SKU# 1007 490 584
Model# FRN-801820-S-2
USE AND CARE GUIDE
WOODFORD SECTIONAL - LEFT ARM
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
sectional
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY WOODFORD FRN-801820-S-2
Summary of Contents for HAMPTON BAY WOODFORD FRN-801820-S-2
- Page 1 8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM THANK YOU sectional quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
The frame is warranted to be free of manufacturing defects for two years from the purchase date. If the frame of your furniture fails (ie. broken frame or weld) within 2 years of ownership, Hampton Bay will repair, provide replacement parts, or replace the product at our 2 years warranty only. -
Page 3: Pre-Assembly
Pre-assembly PLANNING ASSEMBLY Before beginning the assembly of this product, make sure all parts are present. Compare parts with Package Contents and Hardware Included lists. If any part is missing or damaged, do not attempt to assemble the product, and return it to the place of purchase. Assembly requires two people. -
Page 4: Package Contents
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Back Frame Left Arm Right Leg Seat Frame Connect Bar Middle Leg Seat Cushion 1 Seat Cushion 2 Back Cushion... -
Page 5: Assembly
Assembly Attaching the Right Leg to the Back Frame Place all parts on a at, clean surface Attach the Back Frame (C) and Connect Bar (G) to the Right Leg (E) by using the Bolt M6x50 (HH), Cap Nut M6 (EE), Bolt M6x80 (DD), then use the Allen Key (II) to secure. - Page 6 Assembly (continued) Tightening the Back Tighten Back Frame (C) with Screw M6x40 (CC) and Allen Key (II). Attaching the Middle Legs Attach the Middle Legs (H) to the assembled frame, by using the bolt M6x35 (FF), Nut M6x15 (GG), then use the Allen Key (II) to secure.
- Page 7 Assembly (continued) Completing the Assembly Place the sofa on a at surface and put Seat Cushions (I and J) and Back Cushion (K) on the sofa. Place the sofa on a at surface. Adjust the plastic leveling feet if the four legs are not level. The sofa is ready to use now.
-
Page 8: Care And Cleaning
Care and Cleaning Always make certain to cover your outdoor wood furniture with waterproof covers when you are not using it. Using covers will protect your furniture from all weather elements and prolong the life of the wood furniture. Do not use plastic covers to protect your furniture as this may cause mold to grow on your furniture. - Page 9 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. Factory sofa ID # HUC39612...
