Grandstream Networks GVR355 Series Manual

H C
OW TO ONFIGURE
NVR/GVR355X
Unlike plastic case indoor camera GXV3611IR_HD, the metal case outdoor IP66 weatherproof
IP cameras GXV3672, GXV3674 and GXV3610 series do not have built-in Alarm_In and
Alarm_Out interface. But when combined with Grandstream GVR355X, SIP Prox or IP-PBX, the
GVR355X's built-in Alarm_In and Alarm_Out interface can be used to connect to related 3
party device like Door Bell/Intercom and Relay or Door Strike, to accomplish the SIP Open Door
function when configured with related SIP IP-PBX.
The benefit of such solution is that the GVR355X can only record all the person pressed the door
bell and door can be controlled (local or remotely) via video SIP calls, either via Grandstream IP
video hard phone like GXV3240 or GXV3275, or Grandstream GS_Wave soft phone (pending)
running on Android or iOS.
Following is the example of how to configure this feature. Recommend using latest firmware for
all related Grandstream device. The FW used in below example are:
•
GVR355x
•
GXV3610/3672/3674: FW: 1.0.3.13
Firmware beyond the above versions are required for this feature to function properly.
GXV3672/GXV3674/GXV3610 (IP Camera) Side:

• Basic - SIP Setting:

Figure 1: IP Camera Basic Settings – SIP Configuration
Grandstream Networks, Inc
www.grandstream.com
SIP O
PEN
W
AND EATHERPROOF
FW: 1.0.1.29
SIP Open Door using NVR/IPC
D G
OOR VIA RANDSTREAM
S IP C
ERIES AMERAS
Last Updated: 10/2015
rd
Page 1 of 6
