PR-4000 Assembly Instructions
Hardware Included:
M16x110 Bolt, Washers, Nut -
x 5 6
1.
Attach horizontal connecting braces to top
and bottom of each pair of uprights.
x 16
(M16x110)
x 32
x 16
Any issues? Please contact us directly by phone: 720-420-1731, email: info@repfitness.com or
morse code...(.-. . .--. ..-. .. - -. . ... ...). We are always here for our Customers! - Team REP
Parts Included:
Rack:
4 Uprights
4 Horizontal Connecting Braces
Top Horizontal Name Plate Bracet
Multi-Grip Pullup Bar
2 J-Cups
2.
Connect the horizontal brace with name
This is the last step for
assembling the main rack
Denver, CO
Weight Storage Attachment:
2 Uprights
4 Short Horizontal Connecting Braces
6 Long Weight Horns
6 Short Weight Horns
plate and pullup bar.
x 8
(M16x110)
x 16
x 8
Advertisement
Table of Contents
Related Manuals for REP PR-4000
Summary of Contents for REP PR-4000
- Page 1 This is the last step for assembling the main rack Any issues? Please contact us directly by phone: 720-420-1731, email: info@repfitness.com or morse code...(.-. . .--. ..-. .. - -. . … …). We are always here for our Customers! - Team REP...
- Page 2 Adding Weight Storage: Attach short horizontal connecting braces to top and bottom of the back uprights of the rack and the weight storage uprights. (M16x110) x 16 Attach weight horns and secure j-cups at desired height. x 24 (M16x110) x 48 x 24 Use the same bolt used to secure the front connecting brace on the other side...
