Spitzer LIGHTING DOWNLIGHT Series Instruction Manual

DOWNLIGHT SERIES
SLIM CANLESS SWIVEL DOWNLIGHT
PRODUCT PARAMETER
INPUT VOLTAGE 120V
DIMMING TRIAC
MATERIAL DIE-CAST METAL
PRE - INSTALLATION
Please read and understand all instructions before operate or install the product.
Failure to do so may lead to electric shock, fire or other injuries that could be
hazardous or even fatal.
- Shut off the electricity to the wires that you are working on
- Do NOT open, no user serviceable parts inside. Any changes or modifications
and applications not expressly approved by the manufacturer could void the user's
authority to operate the equipment and warranty
INSTALLATION (Caution: Before beginning installation turn off the circuit breaker and light switch)
4" MODEL
A
B Junction box with connector
www.spitzerlighting.com
I N S T A L L A T I O N M A N U A L
BE SURE THE POWER IS OFF! RISK OF ELECTRICAL SHOCK: Always use the switch to power off. Do not perform
any operations while this unit is powered on. The electrical system you want to connect the device to must be
grounded. Read the instructions before using or powering this device. The safety instructions must remain with
the unit in case of transfer. Any damage to the device linked to an inappropriate use is excluded from support by
the warranty. Before connecting, make sure that the current and voltage are compatible with this device. We highly
recommend that all installations are made by QUALIFIED ELECTRICIAN. We are NOT responsible by any means for
the use or misuse of the following information. We are NOT responsible in whole or part for any harm or damage
that may or may not be caused. We reserve the right to revise the components of any product, due to part availability
or change ETL, CUL, UL standards without assuming any obligation or liability to modify any products previously
manufactured and without notice. These instructions do not cover all details of variations in equipment, nor do they
provide every possible contingency to be met. Turn off / unplug power when installing or service device.
WARNING: Read all safety precautions and installation instructions carefully before installing or servicing this
fixture. Failure to comply with these instructions could result in a potentially fatal electric shock, fire, and/or
property damage.
• Risk of fire or electrical shock
ꞏ LED retrofit kit installation requires knowledge of luminaires electrical systems. Do NOT attempt installation if not
qualified. Contact a qualified electrician
ꞏ Install this kit only in the luminaires that have the construction features and dimensions shown in the photographs
and/or drawings
ꞏ Do NOT exceed the input rating of the luminaire
ꞏ Do NOT make or alter any open holes in an enclosure of wiring or electrical components during installation
ꞏ To prevent wiring damage or abrasion, do NOT expose wiring to edges of sheet metal or other sharp objects
ꞏ This device is not intended for use with emergency exits
ꞏ This luminaire has been modified to operation LED lamp. Do NOT attempt to install or operate incandescent lamps
or CFL in this luminaire
ꞏ This retrofit kit is accepted as a component of a luminaire where the suitability of the combination shall be
determined by authorities having jurisdiction
- Connect fixture to a 120 Volt, 60 Hz power source only. Any other connection void the warranty
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interface received, including
interference that may cause undesired operation. This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on. The user is encouraged to try to correct the
inference by one or more of the following measures:
- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and the receiver
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
PACKAGE CONTENTS
PARTS QT
4" Lamp 1
1
702 Interchange Blvd., Newark, DE 19711
SAFETY INFORMATION
WARNING
CAUTION
6" MODEL
PARTS
A 6" Lamp
B Junction box with connector
Specification is subject to change without notice
QT
1
1
1/2
