Parts List - Linear Technology DC1811A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 4 CIN2, CIN3, CIN4, CIN5
3 6 COUT1-COUT3, COUT6-COUT8
4 2 COUT4, COUT5
5 2 C1, C14
6 1 C20
7 1 C23
8 3 C21, C22, C24
9 2 JP1, JP2
10 3 J2-J4
11 1 J1
12 6 J5-J10
13 1 Q1
14 7 R3, R5, R7, R9, R25, R31, R32
15 13 R10-R16, R18, R19, R24, R46, R47, R52
16 1 R30
17 3 R2, R44, R45
18 1 R22
19 1 R48
20 1 R53
21 1 U1
22 1 U2
Additional Demo Board Circuit Components
1 0 C2, C15-C17 (OPT)
2 0 R8, R26-R29, R33-R39, R41 (OPT)
3 0 R4, R6, R20, R23, R49 (OPT)
4 0 R50, R51 (OPT)
Hardware-For Demo Board Only
1 24 E1-E24
2 2 XJP1, XJP2
3 4 (STAND-OFF)
4 1
DEMO MANUAL DC1811A
PART DESCRIPTION
CAP., 150µF, 35V, ALUMINUM ELECTR.
CAP., X5R, 10µF, 35V, 10%,1210
CAP., X5R, 100µF, 6.3V, 20% 1210
CAP., 330µF, 6.3V, POSCAP, D3L
CAP., X7R, 2200pF, 25V, 10%, 0603
CAP., X5R, 100nF, 16V, 10%,0603
CAP., X7R, 1µF, 25V,10%, 0805
CAP., X5R, 1µF, 25V,10%, 0603
HEADER 3-PIN 0.079 SINGLE ROW
CONN, BNC, 5 PINS
CONN HEADER 12 POS 2MM STR DL PCB
BANANA SMALL
N-CHANNEL 30-V MOSFET
RES., CHIP, 0Ω, 1%, 0603
RES., CHIP, 10k, 1%, 0603
RES., CHIP, 6.34k, 1%, 0603
RES., CHIP, 4.99k, 1%, 0603
RES., CHIP, 4.22k, 1%, 0603
RES., CHIP, 0Ω, 0.5W, 2010
RES., CHIP, 0.01Ω, 1/2W, 1%, 2010
IC, LTM4676EY#PBF
IC, 24LC025T-E/OT SOT-23 6-LEAD
CAP., 0603
RES., 0603
RES., CHIP OPTIONAL
RES., CHIP, 30, 1%, 2010
TESTPOINT, TURRET, 0.062"
SHUNT
STAND-OFF, NYLON 0.50" tall
FAB, PRINTED CIRCUIT BOARD
MANUFACTURER/PART NUMBER
SUN ELECT., 35CE150AX
MURATA, GRM32ER6YA106KA12
AVX, 12106D107MAT2A
SANYO, 6TPF330M9L
AVX, 06033C222KAT2A
AVX, 0603YD104KAT
AVX, 08053C105KAT2A
AVX, 06033D105KAT2A
SAMTEC, TMM103-02-L-S
CONNEX, 112404
FCI 98414-G06-12ULF
KEYSTONE, 575-4
VISHAY, SUD50N03-09P
NIC, NRC06Z0000TRF
NIC, NRC06F1002TRF
VISHAY, CRCW06036K34FKEA
NIC, NRC06F4991TRF
VISHAY, CRCW06034K22FKEA
NIC, NRC50ZOTRF
VISHAY, WSL2010R0100FEA
LINEAR TECH. LTM4676EY#PBF
MICROCHIP, 24LC025T-E/OT
MILL-MAX, 2308-2-00-80-00-00-07-0
SAMTEC, 2SN-BK-G
KEYSTONE, 8833(SNAP ON)
DEMO CIRCUIT 1811A
dc1811afb
9
