As previously indicated in this User Manual the module requires the correct
sample program loaded to the processor for correct initialization and operation. If
the sample program is not correctly setup, then the module might not fully
initialize or allow access to the debug menu through PCB.
As indicated below, it is required to have a sample program loaded in the
processor in order to allow debug menu access through PCB and to be able to
reconfigure the MVI56-PDPMV1 module.
Also, if you observe the MSTR STAT LED as RED or blinking GREEN/RED it
means that an incorrect sample ladder logic was loaded to the processor (not
matching the actual module mode (LEGACY or FLEX).
The following tables will help you to troubleshoot different scenarios and the LED
behavior.

4.2.4 Legacy mode (Use Legacy Mode = Yes)

Scenario
- Module located in slot that is not
configured
OR
- No processor
OR
- Neither sample logics loaded to
processor (LEGACY or FLEX)
LEGACY Ladder loaded to
processor (module is inserted in
configured slot)
FLEX Ladder
Page 168 of 235
Debug Access After Power Up
No
(Waiting for connection to
processor)
Yes
Yes
MVI56-PDPMV1 ♦ ControlLogix Platform
PROFIBUS DPV1 Master
LED Behavior After Power Up
MSTR STAT= OFF
COM STAT=OFF
DBASE STAT=GREEN
TKN HLD= OFF
OK = RED
BP ACT = AMBER
APP STATUS= AMBER
MSTR STAT= GREEN
COM STAT= GREEN or OFF (depends if the
module is communicating with PROFIBUS
slaves)
DBASE STAT= GREEN
TKN HLD= GREEN
OK = GREEN
BP ACT = AMBER
APP STATUS= AMBER
MSTR STAT= GREEN (1sec) /RED (2 secs)
COM STAT= OFF
DBASE STAT= GREEN
TKN HLD= GREEN
OK = GREEN
BP ACT = OFF
APP STATUS= AMBER
