KIT INSTRUCTIONS
Imaging Scanner
7702-K165
Issue A

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7702-K165 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NCR 7702-K165

  • Page 1 KIT INSTRUCTIONS Imaging Scanner 7702-K165 Issue A...
  • Page 2: Revision Record

    NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
  • Page 3: Kit Contents

    Imaging Scanner This kit contains the components to add an Imaging Scanner to the 18.5" or 21.5" display of the RealPOS XR7 POS. Kit Contents...
  • Page 4: Installation Procedure

    Imaging Scanner Installation Procedure The procedure for installing the Imaging Scanner will depend whether the RealPOS XR7 POS is configured horizontally or vertically. Landscape Configuration 1. Lay the terminal face down on a flat surface. Caution: Always use a soft material (cloth, foam) to protect the display screen when placing the terminal face down.
  • Page 5 Imaging Scanner 3. Remove the Display Collar (9 screws). 4. Remove the Blank Plate from Port C of the Display Collar. The plate is connected to the Display Collar with a strong adhesive. Use care when removing it to not damage the Display Collar.
  • Page 6 Imaging Scanner 5. Screw the landscape mounting bracket on the Imaging Scanner (3 screws). 6. Connect the Right Angled Micro–B end of the USB Cable to the Imaging Scanner and route the cable through the strain reliefs.
  • Page 7 Imaging Scanner 7. Mount the Imaging Scanner on the Display Collar. a. Route the USB cable through the cable access of the Display Collar. b. Screw the mounting bracket with the Imaging Scanner onto Port C of the Display Collar (2 screws). 8.
  • Page 8 Imaging Scanner 9. Replace the Rear Cover on the terminal. Portrait Configuration 1. Lay the terminal face down on a flat surface. Caution: Always use a soft material (cloth, foam) to protect the display screen when placing the terminal face down. 2.
  • Page 9 Imaging Scanner 3. Remove the Display Collar (9 screws). 4. Remove the Blank Plate from Port B of the Display Collar. The plate is connected to the Display Collar with a strong adhesive. Use care when removing it to not damage the Display Collar.
  • Page 10 Imaging Scanner 5. Screw the portrait mounting bracket on the Imaging Scanner (3 screws). 6. Connect the Right Angled Micro–B end of the USB cable to the Imaging Scanner and route the cable through the strain reliefs.
  • Page 11 Imaging Scanner 7. Mount the Imaging Scanner on the Display Collar. a. Route the USB cable through the cable access of the Display Collar. b. Screw the mounting bracket with the Imaging Scanner onto Port B of the collar (2 screws).
  • Page 12 Imaging Scanner 8. Route the cable through the cable management feature of the collar. Secure the cable with tape. Note: Route the cable as straight as possible between the cable access and the cable management feature to avoid interference when reinstalling the display collar. 9.
  • Page 13 Imaging Scanner b. Connect the 5–POS end of the USB cable to the Motherboard. Tuck excess cable length along the sides of the board. 10. Replace the Rear Cover on the terminal.
