PowerTouch 914
By TouchTronics, Inc.
Please r ead entire instruction manual prior to starting the
PowerTouch Remote Contr ol System Installation.
Special Fe atures and Applicatio ns
Flexibility
Installer can select polarity of voltage outputs on all channels.
Power
All four outputs are 5 amp, switched rela ys.
Compact
Receiver is small and easy to install.
Optional Transmitters
Large, oval transmitters with lar ge buttons can be ordered.
Pr ogram Options
Two channels can be programmed as latching, On - Of f
Channel 2 can be programmed with a 2-second courtesy light delay
Standard 4 Channels
Two and four channel transmitters are interchangeable.
Range
Typical antenna range is 60-feet.
57315 Nagy Dr
Elkhart, IN 46517
914 PowerTouch Remote Control Receiver
With Two (4 button) Key Chain Transmitters
Two (two button) Key Chain T ransmitters
www.touchtronics.com
NST13308-P914_A
2020-06-10
Also showing optional:
And Oval Transmitter
Page 1
800-294-2570
574-294-2570
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for TouchTronics PowerTouch 914
Summary of Contents for TouchTronics PowerTouch 914
- Page 1 PowerTouch 914 By TouchTronics, Inc. 914 PowerTouch Remote Control Receiver With Two (4 button) Key Chain Transmitters Also showing optional: Two (two button) Key Chain T ransmitters And Oval Transmitter Please r ead entire instruction manual prior to starting the PowerTouch Remote Contr ol System Installation.
- Page 2 To Clean Grounding Pad: Scraper , Sand Paper, Alcohol Based Cleaner Technical Support V isit the factory website to download a copy of these instructions, e-mail technical questions and see other TouchTronics, Inc. products. Phone / Fax Numbers Indiana Local...
-
Page 3: Component Parts List
Component Parts List 1 pc 914r RF Receiver , 4 Channel w/9” antenna wire 1 set 914h Harness - 10 wire, 9” 2 pcs 914T4 Transmitter , 4 button key chain style Optional 914T2 Transmitter , 2 button key chain style Optional 914T4XS Transmitter ,... -
Page 4: Chassis Ground
Installatio n: Plannin g 1) Receiver Output Voltages A) The receiver has four output voltage (channels) which will operate four separate circuits. The output voltage is 12 volts direct current (vdc). The maximum drive current for each of the four output channels is 5 Amps (maximum) . -
Page 5: Installation: E Lectrical Connections
Installation: E lectrical Connections 1) Install Power Connect the Red wire to a constant +12v battery power source. Note: For best performance, run a clean +12v (15A) directly from the battery or a fuse that is NOT supplying any power to motors, lights or any other type of high current device. - Page 6 Installation: S uggested Application Schematics The following schematics ar e for reference only. The installer must verify that the circuit is pr operly wired with the correct gauge of wire, and pr operly fused with the corr ect fuse size and type for the circuit. Vehicle window switches and door lock switches can be designed as a positive pulse, a negative pulse or a reversal rest @ ground circuit.
- Page 7 Installation: M otors Using Re lays, Safety Di sable Switch WARNING! If using any type of motor , such as a window motor , a ramp motor , a door motor , or a winch motor - add a Disable switch to pr e vent the door or window cir cuit from operating when vehicle is in motion.
- Page 8 Installation: Application Schemati cs M ultiple M otors +12v Fused White/Tan Safety Disable Switch Purple Green/Black Yellow/Black Green/Red Ground Yellow/Red Empty Orange Black Empty Typical Curr ent +12v L ogic Fused @ 1 amp Draw is 100mA High Current Ground Window Window Window...
- Page 9 Trouble Shooting Guide - 914 Series Remote Contr Trouble Shooting Guide - 914 Series Remote Control Warning! Use only a voltmeter to check voltage during installation and testing. *Using a test light WILL damage the outputs! Symptom Possible Cause Corrective Action 1.0 No output from one 1.1 No signal from 1.1a Verify that transmitter is sending a signal and...
- Page 10 Trouble Shooting Guide - 914 Series Remote Control Warning! Use only a voltmeter to check voltage during installation and testing. *Using a test light WILL damage the outputs! Symptom Possible Cause Corrective Action 3.0 No power to remote 3.1 Logic ground or 3.1a Check ground (black wire) and power (red control receiver power connection to...
- Page 11 Trouble Shooting Guide - 914 Series Remote Control Symptom Possible Cause Corr ective Action 5.0 Poor range 0’ to 25’ 5.2 Receiver installed in 5.2a Disconnect door and / or ramp motor and (pulsating 0’ to 25’) poor locations such as recheck range.
- Page 12 1 full year from date of purchase or a maximum of 2 years from the date of manufacture. 5) No product will be covered under the TouchTronics Limited W arranty program that has a manufacture date older than 2 years.
