- Page 1 FLT-09 User Manual Scan for video assembly! V 1.05...
-
Page 2: Table Of Contents
Table of Contents Caution Specifications Dimensional Drawing Components Assembly Operations Troubleshooting Have any queries? Our expert engineers are here to help! sales@progressivedesk.com 1-800-828-9414 progressivedesk.com P a g e | 2... -
Page 3: Caution
Caution Warning Ensure no obstacles are in the desk's path. Ensure the Pinch Point tabletop is not touching any walls. Ensure all cords are Keep hands and appropriate length to accommodate the change in height. fingers clear. Keep children away from electric height-adjustable desks, control units, and handsets. There is a risk of injury and electric shock. -
Page 4: Specifications
Specifications Specification Description Input Voltage 120 VAC, 60 Hz Output Voltage 24 VDC Stroke (Movement) 25.5" Height Range (without tabletop) 23.6" - 49.1" Weight Capacity (load) 330 lbs (110 lbs per leg) No Load Speed 1.57"/s Full Load Speed 1.18"/s Duty Cycle 10% (2 minutes on, 18 minutes off) Operating Noise... -
Page 5: Dimensional Drawing
Dimensional Drawing *Feet and column style may vary slightly P a g e | 5... -
Page 6: Components
Components 4mm Allen Wrench (included) Phillips Head Screwdriver Tape Measure and/or Power Drill Description Feet Side Bracket Frame 1 Frame 2 Center Rail 120° Frame 1 120° Frame 2 M6x14 Machine Screw M6x10 Machine Screw M5x20 Wood Screw M5x16 Wood Screw Remote Extension Cable Control Box... -
Page 7: Assembly
Assembly STEP 1 STEP 3 Attach the 120° Frames (7,8) to one of the Legs (2) as Slide the Side Brackets (3) into both Frames (4,5). shown in the picture below. Line up the holes on the Attach the brackets using two M6x14 Machine Screws Leg with the holes on the Frames. - Page 8 Prior to normal operation, please complete a Reset your tabletop. Procedure outlined in the next section. If you have a Progressive Desk tabletop, please use the provided machine screws included with the abletop. Attach the frame to the tabletop using seven of the M5x20 Wood Screws (12).
-
Page 9: Operations
Operations REMOTE BUTTONS Height Display UP - Hold to move table lift up DOWN - Hold to move table lift down Memory Preset 1 Memory Preset 5 MEMORY PRESET PROGRAMMING Memory Preset 3 1. Use the UP or DOWN button to bring the desk to Memory Preset 4 the desired height. - Page 10 Operations REMOTE CONTROL LOCK To Lock Press and hold the M button. The remote height display will show "S-", then it will show the table lift height, and finally it will display "LOC". The remote control buttons are now locked. To Unlock Press and hold the M button until the height display shows the table lift height.
- Page 11 Operations MEMORY PRESET ONE-TOUCH and CONSTANT-TOUCH MODE One-Touch mode is the default setting. The memory preset button may be pressed once without holding and the table lift will move to the desired height. Any button may be pressed to stop movement. Constant-Touch mode requires you to hold the memory preset button until the desired height is reached.
-
Page 12: Troubleshooting
Troubleshooting Problem Description Solution Disconnect and reconnect all cables (Lifting Column, Control Box, AC Connection issue Power, and Remote), then initiate the Reset Procedure. Table lift is not level Ensure weight on table lift is evenly distributed and does not exceed Weight issue table lift limits, then initiate the Reset Procedure.
