USE AND CARE GUIDE
ORLEANS - DOUBLE LOUNGE WITH CUSHION
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
lounge.
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY ORLEANS FRN-801960-L
Summary of Contents for HAMPTON BAY ORLEANS FRN-801960-L
- Page 1 8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM THANK YOU lounge. quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
The frame is warranted to be free of manufacturing defects for two years from the purchase date. If the frame of your furniture fails (ie. broken frame or weld) within 2 years of ownership, Hampton Bay will repair, provide replacement parts, or replace the product at our e warranted against blistering, cracking, or peeling for 2 years from purchase date. -
Page 3: Pre-Assembly
Pre-assembly PLANNING ASSEMBLY Before beginning the assembly of this product, make sure all parts are present. Compare parts with Package Contents and Hardware Included lists. If any part is missing or damaged, do not attempt to assemble the product, and return it to the place of purchase. Assembly requires two people. -
Page 4: Package Contents
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Bed Frame Axle Middle Leg Leg 1 Leg 2 Leg 3 Wheel Bed Cushion... -
Page 5: Assembly
Assembly Attaching three Legs to the Bed Frame Attach Leg 3 (G) and Leg 1 (E) to the Bed Frame (A) by using the Bolt M8x55 (AA) and Small Washers (BB), then use the Allen Key (GG) to secure. Attach the Middle Leg (D) to the Bed Frame (A) by using the Screw M6x40 (EE) then use the Allen Key (GG) to secure. - Page 6 Assembly (continued) Attaching Leg 2 Attach the Leg 2 (F) to the Assembled Bed frame (A), by using the Bolt (AA) and Small Washers (BB), then use the Allen key (GG) to secure. Attaching the Arms to the Bed Frame Attach the Arms (B) to the Assembled Bed frame (A), by using the Bolt M8x65 (CC) and Nut M8 (DD), then use the Allen Key (GG) to secure.
- Page 7 Assembly (continued) Completing the Assembly cushion (I) on the Lounger. Raise or lower the top of the lounger to change the tilt, then place the stop bar in the groove to lock the tilt. This Double Lounge is ready to use now. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 8: Care And Cleaning
Care and Cleaning Always make certain to cover your outdoor wood furniture with waterproof covers when you are not using it. Using covers will protect your furniture from all weather elements and prolong the life of the wood furniture. Do not use plastic covers to protect your furniture as this may cause mold to grow on your furniture. - Page 9 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. Factory double lounge ID # HUC26209...
