Sportsound
2000HD
Audio System
Installation & Maintenance Manual
Rev 4 – 12 March 2014
DD1798478
201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128
Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: 605-697-4746
Web: www.daktronics.com/support
Tables
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sportsound 2000HD and is the answer not in the manual?

Questions and answers

Related Manuals for Daktronics Sportsound 2000HD

Summary of Contents for Daktronics Sportsound 2000HD

  • Page 1 ® Sportsound 2000HD Audio System Installation & Maintenance Manual Rev 4 – 12 March 2014 DD1798478 201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128 Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: 605-697-4746 Web: www.daktronics.com/support Tables...
  • Page 3 ® Sportsound is a registered trademark of Daktronics, Inc. All other trademarks used in this manual are property of their respective owners.

  • Page 5: Table Of Contents

    Fiber Conversion Box ..................... 15 Section 6: Replacement Parts ..................... 17 Sound Cabinet ........................17 Fiber Conversion Box ......................17 Section 7: Daktronics Exchange and Repair & Return Programs ..........19 Exchange Program ........................ 19 Before Contacting Daktronics ..................19 Table of Contents...
  • Page 6 Repair & Return Program ....................20 Shipping Address ......................20 Daktronics Warranty and Limitation of Liability ............. 20 Appendix A: Reference Drawings ....................21 Appendix B: Supplementary Manuals ................... 23 Appendix C: Daktronics Warranty and Limitation of Liability............. 25 Table of Contents...

  • Page 7: Introduction

    Reference drawings in this manual are inserted in numeric order in Appendix A. Daktronics identifies manuals by the DD or ED number located on the cover page of each manual. For example, this manual would be referred to as DD1798478.

  • Page 8: Daktronics Nomenclature

    Power or signal jack Power or signal plug for the opposite jack Following the Replacement Parts List is the Daktronics Exchange Policy and the Repair & Return Program. Refer to these instructions if replacing or repairing any system component. Product Safety Approval Daktronics outdoor displays are ETL listed and tested to CSA standard for outdoor use.

  • Page 9: Sound System Components

    " (1645 mm) high by 21'-9" (6630 mm) wide. Drivers Three different types of drivers are used in the sound cabinet:  12" (305 mm) low frequency drivers: Daktronics part # A-2306: (Figure 4)  8" (203 mm) mid-range drivers: Daktronics part # A-2305 (Figure 5) ...

  • Page 10: Amplifier Components

    In sound systems, the amplifier is the last component before the drivers. It receives a signal from the source equipment and amplifies it to power the speakers. The Sportsound 2000HD sound system utilizes ten (10) power amplifiers with built-in Digital Signal Processor (DSP), which manages equalization, limiting, compression, and crossover functions.

  • Page 11: Mechanical Installation

    Section 3: Mechanical Installation A qualified technician must install the Sportsound 2000HD sound system cabinet. It is the customer’s responsibility to ensure that a qualified structural engineer approves the mounting structure and any additional hardware needed to secure the cabinet.

  • Page 12: Mounting The Cabinet

    Also, loads should be applied directly in the plane of the eyebolt as shown in Figure 10. Note: Daktronics assumes no liability for damages resulting from incorrect setup or lifting methods. Eyebolts are intended for lifting only. Do not attempt to permanently support the cabinet with the eyebolts or eyebolt holes.

  • Page 13: Electrical Installation

    System Riser; Electrical & Audio Notes ..........Drawing B-985713 Schematic; Control Enclosure/Sound Cabinet 2000HD ...... Drawing B-1082599 Drawing C-984140 details power and signal connections of the Sportsound 2000HD sound system. To gain access to internal power and signal connection points, open the far right rear access door (Figure 11).

  • Page 14: Power

    To access the internal components of the control enclosure, first loosen the 6 screws with a Philips head screwdriver, and then use the handle to lift the enclosure cover up and away so the screws pass through the keyholes. Refer to Figure 12 for component and connection locations within the sound cabinet and control enclosure and Drawing B-1082599 in Appendix A for a detailed wiring schematic.

  • Page 15: Signal

    Signal Six-core, multimode 50-micron fiber optic cable (Daktronics part # W-1489) must be run in conduit from the fiber conversion box location and terminated in a fiber splice box near the sound cabinet. Fiber patch cables (part # W-1512) will then run in conduit to the control enclosure media converter (FCC2).
  • Page 16 Refer to Figure 13 for external fiber conversion box connections and Figure 14 for internal connections and component locations. Refer to Detail “A” in Drawing C-984140 for analog backup connection and Detail “B” for fiber connection. Drawing A- 1095894 provides a detailed wiring schematic.

  • Page 17: Maintenance & Troubleshooting

    If the speaker mesh fades or tears over time, or if new graphics/logos are desired, it may be replaced. Only qualified sign companies should be used to replace the speaker mesh. Refer to Drawing B-983337 for speaker mesh layout. Contact Daktronics for mesh reordering. Removing Mesh Frame The front of the sound cabinet has a removable aluminum frame that secures the speaker mesh.
  • Page 18 Attaching New Speaker Mesh When ordered through Daktronics, the mesh has a line with a series of tick marks printed on the front (Figure 16). These tick marks are used to indicate the location of the tension clips and mandrels.
  • Page 19 Lay the mesh across the frame and snap each clip into the tension channels (Figure 19). Note: Pull on the corners of the mesh to remove any wrinkles. When pulling on the fabric, do not pull directly on the fabric flap or tension clip, or the clip may pop off.

  • Page 20: Troubleshooting

    Clipping audio at source Bring source level down (announcer’s rack) output below clip Blown driver in cabinet Contact Daktronics to verify defective equipment and replace Audio from cabinet is Amplifier modules within Reduce source output level intermittent...

  • Page 21: Indicator Lights

    For more troubleshooting steps, refer to the announcer’s rack manuals listed in Section 2.4. Indicator Lights Announcer’s Rack Refer to the troubleshooting section of a specific announcer’s rack manual for more information about the indicator lights. Fiber Conversion Box Within the fiber conversion box, indicator lights on the equipment help verify proper connection with sound cabinet.

  • Page 23: Replacement Parts

    Section 6: Replacement Parts Sound Cabinet Part Description Part Number Voltage Surge Protector A-1129 24 VDC Power Supply A-2238 1.4" Compression Driver A-2302 8" Midrange Driver A-2305 12" Woofer A-2306 Industrial Media Converter / Ethernet Switch, 16 Port A-2466 Power Amplifier SP1 1000 A-2469 Power amplifier SP2 1000-1000 A-2470...

  • Page 25: Daktronics Exchange And Repair & Return Programs

    The Daktronics Exchange Program is a service for quickly replacing key components in need of repair. If a component fails, Daktronics sends a replacement part to the customer who, in turn, returns the failed component to Daktronics. This decreases equipment downtime.

  • Page 26: Repair & Return Program

    Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: Call or fax Daktronics Customer Service: Refer to the appropriate market number in the chart listed on the previous page.

  • Page 27: Appendix A: Reference Drawings

    Appendix A: Reference Drawings Drawing Title Drawing Number Shop Drawing; Sound System; 2000HD ................... C-330901 Mesh Layout; 2000HD Gen II ....................B-983337 System Riser; 2000HD ......................C-984140 System Riser; Electrical & Audio Notes ..................B-985713 Speaker Adjustment Chart; 2000HD ..................C-1023805 Schematic;...
  • Page 30 REQUIRMENTS. THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE BROOKINGS, SD 57006 EXPRESSED WRITTEN CONSENT OF DAKTRONICS, INC. 4 JUN 12 ADDED MESH PART NUMBER AND REV TO DRAWING COPYRIGHT 2011 DAKTRONICS, INC. DO NOT SCALE DRAWING...
  • Page 34 24VDC PWR SPLY DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED A-2238 WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2012 DAKTRONICS, INC. A200 SPORTSOUND SYSTEMS A201 FIXED WIRE COLOR LABEL ON PIN 8 OF TRX1...
  • Page 35 FCC2 MOXA/EDS-205A FIELD INSTALLED POWER CORD; W-2524 FPP1 A-2580 NET2 NET3 NET4 V1 + NET5 V1 - W-1489, 6 CORE FILTER OUTPUT FIBER; TO FIBER CONNECTION SPLICE 0M-788412 E-1073 @3 P-1197@6 BOX/CONTROL PWS1 24VDC PWR SPLY ENCLOSURE A-2238 GRN/YEL SWT2 W-1615 TWISTED POWER INPUT AUDIO CABLE;...
  • Page 37 Appendix B: Supplementary Manuals Fiber Conversion Box / Sound Cabinet Component Manuals Biamp Audia Input & Output Expanders Operation Manual Moxa EtherDevice Switch Installation Guide Supplementary Manuals...
  • Page 38 AudiaEXPI/O-2 Input & Output Expanders Operation Manual Biamp Systems | 9300 S.W. Gemini Drive | Beaverton, OR | 97008 | USA | +1.503.641.7287 | www.biamp.com...
  • Page 39 INTRODUCTION AudiaEXPI/O-2 is an input/output expander that accepts two mic/line analog audio inputs, provides two channels of digital audio output via CobraNet, accepts two channels of digital audio input via CobraNet, and provides two mic/line-level analog audio outputs. Expander is in a convenient half-rack-width format.
  • Page 40 AudiaEXPI/O-2 - Front Panel Peak Indicators (Inputs 1–2): These red LEDs will light whenever input channel signal levels exceed 6dB below clipping. Use this feature to aid in the adjustment of the Trim controls (see below). Rotary Encoder & LCD Display: This control and display are used for initial setup of the AudiaEXPI/O-2 unit. When power is first applied to the unit, the display will cycle through a product description, followed by a title screen.
  • Page 41 SPECIFICATIONS...
  • Page 42 WARRANTY BIAMP SYSTEMS IS PLEASED TO EXTEND THE FOLLOWING 5-YEAR LIMITED WARRANTY TO THE ORIGINAL PURCHASER OF THE PROFESSIONAL SOUND EQUIPMENT DESCRIBED IN THIS MANUAL 1. BIAMP Systems warrants to the original purchaser of new THIS WARRANTY IS IN LIEU OF ALL OTHER products that the product will be free from defects in material WARRANTIES, EXPRESS OR IMPLIED.
  • Page 43 DoC MEX201003         EC Declaration of Conformity Biamp Systems Corporation, as manufacturer having sole responsibility, hereby declares that the following described product complies with the applicable provisions of the DIRECTIVES below except as noted herein. Any alterations to the product not agreed upon and directed by Biamp Systems Corporation will invalidate this declaration.
  • Page 44 Overview The EDS-205A/208A series of industrial Ethernet switches are entry-level industrial 5 and 8-port Ethernet switches that support IEEE 802.3, IEEE 802.3u, and IEEE 802.3x with 10/100M, full/half-duplex, and MDI/MDIX auto-sensing. The EDS-205A/208A series provides 12/24/48 VDC (9.6 to 60VDC)/18 to 30 VAC redundant power inputs that can be connected simultaneously to a live AC/DC power source.
  • Page 45 Panel Layout of EDS-205A/208A Panel Layout of EDS-205A-M-SC/ST (Standard) EDS-205A-M-SC EDS-205A-M-ST NOTE: Front Panel View Front Panel View The appearance of EDS-208A EDS-205A Front Panel View Front Panel View EDS-205A-S-SC is Grounding screw identical to Terminal block for EDS-205A-M-SC. power input P1/P2 Heat dissipation Grounding screw orifices...
  • Page 46 Panel Layout of EDS-208A-M-SC/ST Panel Layout of EDS-208A-MM-SC/ST EDS-208A-M-ST EDS-208A-M-SC EDS-208A-MM-ST EDS-208A-MM-SC NOTE: NOTE: Front Panel View Front Panel View Front Panel View Front Panel View The appearance of The appearance of EDS-208A-S-SC is EDS-208A-SS-SC is identical to identical to EDS-208A-M-SC.
  • Page 47 Mounting Dimensions (unit = mm) DIN-Rail Mounting The aluminum DIN-rail attachment plate should already be fixed to the back panel of the EDS when you take it out of the box. If you need to reattach the DIN-rail attachment plate, make sure the stiff metal spring is situated towards the top, as shown in the figures below.
  • Page 48 Grounding the EtherDevice Switch STEP 3: Once the screws are fixed on the wall, insert the four screw heads through the large parts of the keyhole-shaped apertures, and then slide the Grounding and wire routing help limit the effects of noise due to EDS-205A/208A downwards, as indicated.
  • Page 49 MDI Port Pinouts MDI-X Port Pinouts 8-pin RJ45 Signal Signal ST-Port Pinouts ST-Port to ST-Port Cable Wiring Cable Wiring RJ45 (8-pin) to RJ45 (8-pin) Straight-Through Cable Wiring Straight-Through Cable Switch Port NIC Port RJ45 Plug Pin 1 RJ45 RJ45 ATTENTION Connector Cable Wiring Connector...
  • Page 50 LED Indicators Switching and Address Learning The front panel of the Moxa EtherDevice Switch contains several LED The EDS has an address table that can hold up to 1024 addresses, which makes indicators. The function of each LED is described in the table below. it suitable for use with large networks.
  • Page 51 Power Input Voltage 12/24/48 VDC (9.6 to 60 VDC), 18 to 30VAC (47 to 63 Hz) Input Current @ 24VDC 0.1 A (EDS-205A) 0.11 A (EDS-205A-M/S) 0.13 A (EDS-208A) 0.17 A (EDS-208A-M/S) 0.22 A (EDS-208A-MM/SS) Connection Removable 4-contact terminal block Overload Current 1.1 A Protection...

  • Page 53: Appendix C: Daktronics Warranty And Limitation Of Liability

    Appendix C: Daktronics Warranty and Limitation of Liability Daktronics Warranty and Limitation of Liability...
