For FLEX Mode:
Choose a location for the file that you can access easily from RSLogix 5000
2
(My Documents or Desktop, for example), and then click S
Click OK to close the inRAx Data Type dialog box.
3
NOTE: If you make any changes to your module or PROFIBUS configurations, you will probably
want to create new AOI Rung Import files using this procedure. If you create new files, before you
can import them into your existing application, some of the previously imported controller tags and
ladder logic will need to be manually deleted. For additional information, please see the topic
Changing an Existing Configuration and Importing Changes (page 68).
