- Page 1 ASSEMBLY INSTRUCTIONS UPGRADE SET PRA-FT-DUAL-5002/4002-S STILL NEED HELP WITH ASSEMBLY? VISIT OUR ASSEMBLY LIBRARY HERE: HELP.REPFITNESS.COM R E P F I T N E S S 45-003291-V2 W W W . . C O M...
-
Page 2: Parts List
PARTS LIST 4000 SERIES 5000 SERIES 24 MM WRENCH 36 MM WRENCH 2X REQUIRED 2X REQUIRED 17 MM WRENCH 2X REQUIRED 8 MM 4 MM 6 MM 1X REQUIRED 1X REQUIRED 1X REQUIRED 40-0118 25-0308 STICKER SET 10LB WEIGHT STEP 11 STEP 1 IF YOU ARE MISSING ANY PARTS, OR OTHERWISE STOP... - Page 3 NOTE: LOOSEN JAM NUT, THEN REMOVE ADJUSTER BOLT R E P F I T N E S S W W W . . C O M...
- Page 4 17 MM WRENCH 6 MM 1X REQUIRED 2X REQUIRED SAVE HARDWARE FOR LATER USE R E P F I T N E S S W W W . . C O M...
- Page 5 4000 SERIES 5000 SERIES 24 MM WRENCH 36 MM WRENCH 2X REQUIRED 2X REQUIRED SAVE HARDWARE FOR LATER USE R E P F I T N E S S W W W . . C O M...
- Page 6 8 MM 1X REQUIRED SAVE HARDWARE FOR LATER USE R E P F I T N E S S W W W . . C O M...
- Page 7 REPEAT STEPS ON OPPOSITE SIDE R E P F I T N E S S W W W . . C O M...
- Page 8 R E P F I T N E S S W W W . . C O M...
- Page 9 R E P F I T N E S S W W W . . C O M...
- Page 10 17 MM WRENCH 2X REQUIRED R E P F I T N E S S W W W . . C O M...
- Page 11 SAVE HARDWARE FOR LATER USE R E P F I T N E S S W W W . . C O M...
- Page 12 15-2090 - 80”, 15-1967 - 93” 4 MM GUIDE ROD 1X REQUIRED 10-0294 SET SCREW COLLAR, 10-0527 RUBBER DAMPER 25-1891 25-0308 25-2019 15-1966 10-0225 ADD-ON WEIGHT RUBBER STOP 10LB WEIGHT GUIDE ROD BRACKET HEADPLATE NOTE: DISCARD 10-0527 THE SPACERS 10-0294 NOT USED 25-2019 10-0527...
- Page 13 8 MM 1X REQUIRED 10-0418 WASHER, FLAT BLACK 10-0773 BOLT, BUTTON HEAD HEX DRIVE 10-0464 WASHER, SPLITLOCK BLACK M12X1.50, L100 BLACK R E P F I T N E S S W W W . . C O M...
- Page 14 TIGHTEN SET SCREW R E P F I T N E S S W W W . . C O M...
- Page 15 4000 SERIES 5000 SERIES 24 MM WRENCH 36 MM WRENCH 2X REQUIRED 2X REQUIRED 10-0315 10-0024 NUT, HEX DRIVE, NUT, HEX DRIVE, M24X3.00 NYLON INSERT PR-5000 - 15-1972 M16X2.00 PR-4000 - 15-2060 SHROUD, BOTTOM 10-0026 10-0030 FRONT, RIGHT WASHER, FLAT, BOLT, HEX DRIVE, 10-0057 10-0023...
- Page 16 4000 SERIES 5000 SERIES 24 MM WRENCH 36 MM WRENCH 2X REQUIRED 2X REQUIRED 10-0315 10-0024 NUT, HEX DRIVE, NUT, HEX DRIVE, M24X3.00 NYLON INSERT PR-5000 - 15-1971 M16X2.00 PR-4000 - 15-2061 SHROUD, BOTTOM 10-0026 10-0030 FRONT, LEFT WASHER, FLAT, BOLT, HEX DRIVE, 10-0023 10-0057...
- Page 17 17 MM WRENCH 6 MM 1X REQUIRED 2X REQUIRED 10-0815 10-0020 25-1511 BOLT, SHCS, NUT, HEX DRIVE, PULLEY M10X1.5, L40 M10X1.50 ENSURE CABLE IS ROUTED AROUND PULLEY R E P F I T N E S S W W W . .
- Page 18 17 MM WRENCH 2X REQUIRED 10-0420 25-2090 BOLT, HEX DRIVE SHROUD, BOTTOM BLACK FRONT, CENTER M10X1.50, L90 R E P F I T N E S S W W W . . C O M...
- Page 19 25-2181 10-0065 20-0240 RETAINING DOWEL CARABINER HANDLE R E P F I T N E S S W W W . . C O M...
- Page 20 15-1951 FOOTPLATE R E P F I T N E S S W W W . . C O M...
- Page 21 IF EITHER HEADPLATE IS NOT AT THE TARGET FLOAT, LOOSEN/TIGHTEN THE ADJUSTER BOLT ON THE TROLLEY UNTIL THE HEADPLATE REACHES THE TARGET FLOAT. NOTE: MINIMUM ADJUSTER BOLT ENGAGEMENT IS 10 FULL TURNS. AFTER ADJUSTING ADJUSTER BOLT, TIGHTEN JAM NUT TO THE BOTTOM IF THE TARGET FLOAT CANNOT BE ACHIEVED, CONFIRM THE CABLE ROUTING IS CORRECT AND THAT ALL COMPONENTS FIT TIGHTLY TOGETHER.
- Page 22 40-0118 STICKER SET 11.3 13.6 15.9 18.1 20.4 22.7 24.9 27.2 29.5 31.8 34.0 36.3 38.6 40.8 R E P F I T N E S S W W W . . C O M...
