1
Remove the PSoC 5LP Development Kit from the
package.
3
Plug the USB cable into your PC and the USB
communications port (J2).
Note: USB Port J2 is the PSoC device's USB communications
port. USB Port J1 is used for program/debug and requires
the appropriate software drivers to be installed.
5
Insert the PSoC 5LP Development Kit CD.
Install PSoC Creator and the kit software.
®
PSoC
5LP DEVELOPMENT KIT
QUICK START GUIDE
2
Plug the LCD module into port P8.
4
Vary the R56 potentiometer. The voltage
is displayed with 12-bit resolution on the
LCD module.
6
Launch PSoC Creator.
Open the code examples from the Start page.
