Grill Assembly
16. Remove plastic cap from top of propane cylinder and turn
propane cylinder clockwise into regulator hand tight. (Fig. 16)
Insert the regulator pipe firmly. The regulator uses a push-on
17.
fitting to attach to the grill. It is necessary to hold the grill to make
sure the fitting is seated, Align the regulator to the fuel tube on
the side of the grill and push on until you hear the retainer "click"
into place (Fig. 17). Gently pull on the regulator to ensure that
the connection is secure.
18. Never operate grill with propane cylinder in an inverted position.
(Fig. 18)

Leak Check

WARNING
• Perform leak test outdoors.
• Extinguish all open flames.
• NEVER leak test when smoking.
• Do not use the outdoor grill until connection has been leak tested
and does not leak.
continued
Fig. 16
Fig. 17
Fig. 18
Note: Use Coleman 16.4 oz. disposable propane
cylinders. The LP-gas supply cylinder to be
used must be constructed and marked in
accordance with the specifications for LP-
gas cylinders of the
Transportation (DOT) or the National
Standard of Canada, CAN/CSA B339 ,
Cylinders, Spheres and Tubes for the
Transportation of Dangerous Goods.
U.S. Department of
9
