  • Page 1 FLT-02 User Manual Scan for video assembly! V 2.02...

  • Page 2: Table Of Contents

    Table of Contents Caution Specifications Dimensional Drawing Components Assembly Reset Procedure Operation Troubleshooting Have any queries? Our expert engineers are here to help! sales@progressivedesk.com 1-800-828-9414 progressivedesk.com P a g e | 2...

  • Page 3: Caution

    Caution Warning Ensure no obstacles are in the desk's path. Ensure the Pinch Point tabletop is not touching any walls. Ensure all cords are Keep hands and appropriate length to accommodate the change in height. fingers clear. Keep children away from electric height-adjustable desks, control units, and handsets. There is a risk of injury and electric shock.

  • Page 4: Specifications

    Specifications Specification Description Input Voltage 120 VAC, 60 Hz Output Voltage 24 VDC Stroke (Movement) 25.5" Height Range (without tabletop) 23.6" - 49.1" Base Width 39.6" minimum - 74" maximum Minimum Tabletop Size 45" x 25" Weight Capacity (load) 270 lbs (135 lbs per leg) No Load Speed 1.57"/s Full Load Speed...

  • Page 5: Dimensional Drawing

    Dimensional Drawing Maximum Width - 72.4" Minimum Width - 43" 0.3" 17.7" 8.2" 10" 10" 22.6" 2" 27.5" *Feet and column style may vary slightly P a g e | 5...

  • Page 6: Components

    Progressive Desk Table Top Included Hardware M6x13 Machine Screw If you purchased a Progressive Desk tabletop, use the machine screws included in the tabletop packaging (#17) instead of the wood screws (#14). Progressive Desk tabletops will have pre-drilled threaded holes for installation.

  • Page 7: Assembly

    Assembly STEP 1: Expand the frame and separate all components Separate control box (7), center rails (5), and frame ends (3,4). STEP 2: Attach the legs to the frame ends Ensure the frame end (4) is positioned as shown. Use the Allen wrench to partially install each machine screw (12) until all screws are inserted before fully tightening.
  • Page 8 Assembly STEP 4: Connect both frame ends using the center rails Ensure the gap is facing inward and is closer to the top edge. Insert center rails (5) to join frame ends (3,4) together. Do not insert or tighten machine screws until Step 8. STEP 5: Install each foot with pre-installed glides Use an Allen wrench to install the foot (2) using 4 machine screws (11).
  • Page 9 Assembly STEP 7: Secure the desk frame & remote to the tabletop Progressive Desk Tabletop If you have a Progressive Desk tabletop, use the machine screws (17) included in the tabletop packaging. Line up the desk frame with the predrilled holes on the underside of the tabletop and insert all machine screw before using the Allen wrench to tighten each machine screw (17).

  • Page 10: Reset Procedure

    Reset Procedure WARNING: During the Reset Procedure, the table lift will retract 7mm below the lowest normal operating height. Please ensure that no obstacles impede this motion of travel. 1. Move the desk frame to the lowest position. (If there is "RST" displayed on the remote, continue to step 3).

  • Page 11: Troubleshooting

    Troubleshooting Troubleshooting Guide Problem Possible Cause Corrective Action Low power mode Press any button on the remote and LED will activate. activated Remote LED is off. Disconnect and reconnect the RJ-45 remote connector. Ensure Connection issue connection is secure and cable is not damaged. Follow "Setting Limit Switches"...
