(Items in parentheses are Factory Default Settings)
Analysis Mode 1 (FBB)
FBB: First Beam Blocked
FBM: First Beam Made
LBB: Last Beam Made
LBM: Last Beam Made
TBB: Total Beams Blocked
TBM: Total Beams Made
CBB: Contiguous Beams Blocked
CBM: Contiguous Beams Made
Disabled
Analysis Mode 2 (Disabled)
FBB: First Beam Blocked
FBM: First Beam Made
LBB: Last Beam Made
LBM: Last Beam Made
TBB: Total Beams Blocked
TBM: Total Beams Made
CBB: Contiguous Beams Blocked
CBM: Contiguous Beams Made
Disabled
Scan Control Modes (Continuous)
Continuous Scanning
Gate Mode
Host Mode
Scanning Methods (Straight)
Straight Scan
Skip Scan 1
Skip Scan 2
Skip Scan 3
Skip Scan 4
Skip Scan 5
Skip Scan 6
Skip Scan 7
Interlaced (Dither) Scan
Edge Scan
Output 1 Analysis Mode (Disabled)
Disabled
Analysis Mode 1
Analysis Mode 2
Output 1 Set Point – Low (1)
1-384
Output 1 Set Point – High (1)
1-384
Output 1 Hysteresis – Low (0)
0-385
Output 1 Hysteresis – High (2)
0-385
Output 1 Invert (No)
No
Yes
Specifications
Output 2 Analysis Mode (Disabled)
Trigger
Alarm
Disabled
Analysis Mode 1
Analysis Mode 2
Single Scan (No)
No
Yes
Output 2 Set Point – Low (1)
1-384
Output 2 Set Point – High (1)
1-384
Output 2 Hysteresis – Low (0)
0-385
Output 2 Hysteresis – High (2)
0-385
Output 2 Invert (No)
No
Yes
Measurement Mode 1 Result (0)
Measurement Mode 2 Result (0)
Output 1 & 2 Scan Number (1)
1-9
Alignment Status (Unknown)
0: Made
1: Broken
Number of Beams (0)
0-384
Beam Status (0)
0: Broken or not used
1: Made
Blanking Beams (0)
0: Not blanked
1: Blanked
Number of Emitter Beams (0)
0-192
Number of Receiver Beams (0)
0-192
Status of Controller (Unknown)
Unknown
EEPROM error
Controller error
ROM error
Normal
Emitter error
Receiver error
Emitter/receiver mismatch
