Coleman 9972 Series Assembly Manual page 7

Grill Assembly
6. Install grease tray onto tracks at bottom front of grill. (Fig. 6)
7. Insert tab on heat tent into slot on bracket at back of grill.
(Fig. 7)
Push down on tab at front of heat tent to lock into slot on grill
8.
bracket. (Fig. 8)
9. Install the remaining heat tent as shown. (Fig. 9)
10. Slip right side grill grate under tab at back of grill. (Fig. 10)
continued
Fig. 6
Fig. 7
Fig. 8
Fig. 9
Fig. 10
7
