Foreword

Before using this product

Please read this user manual carefully in order to ensure your safety and the proper operation of
this product. Keep for future reference.
Thank you for purchasing a GODOX product.
TT600 camera flash adopts Godox wireless X system and 2.4G ratio transmission, which is
compatible with AD360II-C、 AD360II-N、 TT685C、 TT685N、 X1T-C、 X1T-N, etc. Fit all DSLR camera
brands e.g. Canon, Nikon, Sony, etc.
This TT600 camera flash features:
GN60 (m ISO 100, @200mm). Adjust from 1/1 to 1/128 in 1/3rd stops
Built-in 2.4G wireless transmission to support transmitting and receiving
High speed sync, wireless remote control, multi flash and manual focus assist
Stable consistency and color temperature with good even lighting
User-friendly LCD display & control panel
GODOX PHOTO EQUIPMENT CO.LTD
Camera Flash
TT600

Advertisement

Table of Contents
loading

Related Manuals for Godox TT600

Summary of Contents for Godox TT600

  • Page 1 Keep for future reference. Thank you for purchasing a GODOX product. TT600 camera flash adopts Godox wireless X system and 2.4G ratio transmission, which is compatible with AD360II-C、 AD360II-N、 TT685C、 TT685N、 X1T-C、 X1T-N, etc. Fit all DSLR camera brands e.g.

  • Page 2: For Your Safety

    For Your Safety Always keep this product dry. Do not use in rain or in damp conditions. This product contains high-voltage electronic parts. Touching the high-voltage circuit inside it may result in electric shock. Do not disassemble. Should repairs become necessary, this product must be sent to an authorized maintenance center.
  • Page 3 Control Panel LCD Panel What’s in the Box of TT600? Separately Sold Accessories Attaching to a Camera Using the Flash Power Management Flash Output ZOOM: Setting the Flash Coverage M Mode Multi Mode: Stroboscopic Flash S1 Mode S2 Mode Hi-Speed Sync Triggering...

  • Page 4: Name Of Parts

    Name of Parts Body 01. Catchlight Panel 02. Built-In Wide Panel (Retracted) 03. Flash Head 04. Optic Control Sensor 05. Focus Assist Beam 06. Wireless Control Port 07. Sync Cord Jack 08. Hotshoe 09. Lock Ring 10. Battery Compartment Control Panel 11.
  • Page 5 28. < > Wireless Signal Transmission 29. < > Focus Assist Beam Indicator 30. Channel 31. Group What’s in the Box of TT600? 1-flash unit 1-Mini Stand 1-Protection Case 1-Instruction manual Separately Sold Accessories The product can be used in combination with the following accessories sold separately, so as to...

  • Page 6: Using The Flash

    achieve best photography effects: Cells II high speed trigger, FT-16S power & trigger control, Car charger, Mini softbox, White & Silver Reflector, Honeycomb, Color gels, Snoot, etc. Attaching to a Camera 1. Attach the Camera Flash. Slip the camera flash’s mounting foot into the camera’s hotshoe all the way. 2.
  • Page 7 2. Flash Output Flash output can be varied from 1/128th power to 1/1 full power in 1/3 stop increments. To obtain a correct flash exposure, use a hand-held flash meter to determine the required flash output. Adjust the power output by rotating Select Dial (14). The following table makes it easier to see how the stop changes in terms of f/stop when you increase or decrease the flash output: Figures displayed when reducing flash output level→...
  • Page 8 5. Multi Mode: Stroboscopic Flash Press Mode Selection Button (11) to enter Multi mode (Stroboscopic flash). With stroboscopic flash, a rapid series of flashes is fired. It can be used to capture multiple images of a moving subject in a single photograph. You can set the firing frequency (number of flashes per sec.
  • Page 9 Hz  Flash Output  1/16 1/32 1/64 1/128 12-14 15-19 20-50 60-199 Hz  Flash Output 1/16 1/32 1/64 1/128 To avoid overheating and deteriorating the flash head during stroboscopic flash, do not use stroboscopic flash more than 10 times in succession. 6. S1 Mode: S1 Slave Triggering Mode Long Press <zoom/Fn>...
  • Page 10 2. TTL wireless flash trigger X1C 3. TTL wireless flash trigger X1N *Hi-speed sync triggering mode is not available when TT600 is mounted onto the camera To avoid overheating or deteriorating the flash head during high speed sync flash, the over-temperature protection function will be activated automatically after 10 continuous high-speed flashes and the recycle time becomes 10 seconds longer.
  • Page 11 When the buzzer is turned on, is shown on the LCD display. 11. Wireless Flash Shooting: Ratio (2.4G) Transmission TT600 has 2.4G ratio transmission (Master/Slave) Wireless mode setting: Long press < MODE/ > button and hold for 2 seconds until icon is blinking.
  • Page 12 To control the flash wirelessly, you need a Godox FT series remote control set (on-camera and on-flash). Insert its receive end into the Wireless Control Port (6) on the flash and insert the transmit end into the camera hot shoe.
  • Page 13 14. Custom Function----Sleep Function This product is equipped with Sleep Function to avoid battery drain when the flash unit is idle. Press < > button and hold for 2 seconds to enter the sleep Function Mode. The LCD panel displays “SL” (Sleep) and “Sleeping Time”. Idle time before entering Sleep Mode is 10 minutes by default.
  • Page 14 Time Setting <3> 3 minutes enter Custom Functions. <10> 10 minutes 2. Turn the Select Dial to adjust <30> 30 minutes sleeping time. <60> 60 minutes 3. Press <Zoom/Fn> button to <OF>（OFF） return. *Press any button can wake up the flash.
  • Page 15 return. Backlight Backlight can be set as follows： 1. Press <Zoom/Fn> button to Setting <ON>：Always lighting enter Custom Functions. <12>：Off in 12 sec. 2. Press SET button to enter bL <OF>：Off states. 3. Turn the Select Dial to adjust. 4. Press <Zoom/Fn> button to return.
  • Page 16 about 10 to 15 seconds. If this occurs, allow a rest time of about 10 minutes, and the flash unit will then return to normal. When the over-temperature protection is started, is shown on the LCD display. Number of flashes that will activate over-temperature protection: Power Output Level Number of Flashes 1/2 +0.7...
  • Page 17 1/128（+0.3,+0.7）; 2. Other Protections The system provides real-time protection to secure the device and your safety. The following lists prompts for your reference: Prompts on LCD Panel Meaning A failure occurs on the temperature sensor. Please send this kit to a maintenance center. A failure occurs on the recycling system so that the flash cannot fire.

  • Page 18: Technical Data

    Technical Data Product Model TT600 GN60 (m ISO 100) Guide No. (1/1 power @ 200mm) Vertical Rotation Angle -7° to 90° Horizontal Rotation Angle 0 to 360° Power Supply Ni-MH batteries (recommended) or 4*LR6 alkaline batteries Full Power Flashes Approx.
  • Page 19 -It is normal for the flash tube to be warm when in use. Avoid continuous flashes if unnecessary. -Maintenance of the flash must be performed by our authorized maintenance department which can provide original accessories. -This product, except consumables e.g. flash tube, is supported with a one-year warranty. -Unauthorized service will void the warranty.
  • Page 20 guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna.
