Coleman 9972 Series Assembly Manual page 6

Grill Assembly
IMPORTANT: Remove all protective plastic film from stainless
steel parts and any packing materials from grill prior to
assembly/use. This film or packing materials are installed at the
factory to prevent damage that could occur during shipment
and handling.
With lid latched, lift up on handle and set grill so it is resting on
1.
the back of the case. (Fig. 1)
Note: Use a drop cloth to help protect the stainless steel finish.
2. Align bolts on leg with holes on bottom of grill and hand tighten
knobs clockwise to secure. (Fig. 2)
Install other leg as shown. (Fig. 3)
3.
Set grill upright on legs, open latch and lift lid up. (Fig. 4)
4.
5. Install crumb tray in center front of grill. (Fig. 5)
6
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
