Chapter 2
Onboard LAN (JP11)
NC
ISOLATEB
GND
CD-ROM Audio-in (CN2)
GND
L
R
1
Auxiliary Audio-in (CN3)
Audio Mono-in/out (CN4)
WOL (Wake-on-LAN) Connector (CN5)
USB 0/1 Ports and USB 2/3 Connector (USB1/CN6)
Blue LED Connector (CN17)
10
This function allows you to enable and disable the on board
LAN. You must set the jumper's cap to pins 1-2 to enable or
set pins 2-3 to disable this function.
This connector is used for Add on Card e.g. modem with Mono
In/Out connector
both shows the system's power status. The only difference is that
this one is blue while the other is red LED.
the power indicator LED,
