- Page 1 Amherst / Halifax / Washington Bedside Table Model # AXCRAMH46-HIC...
- Page 2 Great quality is a right. Thank you for shopping with Simpli Home, America's top brand for high-value furniture. It's time to register your product warranty. It's quick and easy. And you'll be happy you did. ü Activate your 1-year warranty ü...
- Page 3 Review your product and collect rewards! Thank you for your purchase! We hope you enjoy it. We’d love your feedback. Please share a review and get instant rewards! simpli-home.com/product-review Share photos and get your cash back! Send us images or share them on social and qualify for instant rewards.
- Page 4 For Fastest Customer Service: Open your phone’s camera. Point your phone’s camera at the QR code to scan. Click on the pop up. You’ll be taken to our customer service page. Fill the form with your order information and issue. Submit form.
- Page 5 IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. Safety Information Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. Hardware package may have spare parts.
-
Page 6: Care And Maintenance
Care & Maintenance This furniture is designed for indoor use. Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally along different grain directions. - Page 7 Pre-Assembly Information Model # AXCRAMH46-HIC Part Description RIGHT SIDE LEFT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF LEFT DRAWER SIDE DRAWER FRONT QTY 1 QTY 2 QTY 2 DRAWER BACK DRAWER BOTTOM RIGHT DRAWER SIDE QTY 2 QTY 2 QTY 2 BACK PANEL QTY 1...
- Page 8 Pre-Assembly Information Model # AXCRAMH46-HIC Hardware Description ALLEN KEY SCREW CAM LOCK PIN M6 X 30mm ALLEN KEY CAM LOCK QTY 20 QTY 1 QTY 8 SETS Required - Flathead screwdriver PHILLIPS SCREW ROUND HEAD HANDLE Phillips screwdriver M4 X 15mm M4 X 25mm Not Included QTY 12...
- Page 9 Components - Key Diagram Model # AXCRAMH46-HIC...
- Page 10 Assembly Model # AXCRAMH46-HIC Step 1 1. Attach four Cam Lock Pins 2 to pre-drilled holes at back of Drawer Front D . 2. Use Phillips screwdriver to secure Cam Lock Pins. Step 2 1. Align Cam Lock Pins with drilled holes and attach Drawer Sides EL , ER. 2.
- Page 11 Assembly Model # AXCRAMH46-HIC Step 3 1. Slide Drawer Bottom G firmly into slots on Drawer Side EL , E Drawer Front D . Step 4 1. Align Drawer Back F with Drawer Bottom G and press firmly into slot. 2.
- Page 12 Assembly Model # AXCRAMH46-HIC Step 5 NOTE: The screwdriver is not included in the hardware pack. 1. Use phillips screwdriver to attach Handle 5 to Drawer Front D . Repeat Step 1 - 5 for the second drawer.
- Page 13 Assembly Model # AXCRAMH46-HIC Step 6 using six Allen Key Screws 1 1. Attach Bottom Shelf C to Sides A (three screws on each Side). 2. Use Allen Key 3 to tighten Screws. Do not over-tighten. Step 7 1. Attach Top B to Sides A using six Allen Key Screws 1 (three Screws on each Side) .
- Page 14 Assembly Model # AXCRAMH46-HIC Step 8 NOTE: The screwdriver is not included in the hardware pack. 1. Attach Back Panels H to back frame of Table using twelve Phillips Screws Round Head 4 into drilled guide holes. 2. Use Phillips screwdriver to tighten Screws. Do not over-tighten.
- Page 15 Assembly Model # AXCRAMH46-HIC Step 9 1. Insert assembled Drawers into glides on assembled Table.
