USE AND CARE GUIDE
WOODFORD 4 PIECE CHAT SET - LOVESEAT AND TABLE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY WOODFORD FRN-801820-1
Summary of Contents for HAMPTON BAY WOODFORD FRN-801820-1
- Page 1 8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM THANK YOU quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
The frame is warranted to be free of manufacturing defects for two years from the purchase date. If the frame of your furniture fails (ie. broken frame or weld) within 2 years of ownership, Hampton Bay will repair, provide replacement parts, or replace the product at our warranty only. -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Before beginning the assembly of this product, make sure all parts are present. Compare parts with Package Contents and Hardware Included lists. If any part is missing or damaged, do not attempt to assemble the product, and return it to the place of purchase. Assembly requires two people. -
Page 4: Package Content
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Table Top Table Leg Backrest Frame Seat Frame Right Arm Left Arm Connect Bar Middle Leg Back Cushion Seat Cushion... -
Page 5: Assembly
Table Assembly Attaching the Legs to the Table To the Table Top Attach the Table Legs (B) to the Table Top (A) by using the Nut (AA), Washers (BB), then use the Wrench (CC) to secure. Completing the Assembly Adjust the plastic leveling feet if the four legs are not level. The table is ready to use now. - Page 6 Loveseat Assembly Attaching Left Arm to the Loveseat Backrest Frame Attach the Left arm (F) and Connect Bar (G) to the Backrest Frame (C), by using the Bolt M6x50 (DD), Cap Nut M6 (JJ), Bolt M6x80 (GG), and Screw M6x40 (FF), then use the Allen Key (EE) to secure.
- Page 7 Loveseat Assembly (continued) Tightening Backrest Frame Tighten Backrest Frame (C) with Screw M6x40 (FF) and Allen Key (EE). Attaching the Middle Legs Attach the Middle Legs (H) to the assembled frame, by using the bolt M6x35 (HH), Nut M6 (II), then use the Allen key (EE) to secure.
- Page 8 Loveseat Assembly (continued) Covering Exposed Bolts Use Cap (KK) to cover all exposed bolts. Completing the Assembly (J) and Back Cushion (I) on the Loveseat. The Loveseat is ready to use now.
-
Page 9: Care And Cleaning
Care and Cleaning Always make certain to cover your outdoor wood furniture with waterproof covers when you are not using it. Using covers will protect your furniture from all weather elements and prolong the life of the wood furniture. Do not use plastic covers to protect your furniture as this may cause mold to grow on your furniture. - Page 10 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. Factory coffee table ID # HUC37724-1...
