- Page 1 M-131-07R Supersedes M-131-07 Black-Topper ® CENTENNIAL Series, S-2000 Series Updates & Service Material...
-
Page 2: Table Of Contents
12 Volt Relay in Rear Control Box without Spray Delay Switch ........25 Warning - Fluoroelastomer Handling..2 Solenoid Valve Coils with built-in Diodes ..26 Etnyre Spraybar Nozzles ......3 Electronic Temperature Probe - DC-2 Com- Adjusting the Spray Bar Nozzles ....4 puter ............27... -
Page 3: Cationic Emulsion Notice
Cationic Emulsion Notice Certain Cationic Emulsions are known to be corrosive to carbon steel, aluminum, and even some grades of stainless steel. Hydrocloric acid is often used in cationic emulsions to produce the electronic charge that makes the emulsion cationic. Cationic emulsions may be identified by the “C” at the beginning of the product name or identification number, such as “CRS-2”... -
Page 4: Etnyre Spraybar Nozzles
Etnyre Spraybar Nozzles Ref. Part No. Description Application Application Flow Gallons (Metric) Liters Per Gallons Per Per Square Yard Square Meter Minute Per Foot 3353788 V Slot Tack Nozzle .05 – .20 .19 – .75 3.0 to 3351008 S36-4 V Slot .10 –... -
Page 5: Adjusting The Spray Bar Nozzles
Adjusting the Spray Bar Nozzles Adjusting the Spray Bar Nozzle Angle WARNING Adjust the nozzles to obtain an angle of To prevent possible burns from hot asphalt approximately 30 degrees with the spraybar spray: Do not stand, or allow anyone to centerline. -
Page 6: Filling From Supply (Loading)
Filling from Supply (Loading) Centennial Flow Diagram... -
Page 7: Circulate In Tank
Circulate In Tank Centennial Flow Diagram... -
Page 8: Circulate In Bar
Circulate In Bar Centennial Flow Diagram... -
Page 9: Spraying
Spraying Centennial Flow Diagram... -
Page 10: Suckback Spraybar
Suckback Spraybar Centennial Flow Diagram... -
Page 11: Handspray
Handspray Centennial Flow Diagram... -
Page 12: Suckback Handspray
Suckback Handspray Centennial Flow Diagram... -
Page 13: Pump Off
Pump Off Centennial Flow Diagram... -
Page 14: Transfer
Transfer Centennial Flow Diagram... -
Page 15: Flushing
Flushing Centennial Flow Diagram... -
Page 16: Start Up Factor
Start Up Factor The Start Up Factor screen looks like this: You can get to the start up factor screen by pushing the "change display" button on the control panel and stepping through the GPM/FPM screen, the feet and gallons traveled screen, and the temperature screen. -
Page 17: Dc2 Self Diagnostics
DC2 Self Diagnostics DC2 Self Diagnostics Low Battery Voltage The DC2 is equipped with a self diagnostics Indicates that the truck’s voltage has dropped system that may display messages on the LCD. below 9 VDC. Inspect the truck power supply or Some of the more common messages are the voltage to the DC2 Controller. - Page 18 Electronic Controls The signal is sent from the pot to the EDC. Measure the signal from the pots to the EDC with The DC2 is a blue, notebook sized, self- an amp meter. Connect the amp meter leads to contained electronic control module located the red and black wires at the pump stroker on under or behind the operator’s seat.
-
Page 19: Checking: Dc-2 Computer Edc Threshold
Checking: DC-2 Computer EDC Threshold Threshold is determined by how many milliamps it takes to put the hydraulic pump on stroke. a) Disconnect red wire from center terminal post of front / rear asphalt pump control switch (located in rear control panel). b) Attach multi-meter leads (in series) to read DC milliamps. -
Page 20: Speed Sensor Repair Kit
Speed Sensor Repair Kit Part # 7050221 Instructions to change speed SELECTOR Before (BROWN,BLACK. sensor from 12V to 5V controlled SWITCH BROWN, GOLD) 6701976 voltage for all distributors AT REAR 6702033 6701911 1. Turn off power. TERMINAL STRIP 2. Disconnect 30 pin connector from IN CAB PUMP computer. -
Page 21: Tach Calibration
Tach Calibration Instructions for calibrating pump speed for units with 309 pulses per gallon only (hydraulic motor #6603157 with 4.39 to 1 ratio gearbox). For coarse calibration: Setting Hex Wrench “8” Using 5/64 inch Select setting 8 or 2 mm hex on back of wrench turn pump tach. -
Page 22: Wiring - Radar And Pump Tach
Wiring - Radar and Pump Tach Pump Tachometer 6702135 80 Tooth Gear Black Magnetic Pick-up on Pump 6701838 at Pump 12VDC Capacitor 1 UF 100 VDC 6702143 White 1K OHM Resistor Digital Cable Connector 6701540 Counter 6701048 6701510 6702140 1/16" Max. Radar Tachometer Black... -
Page 23: Dickey Johns Radar Wiring Diagram - Kit, Radar Analog 7510025
Dickey Johns Radar Wiring Diagram - Kit, Radar Analog 7510025 Power Wire 12VDC Switch SPDT #3160005 Master Spray Momentary Switch (6700161) Bar On/Off *6702082 Solenoild Valve WHITE POWER 12VDC BLACK To Digital WHITE Counter From Radar GREEN Speed Sensor BLACK GREEN/WHITE Relay #6702017, Mtg Plate #6702018, Latching Relay, Place in Electric Air Control... -
Page 24: 12 Volt Power Supply
12 Volt Power Supply Black Marker Red 10 Gauge (tape) with Yellow Connector Master Front Power Control Switch Red 10 Gauge Red 10 Gauge Red 10 Gauge Terminal Strip Rear Control Master Power Switch Black Marker (tape) -
Page 25: Volt Power Supply Centennial With New Style Wiring Harness
12 Volt Power Supply Centennial with new style wiring harness Red 10 Gauge with Yellow Connector Master Front Power Control Switch Green 10 Gauge Red 10 Gauge White 10 Gauge Terminal Strip Rear Control Master Power Switch... -
Page 26: Volt Relay In Rear Control Box Without Spray Delay Switch
12 Volt Relay in Rear Control Box without Spray Delay Switch Left Side Right Side Mercury Mercury Switch Switch Black Black In Rear Control Box MAC Valves MAC Valves Black Black Black Black Relay Left Side Right Side Air Valves Air Valves Terminal Strip Computer... -
Page 27: Solenoid Valve Coils With Built-In Diodes
Solenoid Valve Coils with built-in Diodes Solenoid valve coils made with built-in diodes suppress electronic noise which can interfere with computer controls. These solenoids on Deltrol valves can be identified by the fact that the spade terminals on the coil are not the same size. The larger, 1/4 inch spade must be used for the ground and the smaller, 3/16 inch spade must be used for the power or hot lead. -
Page 28: Electronic Temperature Probe - Dc-2 Com
Electronic Temperature Probe DC-2 Computer Printed Circuit Board Inside Cab Control Box Disconnect wires and measure resistance between Red and Black Black wires at terminals #5 and #6. Resistance should match chart for temperatures shown. A loose connection (or broken wire) at the probe will make for increased resistance and higher temperature reading. -
Page 29: Temperature Conversion - Resistance Of Rtd Temperature Probe - Omega Pr-14-2- 100-1/4-9-E 3370234
Temperature Conversion - Resistance of RTD Temperature Probe Omega PR-14-2-100-1/4-9-E 3370234... -
Page 30: Radio Frequency Interference Filter Installation
Radio Frequency Interference Filter Installation Gather together some slack from the magnetic pick up cable. Unfold the filter case and wrap the slack cable through the filter forming five loops. Close the filter case and tie it shut with a wire or tape. -
Page 31: Wiring Schematic - Fuel Oil Burners With Built-In Fuses
Wiring Schematic – Fuel Oil Burners with Built-In Fuses WIRING DIAGRAM WITH PRIMARY CONTROL (1) BURNER SHOWN BLOWER REAR SWITCH MASTER 6701966 POWER 6700255 SWITCH 10 GA. WIRE +12V FROM 25A FUSE IGNITOR VALVE RELAY 6702014 CAD CEL BLACK MOTOR DC PRIMARY CONTROL #7350 BLACK 14 GA. -
Page 32: Wiring Schematic - Fuel Oil Burners With External Fuses
Wiring Schematic – Fuel Oil Burners with External Fuses WIRING DIAGRAM WITH PRIMARY CONTROL (1) BURNER SHOWN BURNER REAR SWITCH MASTER 6701966 POWER 6700255 SWITCH 10 GA. WIRE +12V FROM 25A FUSE ALARM IGNITOR VALVE RELAY 6702014 CAD CEL BLACK MOTOR DC PRIMARY CONTROL #7350 30 AMP... -
Page 33: Beckett Fuel Oil Burner Instruction Manual
Beckett Fuel Oil Burner Instruction Manual... -
Page 38: Way Valve Rotary Actuator Modification
4 Way Valve Rotary Actuator Modification 4 Way Valve Spray Actuator 4 Way Valve Actuator Mac Valve Wiring - Circulate in Tank - Circulate in Bar To 4 Way Actuator 6603023 4 Way Valve Rotary Actuator 0219189 1/4 NPT Pipe Plug (2) Required 0144035 1/4 x 1/8 NPT Bushing... -
Page 39: Installation Of Actuators
Installation of Actuators 4-Way Valve 1st Actuator 2nd Actuator To "B" Port Of Mac Valve To "A" Port Of Mac Valve Rear of distributor To "B" Port Of Mac Valve To "A" Port Of Mac Valve 2nd Actuator 4-Way Valve 1st Actuator (viewed from rear) (viewed from rear) -
Page 40: Way Valve Modification
4 Way Valve Modification Extension Shaft Packing (3) Insert Washer Here 3340029 Pump Packing (3) Required 0197070 1 3/8 in. Washer (1) Required Install all needed parts shown: a) Loosen set screw on Extension Shaft and slide shaft back far enough to allow removal of lock nuts from 4 Way valve shaft. -
Page 41: Asphalt Pump Shaft Seal Installation Tool (3321447)
Asphalt Pump Shaft Seal Installation Tool (3321447) Required to install (new style) Seal #6420231... -
Page 42: Instructions For Installing (6445090) Shaft Coupling Between Asphalt Pump And Gearbox On Centennial Distributors
Instructions for installing (6445090) Shaft Coupling between Asphalt Pump and Gearbox on Centennial Distributors 1. Coat all coupling bolts with anti-seize before installing. 2. Align the asphalt pump shaft keyway to top dead center. 3. Install shaft key in asphalt pump shaft. 4. -
Page 43: Ball Case Screw Tightening Procedure
Ball Case Screw Tightening Procedure Torque 55 Ft. Lb. ± 2 Ft. Lb. NOTE: Torque All Ball Case Screws to 55 Ft. Lb. ± 2 Ft. Lb. -
Page 44: Ball Joint Tightening And Locking
Prime both threads with Loctite Primer "N" (Etnyre #6800030). Allow to dry for three to five minutes. Apply four beads of Loctite "272" thread locker (Etnyre #6800047), about 1/8" wide, equally spaced, to the male threads as shown below. Grease the ball liberally on the surface that contacts the case, o-ring and nut with chiksaw #11 high temperature grease. -
Page 45: Heavy Duty Bar Raise
Heavy Duty Bar Raise Aluminum Solenoid Block in Tool Box Relief B 700 PSI Relief A 400 PSI Cylinder B Cylinder A Left Right 3" " When lifting bars, if cylinder "B" bottoms before Cylinder "A", Relief "A" will pop taking pressure off of Cylinder "B".
