General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your lawn
& garden Trailer sprayer.
BEFORE RETURNING THIS PRODUCT
FOR ANY REASON, PLEASE CALL
1-800-831-0027
MONDAY-FRIDAY, 8:00 AM TO 5:00 PM CST
If you should have a question or experience a problem with
your Fimco Industries Product: Visit our website @
www.fimcoindustries.com or call the Toll free number above. Our
technical support representatives will be happy to help you.
In most cases a customer service rep. can resolve
the problem over the phone.
To obtain prompt, efficient service, always remember to give the
following information....
• Correct Part Description and/or part number
• Model number and Serial Number
Part descriptions and numbers can be obtained from the
illustrated parts list section(s) of this manual.
Retain a copy of your receipt for your
unit, as it will be required to validate
any warranty service.
Warranted against manufacturer or
workmanship defects from date of
purchase with copy of receipt:
Homeowner Usage: Sprayer-One Year and Pump-Two Years.
Commercial Usage: Sprayer and Pump-90 Days.
OWNER'S MANUAL
Model: 25-3N-TRL-GS (5303649)
(25 Gallon 3-Nozzle Lawn & Garden Trailer Sprayer)
NOTE:
Maximum Speed - 5 MPH
Refer to vehicle's manual for towing instructions.
WARNING:
To reduce the risk of injury, the
user must read and understand the operator's
manual before using this product.
WARNING:
Cancer and Reproductive Harm.
www.P65Warnings.ca.gov
***IMPORTANT REMINDER***
IMPORTANT:
Occasionally check the strainer screen to ensure it is
clean and clear of any debris, especially if experiencing a
sudden loss of pressure. Strainer is located on the end of
the intake hose, inside of the tank. Use protective gear
when removing hose from tank and cleaning the strainer.
www.fimcoindustries.com
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440
[5195788
(08/22)]
Page 1
Advertisement
Table of Contents
Related Manuals for Fimco 25-3N-TRL-GS
Summary of Contents for Fimco 25-3N-TRL-GS
- Page 1 1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049 Homeowner Usage: Sprayer-One Year and Pump-Two Years. Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440 Commercial Usage: Sprayer and Pump-90 Days.
-
Page 2: Table Of Contents
3-Nozzle Harness Exploded View and Parts List ....13 Calibration ................8 Sprayer Dimensions ............14 Maintenance, Tank Care and Winter Storage ....... 9 Warranty ................14 Model: 25-3N-TRL-GS (5303649) (25 Gallon 3-Nozzle Lawn & Garden Trailer Sprayer) Technical Specifications • 25 Gallon Corrosion-Resistant Polyethylene Tank •... -
Page 3: Sprayer Contents
Sprayer Contents: Tank Lid & Lanyard Owner’s Manual Trailer Boom Mount Tires/Wheels Tank Pre-Assembly Trailer Tongue 3-Nozzle Center Boom & Wings 3-Nozzle Harness Contents of Trailer Parts Bag #5281787 Contents of FJ Boom Parts Bag #5282587 Contents of Bolt Bag #5281789 Contents of Axle Kit #5281788 Page 3... -
Page 4: Sprayer Assembly
Assembly Procedure After removing the tank from the box, start the assembly Step 1 procedure by turning the tank upside on a stable, flat surface. A 1/2” socket wrench is required for this step. Do not over-tighten bolts. A) Mount the axle/tank supports to the underside of the tank as shown in Step 1. - Page 5 Assembly Procedure After the boom mount is secured to the tank. Step 5 1/2” socket wrench & wrench is required for this step. Attach the center portion of the boom to the boom mount, making sure the boom is centered. Secure in place with (2) flanged hex bolts and (2) flanged hex nuts.
- Page 6 Assembly Procedure Install the pressure gauge, hand tighten securely. ** DO NOT OVER-TIGHTEN ** Step 7 Screw the lid onto the tank. Place the end of the lanyard through the tab in the tank. This is so the lid can ‘hang’ off the tank when filling/rinsing the tank out.
-
Page 7: Operation
IMPORTANT: Remove tank lid and be sure the tank is clean and free of any foreign material. Rinse tank out of any tank residue before filling with water to test. Testing the Sprayer NOTE: Manifold Valves CLOSED It is VERY important to test this sprayer with plain water before actual spraying is attempted. -
Page 8: Calibration
Using the Boom Nozzles Four things must be considered before spraying with the boom. How much chemical must be mixed in the tank. Rate of spray (gallons per acre to be sprayed). What pressure (p.s.i.) will be used. ... -
Page 9: Maintenance, Tank Care And Winter Storage
Drain and then refill half full, add the recommended amount of a good quality tank cleaner, such as FIMCO Tank Neutralizer and Cleaner. (If no tank cleaner is available, you may substi- tute dish soap for this step, about 1-2 oz. -
Page 10: Pump Exploded View And Parts List
#5168833 3/8” Hose Barb Port Kit Fitting #5168836 DON’T • • Clean and rinse your pump after each use with Fimco Tank Use to pump bleach. Neutralizer. • Use to pump petroleum products such as diesel fuel, gaso- • Winterize your pump or sprayer by rinsing, draining and line or kerosene. - Page 11 Before Troubleshooting or Attempting to Service the Pump: ♦ Review Troubleshooting Chart: Do Not attempt to repair until steps below are followed. ♦ Personal Protective Gear: Wear protective gear when servicing pump. ♦ Disconnect Power: Disconnect the power to the pump and relieve the pressure from the system. ♦...
-
Page 12: Sprayer Exploded View And Parts List
Exploded View/Parts List: 25-3N-TRL-GS (5303649) See Next Page for 3-Nozzle Harness Handgun Hose Assembly Breakdown & Parts List Boom Feeder Hose Bypass Tube Intake Hose Page 12... -
Page 13: 3-Nozzle Harness Exploded View And Parts List
Manifold Assembly #5281538 3-Nozzle Harness Assembly Exploded View/Parts List Nozzle Detail Elbow Cross Based on the minimum overlap required to obtain uniform distribution with 120° tips and 40” spacing. Suggested Minimum Spray Height: 18”-20” above what is being sprayed (to plant, not ground). Optimum Spray Height: 39”... -
Page 14: Sprayer Dimensions
WHAT REMEDIES ARE AVAILABLE UNDER THIS LIMITED WARRANTY. If the conditions set forth above are fulfilled and the Equipment or any part thereof is found to be defective, Fimco, Ind. shall, at its own cost, and at its option, either repair or replace the defective Equipment or part.
