ASSEMBLY / OPERATION INSTRUCTIONS / PARTS
BEFORE RETURNING THIS PRODUCT
FOR ANY REASON, PLEASE CALL
1-800-831-0027
IF YOU SHOULD HAVE A QUESTION OR
EXPERIENCE A PROBLEM WITH YOUR
FIMCO INDUSTRIES PRODUCT:
1-800-831-0027
BEFORE YOU CALL, PLEASE HAVE THE
FOLLOWING INFORMATION AVAILABLE:
SALES RECEIPT & MODEL NUMBER. IN MOST
CASES, A FIMCO INDUSTRIES EMPLOYEE CAN
RESOLVE THE PROBLEM OVER THE PHONE.
GENERAL INFORMATION
The purpose of this manual is to assist you in operating and
maintaining your lawn and garden sprayer. Please read
it carefully as it furnishes information which will help you
achieve years of dependable trouble free operation.
WARNING
DO NOT USE PUMP IN AN EXPLOSIVE
ENVIRONMENT. DO NOT USE TO PUMP
FLAMMABLE FLUIDS, GASOLINE,
KEROSENE, FUEL OIL, ETC.
WARRANTY / PARTS / SERVICE
Products are warranted for one year from date of purchase
against manufacturer or workmanship defects.
MODEL: LG-15-EC
15 GALLON LAWN & GARDEN SPOT SPRAYER
5301302
Your authorized dealer is the best source of replacement
parts and service. To obtain prompt, efficient service, always
remember to give the following information:
1. Correct part description and part number.
2. Model Number of your sprayer.
3. Serial Number of your sprayer.
Part description and part numbers can be obtained from the
illustrated parts list section of this manual.
Whenever you need parts or repair service, contact your
distributor / dealer first. For warranty work always take your
original sales slip, or other evidence of purchase date, to
your distributor / dealer.
TECHNICAL SPECIFICATIONS
• Corrosion Resistant Polyethylene Tank
• 12 Volt Diaphragm Pump, Demand Switch
• 1.0 G.P.M.
• 15 Foot Handgun Hose
The sprayer is partially assembled at the factory. The only
assembly necessary is to hook up the wiring to an existing 12
volt power source. The red wire of the two wire set must be
connected to the positive post on the battery or the "Hot" con-
nection on a switch or to the ammeter. The brown wire may
be grounded or connected to the negative battery post.
It is important to test the sprayer with plain water before
actual spraying is attempted. This will enable you to check
the sprayer for leaks in the plumbing system.
In addition to an on/off switch, the pump on the sprayer is
equipped with a pressure switch that is factory set at a maxi-
mum of 35 PSI. The handgun may be shut off at anytime when
the pump system is running and the pump will be electrically
turned off by the pressure switch. When the handgun trigger
is squeezed the pump will start again. Use care when hooking
up the battery wires to the battery. Be sure the solution has
W W W . F I M C O I N D U S T R I E S . C O M
1000 FIMCO LANE • P.O. BOX 1700 • NO. SIOUX CITY, SD 57049
TOLL FREE: 800-831-0027 • TOLL FREE FAX: 800-494-0440
Form No. 1283
ASSEMBLY
OPERATION
(5004778 2/07) Printed In U.S.A.
