Technical Data - Godox TT600S User Manual

Using the Wide Panel
Pull out the built-in wide panel to enlarge the flash lighting range, so as to get more
softened natural lighting effect.
Pull out the wide panel and place it over the flash head as shown. The flash coverage will
then be extended to 14mm.
The catchlight panel will come out at the same time. Push the catchlight back in.
•

Technical Data

Product Model
Guide No. (1/1 power @ 200mm)
Vertical Rotation Angle
Horizontal Rotation Angle
Power Supply
Full Power Flashes
Recycle Time
Flash Duration
Color Temperature
Wireless Flash Function
Controllable save groups
Transmission Range (approx.)
Channel
Dimension
Weight without Battery
Weight with Battery
TT600S
GN 60 (m ISO 100)
-7° -90°
0-360°
Ni-MH batteries (recommended) or 4*LR6
alkaline batteries
Approx. 230
(2500mA Ni-MH Batteries)
Approx. 0.1-2.6 seconds (envelop Ni-MH
batteries of Panasonic)
Red LED indicator will light up when the
flash is ready
1/300s – 1/20000s
5600K±200K
Master, Slave, Off
5 (A, B, C, D, E)
100m
1~32
64*76*190mm
400g
500g
23
