Summary of Contents for REP PRA-5702
- Page 1 ASSEMBLY INSTRUCTIONS PRA-5702 & PRA 5702-S CABLE REPLACEMENT GUIDE R E P F I T N E S S W W W . . C O M...
-
Page 2: Hardware And Tools
SAFETY • ASSEMBLY BY TWO PEOPLE IS STRONGLY ENCOURAGED FOR SAFETY. • A LADDER OR STEP-STOOL IS RECOMMENDED FOR EASE OF INSTALL. • THIS PRODUCT MUST BE ASSEMBLED ON A FLAT, LEVEL SURFACE TO FUNCTION PROPERLY. • KEEP HANDS, CLOTHING, HAIR, AND OTHER BODY PARTS AWAY FROM CABLE AND PULLEYS DURING OPERATION. - Page 3 CABLE ROUTING AND ANCHORING IS IDENTICAL FOR BOTH SELECTORIZED AND PLATE-LOADED ASSEMBLIES R E P F I T N E S S W W W . . C O M...
- Page 4 USEFUL TIPS TO GET STARTED 1. REMOVE ALL CABLE-END ATTACHMENTS AND DESELECT OR REMOVE ALL WEIGHTS 2. RELIEVE TENSION IN THE UPPER CABLE BY LIFTING THE HEADPLATE AND INSERTING THE PIN IN A LOWER WEIGHT PLATE AS SHOWN BELOW R E P F I T N E S S W W W .
- Page 5 LOWER CABLE REMOVAL DETATCH CARABINER FROM CHAIN LINK ANCHOR (B), THEN REMOVE CARABINER FROM CABLE EYE (A) TIP: PULL DOWN ON CABLE TO GIVE SLACK R E P F I T N E S S W W W . . C O M...
- Page 6 ROUTE CABLE OUT OF THE FLOATING PULLEY R E P F I T N E S S W W W . . C O M...
- Page 7 REMOVE LOWER CABLE FROM THE LOW-ROW ASSEMBLY R E P F I T N E S S W W W . . C O M...
- Page 8 19MM 1X NOT INCLUDED UPPER CABLE REMOVAL REMOVE ANCHOR BOLT FROM TOP OF WEIGHT STACK OR PLATE TROLLEY R E P F I T N E S S W W W . . C O M...
- Page 9 17MM 2X NOT INCLUDED REMOVE PULLEY WHEELS (B THEN A) AND ROUTE CABLE OUT THROUGH FLOATING PULLEY AND THEN REMOVE FROM THE LAT PULLDOWN ATTACHMENT R E P F I T N E S S W W W . . C O M...
- Page 10 17MM 2X NOT INCLUDED UPPER CABLE INSTALL INSERT CABLE BOLT-END FIRST THROUGH FRONT OF LAT PULLDOWN ATTACHMENT AND THEN FOLLOW 25-0767 - 80” THE ROUTING DIAGRAM 25-0768 - 93” REATTACH PULLEY A, ROUTE CABLE THROUGH THE FLOATING PULLEY, AND THEN REATTACH PULLEY B R E P F I T N E S S W W W .
- Page 11 19MM 1X NOT INCLUDED INSTALL ANCHOR BOLT TO TOP OF WEIGHT STACK OR PLATE TROLLEY (A) ONCE ANCHOR BOLT IS INSTALLED, REMOVE PIN AND RETURN HEADPLATE TO HOME POSITION (B), THEN ADJUST CABLE TENSION VIA BOLT AS NECESSARY R E P F I T N E S S W W W .
- Page 12 LOWER CABLE INSTALL INSERT CABLE EYE-END THROUGH THE LOW-ROW 25-0767 - 80” ASSEMBLY 25-0768 - 93” R E P F I T N E S S W W W . . C O M...
- Page 13 ROUTE CABLE THROUGH THE FLOATING PULLEY R E P F I T N E S S W W W . . C O M...
- Page 14 ATTACH CARABINER TO CABLE EYE (A) THEN ATTACH TO CHAIN LINK ANCHOR (B) TIP: PULL DOWN ON CABLE TO GIVE SLACK R E P F I T N E S S W W W . . C O M...
-
Page 15: Maintenance
MAINTENANCE 1. GUIDE RODS: CLEAN THE GUIDE RODS AND REAPPLY SILICONE SPRAY TO THE GUIDE RODS EVERY 3 MONTHS. 2. CABLE TENSION: APPLY PROPER TENSION TO THE CABLE BY TIGHTENING THE ADJUSTER BOLT UNTIL THE HEADPLATE STARTS TO FLOAT, THEN REVERSE ONE-QUARTER TURN UNTIL IT RESTS GENTLY ON THE BELOW PLATE.
