusses the status data structure of the Chroma 6310A series electronic load as shown in Figure 8-1. The standard registers, such as the Event Status register group, the Output Queue, the Status Byte and Service Request Enable registers perform standard GPIB functions and are defined in IEEE-488.2 Standard Digital Interface for Programmable...
  • Page 180 Programmable DC Electronic Load 6310A Series Operation & Programming Manual CHANNEL STATUS (ONE CHANNEL) CONDITION PTR/NTR EVENT ENABLE CHANNEL SUMMARY EVENT ENABLE CHAN 1 N.U. 5-15 CHAN 2 CHAN 3 CHAN 4 CHAN 5 CHAN 6 CHAN 7 CHAN 8...

  • Page 181: Channel Status

    Status Reporting 8.3 Channel Status ■ The Channel Status register offers you one or more channel status conditions, which indicate certain errors or faults have occurred on specific channel. Table 8-1 describes the channel status conditions that are applied to the electronic load. ■...

  • Page 182: Questionable Status

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 8.5 Questionable Status ■ The Questionable Status registers offer you one or more questionable status conditions, which indicate certain errors or faults have occurred on at least one channel. Table 8-2 lists the questionable status conditions that are applied to the electronic load.

  • Page 183: Status Byte Register

    Status Reporting Table 8-3 Bit Description of Standard Event Status Mnemonic Bit Value Meaning Operation Complete. This event bit generated is responding to the *OPC command. It indicates that the device has completed all selected pending operations. Query Error. The output queue was read when no data were present or the data in the queue were lost.

  • Page 184: Service Request Enable Register

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 8.9 Service Request Enable Register ■ The Service Request Enable register can be programmed to specify which bit in the Status Byte register will generate service requests. www.valuetronics.com...

  • Page 185: An Example Of Use

    An Example of Use An Example of Use In this chapter a basic example of controlling electronic load are provided for use of GPIB. The GPIB used here is made by NI (National Instruments). Examples: #include “dec1.h” #include <stdio.h> #include <stdlib.h> #include <sring.h>...
  • Page 186 Programmable DC Electronic Load 6310A Series Operation & Programming Manual static char rxBuf[ 64 ] static void Niread( int pad, char *queryStr ) char cmd[ 4 ]; Niwrite( pad, queryStr ); cmd[ 0 ] = UNL; cmd[ 1 ] = UNT;...

  • Page 187: Run Program

    An Example of Use You can use the following control procedures to run the PROGRAM. <1> PROGram:FILE 1 // Set the PROGRAM FILE to be run <2> PROGram:ACTive 15 // Set the mapping action for Module Channel // chan 1 - chan 8 mapping value weights are // 1, 2, 4, 8, 16, 32, 64,128 <3>...
  • Page 188 www.valuetronics.com...

  • Page 189: Verification

    For the detailed information of operation and programming please refer to the Chapter 3, Chapter 4 and Chapter 5. If the 6310A requires service, refer to the list of Chroma Sales and Support Offices at the web site http://www.chromaate.com/english/contact/default.asp. 10.2 Equipment Required The equipment listed in the following table, or the equivalent to this equipment, is required for verification.
  • Page 190 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Shunt current (DMM Ai): means DMM (I) voltage/shunt resistor 10.3.1.1 Check the High Current Range Connect the Load, DC source, DMM, current shunt as Figure 10-1 shows. Use DMM (I) to measure the voltage across the shunt resistor measurement port, and get the load current.
  • Page 191 Verification To set output voltage of DC source and CCH current in the Table 10-3 for testing model. Press LOAD ON/OFF to enable the load and slowly decrease the dc source voltage until DMM(V) display reached minimal operation voltage of the Table 10-3 for testing model.
  • Page 192 Programmable DC Electronic Load 6310A Series Operation & Programming Manual Table 10-4 Model CCL Current Shunt Current Front Panel Display Name Setting Reading Max. Min. 4.0 A 4.008 A 3.992 A DMM Ai ± 0.004 A 63101A 0.04 A 0.04404 A 0.03596 A DMM Ai ±...

  • Page 193: Cr Mode Verification

    Verification 10.3.2 CR Mode Verification This test verifies if the resistance programming is within specifications when the module is operating in the CR mode. The programmed resistance is calculated from the voltage divided by current. The voltage (DMM (V)) is across the module’s input terminal or measurement terminal.
  • Page 194 Programmable DC Electronic Load 6310A Series Operation & Programming Manual 2.000 Ω CRH1: 1.000 Ω CRH2: Set the DC source to 10V for the model: 63101A, 63102A, 63103A, 63106A, 63107A, 63110A, 63112A, 63113A, 63123A. Set the DC source to 100V for the model: 63105A, 63108A.
  • Page 195 Verification 10.3.2.2 Check the Low ohm Range ▲ or ▼ key to select CRL and then the display shows: Press MODE and use MODE SELECT Press “ENTER” button to select CR low ohm range. CRL1: 2.000Ω CRL2: 1.000Ω Set the DC source to 1V for the model: 63101A, 63102A, 63103A, 63106A, 63107A, 63110A, 63112A, 63113A, 63123A.

  • Page 196: Cv Mode Verification

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 0.03125Ω 0.03232Ω 0.03025Ω 0.0625Ω 0.06635Ω 0.05907Ω 0.2 Ω 0.2008 Ω 0.1992 Ω 63113A 1 Ω 1.0225 Ω 0.9785 Ω 2 Ω 2.0833 Ω 1.9231 Ω 0.015 Ω 0.01517 Ω 0.01484 Ω...
  • Page 197 Verification CV RESPONSE 1:FAST 2:SLO W Set the DC source to 80V/0.1A for model 63101A, 63102A, 63103A, 63106A, 63107A, 63112A and 63123A, 500V/0.1A for model 63105A, 63108A, 63110A, 300V/0.1A for model 63113A, also 120V/0.1A for model 63123A. G. After pressed the button LOAD ON/OFF to enable load on and waited for 30 seconds, record the voltage across the load input terminal.

  • Page 198: Dynamic And Slew Rate Circuit Test

    Programmable DC Electronic Load 6310A Series Operation & Programming Manual 10.3.4 Dynamic and Slew Rate Circuit Test This test verifies the slew rate circuit operation and the dynamic current waveform period specifications when the module dynamic is operating in CC mode.
  • Page 199 Verification MODE SELECT CCDH Press “ENTER” button to select CCDH range. The LCD shows below: CCDH1: 0.000A CCDH2: 0.000A Turn on the DC source and set output voltage 5V. Set current limit of DC source larger than the set current of Table 10-4. Table 10-10 shows the setting values of each model. Table 10-10 Model CCDH1...
  • Page 200 Kuei-shan Hwaya Technology Park Taoyuan County 33383, Taiwan 33383 台灣桃園縣龜山鄉 華亞科技園區華亞一路 66 號 T +886-3-327-9999 F +886-3-327-8898 Mail: info@chromaate.com http://www.chromaate.com Copyright by CHROMA ATE INC. All Rights Reserved. All other trade names referenced are the properties of their respective companies. www.valuetronics.com...

This manual is also suitable for:

6314a6312a63101a63102a63103a63105a ... Show all

Table of Contents
