USE AND CARE GUIDE
ORLEANS - LOUNGE WITH CUSHION
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
lounge.
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Related Manuals for HAMPTON BAY ORLEANS FRN-801960-CL
Summary of Contents for HAMPTON BAY ORLEANS FRN-801960-CL
- Page 1 8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM THANK YOU lounge. quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
The frame is warranted to be free of manufacturing defects for two years from the purchase date. If the frame of your furniture fails (ie. broken frame or weld) within 2 years of ownership, Hampton Bay will repair, provide replacement parts, or replace the product at our 2 years warranty only. -
Page 3: Pre-Assembly
Pre-assembly PLANNING ASSEMBLY Before beginning the assembly of this product, make sure all parts are present. Compare parts with Package Contents and Hardware Included lists. If any part is missing or damaged, do not attempt to assemble the product, and return it to the place of purchase. Assembly requires two people. -
Page 4: Package Contents
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Bed Frame Cushion Front Leg Leg 1 Leg 2 Wheels Connect Bar Mid Leg... -
Page 5: Assembly
Assembly Attaching the Legs to the Bed Frame Attach the Mid Leg (I) to the Bed Frame (A) by using the Screw M6x40 (FF), then use the Allen Key (GG) to secure. Attach Leg 1 (E), Leg 2 (F) and Wheels (G) to the Connect Bar (H) by using the Large Washers (DD). - Page 6 Assembly (continued) Attaching the Arms to the Bed Frame Attach the Arm (C) to the Assembled Bed Frame (A), by using the Bolt M8x65 (BB), Nut M8 (EE), and Allen Key (GG), then use the Allen Key (GG) to secure. Completing the Assembly Use Cap (HH) to cover all the exposed bolts.
- Page 7 Assembly (continued) Change Tilt Drag the top of the lounger to change the tilt. Place the stop bar in the groove to lock the tilt. This chaise lounge is ready to use now. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 8: Care And Cleaning
Care and Cleaning Always make certain to cover your outdoor wood furniture with waterproof covers when you are not using it. Using covers will protect your furniture from all weather elements and prolong the life of the wood furniture. Do not use plastic covers to protect your furniture as this may cause mold to grow on your furniture. - Page 9 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. Factory chaise lounge ID # HUC26214...
