PROGRESSIVE DESK FLT-02 User Manual

Hide thumbs Also See for FLT-02:

Advertisement

Quick Links

Download this manual
FLT-02
User Manual
Scan for video assembly!
V 2.02

Advertisement

loading
Need help?

Need help?

Do you have a question about the FLT-02 and is the answer not in the manual?

Questions and answers

Related Manuals for PROGRESSIVE DESK FLT-02

Summary of Contents for PROGRESSIVE DESK FLT-02

  • Page 1 FLT-02 User Manual Scan for video assembly! V 2.02...

  • Page 2: Table Of Contents

    Table of Contents Caution Specifications Dimensional Drawing Components Assembly Operations Troubleshooting Have any queries? Our expert engineers are here to help! sales@progressivedesk.com 1-800-828-9414 progressivedesk.com P a g e | 2...

  • Page 3: Caution

    Caution Warning Ensure no obstacles are in the desk's path. Ensure the Pinch Point tabletop is not touching any walls. Ensure all cords are Keep hands and appropriate length to accommodate the change in height. fingers clear. Keep children away from electric height-adjustable desks, control units, and handsets. There is a risk of injury and electric shock.

  • Page 4: Specifications

    Specifications Specification Description Input Voltage 120 VAC, 60 Hz Output Voltage 24 VDC Stroke (Movement) 25.5" Height Range (without tabletop) 23.6" - 49.1" Base Width 39.6" minimum - 74" maximum Minimum Tabletop Size 45" x 25" Weight Capacity (load) 270 lbs (135 lbs per leg) No Load Speed 1.57"/s Full Load Speed...

  • Page 5: Dimensional Drawing

    Dimensional Drawing Maximum Width - 72.4" Minimum Width - 43" 0.3" 17.7" 8.2" 10" 10" 22.6" 2" 27.5" *Feet and column style may vary slightly P a g e | 5...

  • Page 6: Components

    Progressive Desk Table Top Included Hardware M6x13 Machine Screw If you purchased a Progressive Desk tabletop, use the machine screws included in the tabletop packaging (#17) instead of the wood screws (#14). Progressive Desk tabletops will have pre-drilled threaded holes for installation.

  • Page 7: Assembly

    Assembly STEP 1: Expand the frame and separate all components Separate control box (7), center rails (5), and frame ends (3,4). STEP 2: Attach the legs to the frame ends Ensure the frame end (4) is positioned as shown. Use the Allen wrench to partially install each machine screw (12) until all screws are inserted before fully tightening.
  • Page 8 Assembly STEP 4: Connect both frame ends using the center rails Ensure the gap is facing inward and is closer to the top edge. Insert center rails (5) to join frame ends (3,4) together. Do not insert or tighten machine screws until Step 8. STEP 5: Install each foot with pre-installed glides Use an Allen wrench to install the foot (2) using 4 machine screws (11).
  • Page 9 Assembly STEP 7: Secure the desk frame & remote to the tabletop Progressive Desk Tabletop If you have a Progressive Desk tabletop, use the machine screws (17) included in the tabletop packaging. Line up the desk frame with the predrilled holes on the underside of the tabletop and insert all machine screw before using the Allen wrench to tighten each machine screw (17).

  • Page 10: Operations

    Operations REMOTE BUTTONS Height Display UP - Hold to move table lift up DOWN - Hold to move table lift down Memory Preset 1 Memory Preset 5 MEMORY PRESET PROGRAMMING Memory Preset 3 1. Use the UP or DOWN button to bring the desk to Memory Preset 4 the desired height.
  • Page 11 Operations REMOTE CONTROL LOCK To Lock Press and hold the M button. The remote height display will show "S-", then it will show the table lift height, and finally it will display "LOC". The remote control buttons are now locked. To Unlock Press and hold the M button until the height display shows the table lift height.
  • Page 12 Operations MEMORY PRESET ONE-TOUCH and CONSTANT-TOUCH MODE One-Touch mode is the default setting. The memory preset button may be pressed once without holding and the table lift will move to the desired height. Any button may be pressed to stop movement. Constant-Touch mode requires you to hold the memory preset button until the desired height is reached.

  • Page 13: Troubleshooting

    Troubleshooting Problem Description Solution Disconnect and reconnect all cables (Lifting Column, Control Box, AC Connection issue Power, and Remote), then initiate the Reset Procedure. Table lift is not level Ensure weight on table lift is evenly distributed and does not exceed Weight issue table lift limits, then initiate the Reset Procedure.
