Control Module Specifications - Banner A-GAGE MINI-ARRAY MACNXDN-1 Instruction Manual

Specifications
2.2 Control Module with DeviceNet Specifications
DeviceNet Configurations
Output Configurations
Power Requirements*
DeviceNet Power*
Inputs
Discrete (Switched) Outputs
System Programming
System Status Indicators
Network Status Indicator
Construction
Environmental Rating
Operating Conditions
*Application Note
10
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
Vendor code:
Device type:
Product code:
Connection types supported: Explicit Message, Poll, COS
Network address:
Baud rate supported:
MACNXDN-1: Two PNP discrete (switched)
MACPXDN-1: Two NPN discrete (switched)
Controller, emitter and receiver: 16 to 30V dc @ 1.2 A max. (typical: 0.5 A @ 16V dc)
11 to 25V dc - supplied by DeviceNet BUS Network
Sensor input: Emitter and receiver wire in parallel to five terminals.
Gate input: Optically isolated, requires 10 to 30V dc (7.5kΩ impedance) for gate signal
NPN outputs: Open collector NPN transistor rated at 30V dc max., 150 mA max.
PNP outputs: Open collector PNP transistor rated at 30V dc max., 150 mA max.
All discrete outputs:
OFF-state leakage current: < 10 µA @ 30V dc
ON-state saturation voltage: < 1V @ 10 mA and < 1.5V @ 150 mA
Via DeviceNet interface and supplied EDS files.
Output (steady red): Output #1 energized.
Alarm (flashing red): Output #2 energized.
Gate (steady red): Gate input status.
Alignment (steady green): Proper emitter/receiver alignment and a clear, unblocked light screen (ON when
green or green/yellow receiver LEDs are ON.
Diag 1 (green), Diag 2 (red), Diag 3 (red): Used in combination to display System status; see Chapter 5,
Bi-colored (red/green) LED visible on the control module front panel indicates network status:
Steady Green: On-line, connected to master
Flashing Green: On-line, address and baud rate OK
Steady Red: Critical network fault or duplicate node address detected
Flashing Red: Connection timeout
OFF: No network power or off-line
Polycarbonate housing; mounts to flat surface or directly onto 35-mm DIN rail
NEMA 1 (IP20)
Temperature: -20° to +70°C (-4° to 158°F)
Maximum relative humidity: 95% @ 50°C (non-condensing)
The controller must be powered up before the DeviceNet connection in every power-up situation
for proper operation
12 (Banner Corp.)
110
1 (MACNXDN-1)
2 (MACPXDN-1)
0-63 (network configured)
125K, 250K, 500K (network configured)
System Diagnostics for more information.
