ASSEMBLY INSTRUCTIONS
1X (6MM) ALLEN KEY INCLUDED
NOT INCLUDED
1X 14mm WRENCH
2X 17mm WRENCH
1X 19mm WRENCH
2X 24mm WRENCH
NOTE: DO NOT FULLY TIGHTEN
UNTIL FINISHED WITH STEP 10
STILL NEED HELP WITH ASSEMBLY?
V I S I T O U R A S S E M B LY L I B R A R Y H E R E :
H E L P. R E P F I T N E S S . C O M
W W W . R E P F I T N E S S . C O M
45-0102-A
