(45 Gallon UTV Sprayer w/3-Nozzle Boom & 2" Receiver Mount)
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your lawn
& garden UTV sprayer.
BEFORE RETURNING THIS PRODUCT
FOR ANY REASON, PLEASE CALL
1-800-831-0027
MONDAY-FRIDAY, 8:00 AM TO 5:00 PM CST
If you should have a question or experience a problem with
your Fimco Industries Product: Visit our website @
www.fimcoindustries.com or call the Toll free number above. Our
technical support representatives will be happy to help you.
In most cases a customer service rep. can resolve
the problem over the phone.
To obtain prompt, efficient service, always remember to give the
following information....
• Correct Part Description and/or part number
• Model number and Serial Number
Part descriptions and numbers can be obtained from the
illustrated parts list section(s) of this manual.
Retain a copy of your receipt for your
unit, as it will be required to validate
any warranty service.
Warranted against manufacturer or
workmanship defects from date of
purchase with copy of receipt:
Homeowner Usage: Sprayer-One Year and Pump-Two Years.
Commercial Usage: Sprayer and Pump-90 Days.
OWNER'S MANUAL
Model: 45-3N-UTV-GS (5303650)
WARNING:
Cancer and Reproductive Harm.
www.P65Warnings.ca.gov
WARNING:
To reduce the risk of injury, the
user must read and understand the operator's
manual before using this product.
***IMPORTANT REMINDER***
IMPORTANT:
Occasionally check the strainer screen to ensure it is
clean and clear of any debris, especially if experiencing a
sudden loss of pressure. Strainer is located on the end of
the intake hose, inside of the tank. Use protective gear
when removing hose from tank and cleaning the strainer.
www.fimcoindustries.com
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440
[5195790
(08/22)]
Page 1
Advertisement
Table of Contents
Related Manuals for Fimco 45-3N-UTV-GS
Summary of Contents for Fimco 45-3N-UTV-GS
- Page 1 Warranted against manufacturer or workmanship defects from date of www.fimcoindustries.com purchase with copy of receipt: 1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049 Homeowner Usage: Sprayer-One Year and Pump-Two Years. Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440 [5195790 (08/22)] Commercial Usage: Sprayer and Pump-90 Days.
-
Page 2: Table Of Contents
Calibration and Tank Care ............. 7 Sprayer Dimensions ............13 Maintenance and Winter Storage ......... 8 Warranty ................14 Model: 45-3N-UTV-GS (5303650) (45 Gallon UTV Sprayer w/3-Nozzle Boom & 2” Receiver Mount) Technical Specifications • 45 Gal. Corrosion-Resistant Polyethylene Tank •... -
Page 3: Sprayer Contents
Sprayer Contents: Owner’s Manual Tank Pre-Assembly Tank Lid & Lanyard Receiver 6’ Boom Boom Support Feeder Hose & 2” Square Cap 3-Nozzle Bolted Boom, Nozzle Clamps (Bag of 3) & 3-Nozzle Harness (30” Spacing) Contents of Bolt Bag 5282588 Contents of Parts Bag # 5282494 Page 3... -
Page 4: Assembly Instructions
Assembly Procedure Assembly Instructions Your sprayer has been mostly assembled at the factory. Only assembly needed is the receiver boom mount and the boom. Make sure the contents of the sprayers carton match the items shown on page 3 of the manual. Remove all parts from the box and follow the instructions on pages 4 and 5 to complete assembly of this unit. - Page 5 Assembly Procedure Step 4 Step 4 Now, attach the nozzle harness to the boom with the nozzle clamps and the nozzles to the inside of the fold, pointing down. Starting with the center hose barb tee of the nozzle harness, center on the boom. Mount the nozzles 30” apart. Place a clamp half over the top of the boom tube and another clamp half below the boom tube, slide the clamp halves together into the groove in the square part of the nozzle.
-
Page 6: Operation
IMPORTANT: Remove tank lid and be sure the tank is clean and free of any foreign material. Rinse tank out of any tank residue before filling with water to test. Manifold Valves CLOSED Testing the Sprayer NOTE: It is VERY important to test this sprayer with plain water before actual spraying is attempted. -
Page 7: Calibration And Tank Care
Calibration Chemical labels may show application rates in gallons per acre, gallons per 1000 square feet or gallons per 100 square feet. You will note that the tip chart shows 2 of these rating systems. Once you know how much you are going to spray, then determine (from the tip chart) the spraying pressure (PSI), and the spraying speed (MPH). -
Page 8: Maintenance And Winter Storage
Drain and then refill half full, add the recommended amount of a good quality tank cleaner, such as FIMCO Tank Neutralizer and Cleaner. (If no tank cleaner is available, you may sub- stitute dish soap for this step, about 1-2 oz. -
Page 9: Pump Exploded View/Parts List
#5168833 3/8” Hose Barb Port Kit Fitting #5168836 DON’T • • Clean and rinse your pump after each use with Fimco Tank Use to pump bleach. Neutralizer. • Use to pump petroleum products such as diesel fuel, gaso- • Winterize your pump or sprayer by rinsing, draining and line or kerosene. - Page 10 Motor is NOT Running - Checking the Pressure Switch If motor is not running and you’ve checked the following: for loose wiring connections, fuse, switch on lead wire was “ON” and made sure you were connected to a fully charged battery but the motor won’t run, then it’s time to check to see if the pressure switch is bad.
-
Page 11: Sprayer Exploded Views
Handgun Hose See Manifold Detail Intake Next Page Hose Boom Feeder Hose Exploded View: 45-3N-UTV-GS (5303650) (See Parts List Below) See Boom & Harness Assembly Next Page for Breakdown & Parts List Page 11... -
Page 12: Boom Exploded View/Parts List
Manifold Assembly #5281538 Opposite Side has Typical Hardware Setup See Hinge Detail 3-Nozzle Boom Assembly (with 3/8” Hose, 1” Sq. Tubing & AIXR11002VP Tips) Clamp Bag of 3: 5281996 Hinge Detail Elbow Cross • 110° wide, tapered flat spray angle with air induction technology for better drift management •... -
Page 13: Sprayer Dimensions
Approx. Dimensions: 23” 24 39/64” 16 1/2” 25 13/64” 37 1/4” 61 13/16” Page 13... -
Page 14: Warranty
WHAT REMEDIES ARE AVAILABLE UNDER THIS LIMITED WARRANTY. If the conditions set forth above are fulfilled and the Equipment or any part thereof is found to be defective, Fimco, Ind. shall, at its own cost, and at its option, either repair or replace the defective Equipment or part.
